Radiance Natural Vent Gas Heater
20004409
The Radiance Natural Vent Room Heater, Model Nos. 3340
thru 3349, 3355, 3356 is a vented gas appliance listed to the
ANSI Standard Z21.88b-2001 and CSA-2.33b-2001 for Vented
Room Heaters, and CSA 2.17-M91, Gas-Fired Appliances For
Use at High Altitudes.
The installation of the Radiance Natural Vent Room Heater
must conform with local codes, or in the absence of local codes,
with National Fuel Gas Code, ANSI Z223.1/NFPA 54 — latest
edition and CSA B-149.1 Installation Code. (EXCEPTION: Do
not derate this appliance for altitude. Maintain the manifold pres-
sure at 3.5 inches w.c. for Natural Gas and 10 inches w.c. for LP
gas at maximum input.)
This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases unless a certified kit is used.
Installation and replacement of gas piping, gas utilization
equipment or accessories, and repair and servicing of
equipment shall be performed only by a qualified agency.
The term “qualified agency” means any individual, firm,
corporation, or company that either in person or through a
representative is engaged in and is responsible for (a)
installation or replacement of gas piping, or (b), the
connection, installation, repair, or servicing of equipment,
whoisexperiencedinsuchwork,familiarwithallprecautions
required, and has complied with all the requirements of the
authority having jurisdiction.
The Radiance Natural Vent Room Heater should be
inspected before use and at least annually by a qualified
service agency. It is imperative that control compartments,
burners,andcirculatingairpassagewaysoftheappliancebe
kept clean.
TheRadianceNaturalVent Room Heateranditsindividual shut-
off valve must be disconnected from the gas supply piping dur-
ing any pressure testing of that system at test pressures in ex-
cess of 1/2 psig (3.5 kPa).
TheRadianceNaturalVentRoomHeatermustbe isolated from
the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply pip-
ing system at test pressures equal to or less than 1/2 psig.
An accessible tap is located above the pilot/On-Off knob for
checking the inlet pressure.
This appliance needs fresh air for safe operation and must be
installed so there are provisions for adequate combustion and
ventilation air.
This appliance must be properly connected to a listed 4”
(100mm) Type B venting system or to an approved masonry or
factory-built chimney system. In Canada, a complete reline of
ClassA chimneysisrequired.Thisheaterisequippedwithavent
safety shutoff system.
Thisapplianceisapprovedforbedroom installations in the U.S.
and Canada.
This appliance may be installed in an aftermarket* manufac-
tured(mobile)home,wherenot prohibited bystateorlocalcodes.
WARNING: Operation of this heater when not connected
to a properly installed and maintained venting system can
result in carbon monoxide (CO) poisoning and possible
death.
The Radiance Natural Vent Room Heater, when installed, must
be electrically grounded in accordance with local codes or, in
the absence of local codes, with the National Electrical Code
ANSI/NFPA70, (latest edition), or of the current Canadian Elec-
trical Code C22.1.
Dueto hightemperaturesthis applianceshouldbelocated
out of traffic and away from furniture and draperies.
WARNING: This appliance is hot while in operation. Keep
children, clothing, and furniture away. Contact may cause
burns or ignition of combustible materials.
Children and adults should be alerted to the hazards of
high surface temperatures and should stay away to avoid
burnsorclothingignition.Youngchildrenshouldbecarefully
supervisedwhentheyareinthesameroomastheappliance.
Clothingorotherflammablematerialsshouldnotbeplaced
on or near the appliance.
Anysafetyscreen,glassorguardremovedforservicingan
appliancemustbe replacedpriortooperating theappliance.
The appliance area must be kept clear and free from
combustiblematerials,gasoline,andotherflammablevapors
and liquids.
The flow of combustion and ventilation air must not be
obstructed. The installation must include adequate
accessibility and clearance for servicing and proper
operation.
WARNING: Donot operatethe RoomHeater withthe glass
panel removed, cracked or broken. Replacement of the
panel should be done by a licensed or qualified service
person.
Donotuse thisappliance ifanypart hasbeen underwater.
Immediatelycallaqualifiedservice techniciantoinspectthe
appliance and to replace any part of the control system and
any gas control which has been under water.
Donotburnwood,trashoranyothermaterialforwhichthis
appliance was not designed. This appliance is designed to
burn either natural gas or propane only.
This gas appliance must not be connected to a chimney
flue serving a separate solid-fuel burning appliance.
CAUTION: Label all wires prior to disconnection when
servicing controls. Wiring errors can cause improper and
dangerous operation.
Verify proper operation after servicing.
* Aftermarket: Completion of sale, nor for purpose of resale,
from the manufacturer.
Installation & Operating Instructions
Proposition 65 Warning: Fuels used in gas,
woodburning or oil fired appliances, and the products
of combustion of such fuels, contain chemicals known
to the State of California to cause cancer, birth defects
and other reproductive harm.
California Health & Safety Code Sec. 25249.6
