Vemer Iride Manuale utente

Chronothermostat

IRIDE

User Manual

- 1 -

Iride Chronothermostat User Manual

■Content of the package Page 3

■Connection diagrams Page 3

■Mounting Page 4

■Safety warnings Page 16

■Technical features Page 17

■Display and keyboard Page 18

■Installation Page 19

■Programming menu Page 22

- Time and date modiﬁcation Page 22

- Programs modiﬁcation Page 23

- Temperatures T1,T2,T3 modiﬁcation Page 24

- Timing setting Page 26

- Advanced functions menu Page 27

■Manual operation Page 30

■Off operation Page 31

■Backlighting management Page 33

■Minimum and maximum value Page 34

■Summer time change Page 34

■Regulation type Page 36

■Timings: what they are Page 38

■Device reset Page 40

■Battery replacement Page 40

■Reference standards Page 41

■Default values Page 42

■Winter preset programs Page 43

■Summer preset programs Page 44

Index

English

- 2 -

Iride Chronothermostat User Manual

Digital chronothermostat IRIDE

• Touch screen display of capacitive type

(sensible to the ﬁngers’ touch)

• Multicolour display red-green-blue according

to the gap between the measured temperature

and the set one (230V model only)

• Digital input for the connection of a telephone

dialler for switches on and switches off of the

device remotely

• Summer and winter operating mode

• Front panels of white and anthracite

grey colour included in the package

(you can buy silver on request)

• Battery or 230V power supply

• 7 programs available for the heating

mode

• 7 programs available for cooling

mode

• Weekly programming with 3 different

settable temperatures levels

• Flush-mounting on 3 modules box

(503 type)

English

- 3 -

Iride Chronothermostat User Manual

CONTENT OF THE PACKAGE

CONNECTION DIAGRAM

Chronothermostat

frames and plastic elements available in white and anthracite grey colors

frames mount A

mount B

plastic

elements VI plastic

elements BM

COM

NA NC

230V~

Iride 230

Iride

COM

NA NC

1 2 3 4 5

X.code

mount AIR

English

- 4 -

Iride Chronothermostat User Manual

BATTERY IRIDE MOUNTING

Bticino Living series, Light, Light Tech, Livinglight, Axolute

Vimar Eikon series, Eikon Evo, Plana

Ave S44 series – ABB Mylos series

English

- 5 -

Iride Chronothermostat User Manual

IRIDE 230 MOUNTING

Bticino Living series, Light, Light Tech, Livinglight, Axolute

Vimar Eikon series, Eikon Evo, Plana

Ave S44 series – ABB Mylos series

English

- 6 -

Iride Chronothermostat User Manual

BATTERY IRIDE MOUNTING

ABB Chiara series

Vimar Arké series

English

- 7 -

Iride Chronothermostat User Manual

IRIDE 230 MOUNTING

ABB Chiara series

Vimar Arké series

English

- 8 -

Iride Chronothermostat User Manual

BATTERY IRIDE MOUNTING

Gewiss Chorus series

Remove the cogs

English
