Vax VRS203 Manuale utente

vax.co.ukVRS203, VRS204, VRS2041

VX3

Let’s get started

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

Please keep instructions for further use and use only as

instructed in this guide. This vacuum cleaner is intended for

household use only and NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors on dry surfaces and

keep the area you’re cleaning well lit.

• Keep ngers, hair and loose clothing away from moving parts

and openings whilst using the vacuum cleaner.

• Don’t use this vacuum cleaner if it has been dropped, damaged

or left outdoors.

• Don’t run over the power cord or use vacuum cleaner if the

power cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri: 8.30am to 6.30pm,

Sat: 9.00am to 5.00pm).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry this vacuum cleaner by the power cord.

Don’t use the power cord as a handle, pull the power cord

around corners, sharp edges or close a door over the power

cord. Don’t unplug vacuum cleaner by pulling on the power cord.

• Turn o all controls on the vacuum cleaner before

disconnecting or connecting the power cord.

• Always keep the power cord away from the brushes whilst

using your vacuum cleaner. After use always wrap the power

cord around the cord clips provided.

• Always make sure both the pre-motor/post-motor lters are

in place before use.

• Always make sure the brushbar is set to hard oor when

using your vacuum on the stairs and take extra care when

positioning the vacuum cleaner on the stairs.

• Always switch o the vacuum cleaner before disconnecting

or connecting the hose and accessories.

• This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

• Only Vax recommended tools should be used with this vacuum cleaner.

• Don’t use this vacuum cleaner if it has been dropped, damaged

or left outdoors.

• Don’t run over the power cord or use vacuum cleaner if the

power cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri: 8.30am to 6.30pm,

Sat: 9.00am to 5.00pm).

• Don’t handle the plug or use the vacuum cleaner with wet hands.

• Don’t pull or carry this vacuum cleaner by the power cord.

Don’t use the power cord as a handle, pull the power cord

around corners, sharp edges or close a door over the power

cord. Don’t unplug vacuum cleaner by pulling on the power cord.

• Don’t vacuum up any ammable or combustible materials (lighter uid, petrol,

kerosene etc.) or use the vacuum cleaner in an area with explosive vapours

or liquid.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to your vacuum cleaner.

• Don’t vacuum up hard or sharp objects such as glass, nails, screws or coins etc.

• Don’t use the vacuum cleaner with incorrect voltage as this may result in

damage or injury to the user. The correct voltage is listed on the ratings label.

• Keep all openings clear and free from debris as this may aect the

airow/suction.

• Always replace the fuse in the plug with a British 13amp fuse. Always protect

the power cable from heated surfaces and open ames.

• Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it could

be a trip hazard.

• Store the vacuum cleaner in a cool, dry area. If lters have been cleaned

as per user the guide instructions ensure they are thoroughly dry before

storing away.

Thank you for buying this VX3.

Taking care of your carpets and hard oors

The VX3 is designed to make vacuuming carpets and hard oors regularly, as eective and

ecient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer.

You’ve chosen carpets and hard oors for your home for a reason and Vax will help you take

good care of them.

Taking care of your VX3

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8.30am to 6.30pm, Saturday 9.00am to 5.00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK

This User Guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

What to do if it goes wrong

Getting in touch

Accessories

VX3

Included with

your machine

VX3 Pet

Accessory hose

Combination

oorhead

Dusting brush

Crevice tool

Tool connector

TurboTool

Telescopic

extension tube

Upholstery tool

Initial Setup for normal operation

1. Use the base accessories.

a. Shortest hose

b. Extension tube set to shortest practicable length.

2. Clean lters installed.

3. Dust receptacle empty.

4. All Bleeds must be closed.

5. Floorheads/tools set to Carpet Mode for carpet cleaning.

6. Mechanical Agitation turned ON for carpet cleaning.

7. Floorheads/tools set to Hard Floor Mode for hard oor cleaning.

8. Mechanical Agitation turned OFF for hard oor cleaning.

Getting to know your machine

Name VX3

Voltage 220-240V~50Hz

Wattage 800W

Cord length 5m

Weight 4.7kg

Technical Specication

Subject to technical change without notice.

Filter Kit (Type 95)*

1-1-134231-00

Pro Cleaning Kit (Type 2)

1-1-133326-00

Turbo Tool (Type 6)

1-1-134419-00

Accessories & Consumables

*To purchase consumables and accessories, please visit vax.co.uk

Getting started

Carry handle

Outer cyclone

Dirt container release button

Cord rewind button

Hose connector Base

Inner separator

Power on/o button

Wheel outer

Dirt container lid

Wheel inner

and lter housing

Dirt container

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

*To purchase consumables and accessories, please visit vax.co.uk

Getting started

Before you begin cleaning

• Always switch o and unplug the vacuum cleaner before connecting or disconnecting the hose/attachments,

or removing and emptying the dirt container.

• The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the

thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o and unplug

from electrical socket. Remove and empty the dirt container also check the vacuum cleaner for blockages. Allow the

vacuum cleaner to cool for approximately 1 hour (if you have cleaned the lters please wait 24 hours for the lters

to fully dry before putting back into the vacuum machine).

• Clean the pre-motor lter every time the dirt container is emptied and replace the post-motor lter every 12 months.

• If the vacuum cleaner is blocked, switch o and unplug before removing the blockage.

Assembling your cylinder

Insert the end of the hose

into the unit. Ensure the

hose has clicked into place.

Slot the metal telescopic extension

tube and hose handle together. All

accessories can be tted to the end

of the metal telescopic extension tube.

Fully unwind the power

cord. A yellow mark on

the cord indicates the

recommended cord length.

Do not exceed the cord

beyond the yellow mark.

Plug in and switch the

unit on by pressing the

power button.

When unwinding the power

cord always pull out to

the yellow marker but

no further.

CAUTION

Using your machine

For use on carpets, click

rocker switch forward. For

use on hard oors click

rocker switch back.

Slide vent cover on hose

grip open to reduce

suction if required.

Raise brushes for carpets. Lower brushes

for hard oors.

How to use

Using your machine

Brushes on the oorhead

should be visible when

using on hard oors.

TIP

IMPORTANT: The base of the vacuum cleaner should always be positioned at on the oor when starting and in use.

The dirt container should be locked into place before lifting the vacuum cleaner by the carry handle.

Cable rewind button

is located at the rear

of the machine. After

unplugging press the

cable rewind until the

cord is fully retracted.

For convenience there is a parking slot located at the

rear of the vacuum cleaner where the oorhead and

tubes can be attached for storage and carrying.

Using your machine

Choose an accessory. Attach accessory

to hose end.

If required use tool

connector.

Using accessories

Storage

Taking care of your machine

Cleaning the pre-motor lter

Remove dirt container

by pushing down the dirt

container release button and

lifting the dirt container.

Hold the dirt container and

twist the lid anti-clockwise.

Tap excess dirt from the lter. Rinse under a tap and leave to dry for 24 hours.

TAP

MAX

40˚C

MAX

40˚C

24hr

Hold the dirt container and press

the dirt release button located at

the rear of the dirt container.

Lift the lid to reveal the

pre-motor lter.

Hold dirt container over a

bin and press dirt release

button to open, allowing

dirt to fall out.

Lift out the pre-motor lter.

Emptying and cleaning the dirt container

Taking care of your machine

IMPORTANT: Always switch o and unplug the vacuum cleaner from the electrical socket before assembling,

opening or emptying the dirt container, or before connecting/disconnecting the attachments.

Pre-motor lter needs to be cleaned every time you empty the dirt container. Do not use your vacuum cleaner

without all of the lters in place.

The motor is equipped with a thermal cut-out. If for any reason the unit should overheat, the thermostat will

automatically turn the unit o.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Vax Aspirapolvere

Vax

Vax V-051 Scheda informativa del prodotto

Vax

Vax Air Series Istruzioni per l'installazione

Vax

Vax Rapide Plus 5140 Manuale utente

Vax

Vax VRS14W Manuale utente

Vax

Vax Impact 502 Istruzioni per l'installazione

Vax

Vax Energise Pulse U85-E2-Be Istruzioni per l'installazione

Vax

Vax Air Stretch U85-AS-Be Scheda tecnica

Vax

Vax VX64 Black Edition Manuale utente

Vax

Vax ONEPWR Spotless Go CLCW-MSKS Manuale utente

Vax

Vax Mach3 U90-M3 series Manuale utente

Vax

Vax White Manuale utente

Vax

Vax Rapide Ultimate W87-RH-P Manuale utente

Vax

Vax C91-MX SERIES Manuale utente

Vax

Vax V-039 Series Manuale utente

Vax

Vax VX2 Manuale utente

Vax

Vax Zero Advance VZ-302 Manuale utente

Vax

Vax MACH-5 VZL-7015AT Manuale utente

Vax

Vax C85-EW Series Istruzioni per l'installazione

Vax

Vax Power 2 C90-P2-H-E Manuale utente

Vax

Vax C87-ZM-B Manuale utente

Vax

Vax Air3 Agile Manuale utente

Vax

Vax HF86-DV-A Istruzioni per l'installazione

Vax

Vax Silentium Plus VBGSP1850 Manuale utente

Vax

Vax C90-M1 Series Manuale utente

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
