Vecom EPBC-1000 Manuale utente
USER
Manual
USER
Manual
1.4.0 Edition 20230530
Intel Atom®x6211E Processor (Elkhart Lake) 2.5” Pico-ITX Single Board
Computer 2 GigE LAN, 2 USB, 2 COM, 12V DC-in
EPBC-1000
ii
©Vecow EPBC-1000 User Manual
Version Date Page Description Remark
1.00 2022/05/20 All Ofcial Release
1.10 2022/10/04 64, 65, 66 Update
1.20 2022/11/30 7, 8 Update
1.30 2023/04/26 3, 36, 37 Update
1.40 2023/05/30 7, 49 Update
Record of Revision
iii
©Vecow EPBC-1000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks
iv
©Vecow EPBC-1000 User Manual
Part Number Description
EPBC-1000
EPBC-1000 2.5” Pico-ITX Single Board Computer, onboard Intel®
Atom® x6211E Processor (Elkhart Lake), DDR4 SO-DIMM, 2 GigE
LAN, 2 USB3.0, 1 COM RS-232/422/485, 1 COM RS-232,
12V DC-in
Order Information
Part Number Description
DDR4 32G Certied DDR4 32GB 3200MHz RAM
DDR4 16G Certied DDR4 16GB 3200MHz RAM
DDR4 8G Certied DDR4 8GB 3200MHz RAM
DDR4 4G Certied DDR4 4GB 3200MHz RAM
61-13Q1009-0DA COM Port Cable
61-193102U-156 USB 2.0 Cable
61-13B0707-386 SATA Data Cable
61-1470022-005 SATA Power Cable (5V only)
61-1300024-39A Audio Cable
75-VU2HSP0-010 Heat Sink for EPBC-1000
Order Accessories
v
©Vecow EPBC-1000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of EPBC-1000 3
1.4 Mechanical Dimension 5
1.4.1 Dimensions of EPBC-1000 5
1.4.2 Dimensions of Heat Spreader 5
1.4.3 Dimensions of Heat sink 5
1.4.4 Dimensions of MB+Heat Spreader 6
1.4.5 Dimensions of MB+Heat Sink 6
CHAPTER 2 GETTING TO KNOW YOUR EPBC-1000 7
2.1 Packing List 7
2.2 Main Board Expansion Connectors 9
2.3 Main Board Jumper Settings 24
CHAPTER 3 SETUP 26
3.1 Installing Heat Sink 26
3.2 Installing DDR4 SO-DIMM Modules 27
3.3 Installing SIM Card 28
3.4 Installing M.2 28
vi
©Vecow EPBC-1000 User Manual
CHAPTER 4 BIOS SETUP 30
4.1 BIOS Setup 30
4.2 Main Menu 31
4.3 Advanced Functions 32
4.4 Chipset Functions 40
4.5 Security Function 45
4.6 Boot Function 47
4.7 Save & Exit 48
APPENDIX A : GPIO Guide 49
APPENDIX B : Software Functions 52
APPENDIX C : Power Consumption 55
APPENDIX D : Supported Memory & Storage List 57
APPENDIX E : Driver install (Unknown Device ) 59
APPENDIX F : Install Win11 (BIOS TPM Setting) 64
1
©Vecow EPBC-1000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow EPBC-1000 is an 2.5" Pico-ITX Embedded Single Board Computer.
Powered by Intel Atom®x6000E Series processor, Vecow PBC-1000 brings
power-efficient, enhanced graphics performance and flexibility capabilities
to empower the edge applications such as Intelligent Control, Energy
Management, M2M, In-Vehicle Infotainment, factory Automation, and any AIoT/
Industry 4.0 applications.
Vecow EPBC-1000 is based on Intel Atom® x6211E processor and provides
low-power consumption with up to TDP 6W. With a variety of functionalities in
a small form factor (measuring only 100mm x 72mm), the EPBC-1000 includes
2 GigE LAN, 2 USB, 2 COM, 1 DisplayPort, and 1 SIM card socket for 5G/
WiFi/4G/LTE/GPRS/UMTS.
Vecow EPBC-1000 features fanless with small form factor design and supports
-40°C to 70°C operating temperature and 12V DC power input, making it
perfect solution for Intelligent Control, Energy Management, M2M, In-Vehicle
Infotainment, factory Automation, and any AIoT/Industry 4.0 applications.
1
2
©Vecow EPBC-1000 User Manual GENERAL INTRODUCTION
1.2 Features
• Dual-core Intel Atom® x6211E Processor (Elkhart Lake), TDP 6W
• 2.5" Pico-ITX compact size, Small Form Factor (SFF), measure only 100 x 72
mm
• Supports fanless -40°C to 70°C Operation
• 1 DDR4 3200MHz SO-DIMM, up to 32GB
• DisplayPort supports up to 4K resolution
• 2 GigE LAN, 2 USB 3.0, 2 COM
• SIM Socket for 5G/WiFi/4G/LTE/GPRS/UMTS
• Expansion : M.2 Key B, M.2 Key E
3
©Vecow EPBC-1000 User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of EPBC-1000
System
Processor Intel Atom® x6211E Processor (Elkhart Lake)
BIOS AMI
SIO IT8659E
Memory 1 DDR4 3200MHz SO-DIMM, up to 32GB
OS Windows 10, Linux
Graphics
Processor Intel® UHD Graphics for 10th Gen Intel® Processors
Interface DisplayPort : Up to 4096 x 2160 @60Hz
Ethernet
LAN 1 Realtek RTL8119I supports GigE LAN
LAN 2 Realtek RTL8119I supports GigE LAN
Audio
Audio Codec Realtek ALC888S-VD, 7.1 Channel HD Audio
Audio Interface 1 Mic-in and Line-out Header
I/O Interface
Front I/O • 2 RJ45 Connector
• 2 USB Connector
• 1 DisplayPort Connector
• 1 SIM Card Socket
• 1 Reset Button
• 1 Power LED
• 1 HDD LED
• 1 WLAN LED
• 1 WWAN LED
Internal I/O • 1 DDR4 SO-DIMM Socket
• 1 M.2 Key B Socket (2280)
• 1 M.2 Key E Socket (2230)
• 1 SATA Data Connector
• 1 SATA Power Connector
• 1 Power Connector
• 2 COM Header (1 RS-232/422/485, 1 RS-232)
• 1 USB 2.0 Header
• 1 GPIO Header
• 1 Audio Mic-in and Line-out Header
Storage
SATA 1 SATA III (6Gbps)
Expansion
M2 • 1 M.2 Key B Socket (2280)
• 1 M.2 Key E Socket (2230)
4
©Vecow EPBC-1000 User Manual GENERAL INTRODUCTION
Power
Power Input 12V DC-in
Power Interface 2-pin Terminal Block : V+, V
Others
Watchdog Timer Reset : 1 to 255 sec./min. per step
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Mechanical
Dimension 100.0mm x 72.0mm (9.34" x 2.83")
Environment
Operating
Temperature -40°C to 70°C (-40°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 75°C
EMC CE, FCC
