1L Electric Water Sprayer
K257 v01: 30/07/21
Please read and retain these instructions for future reference
ASSEMBLY INSTRUCTIONS / INSTRUCTIONS FOR USE:
Unpack the components carefully. Please check all parts have been removed from the packaging.
Specification
Charging Voltage
5V DC
Charging Current
500mA
Battery capacity
One charge continuous working time 60 min
(2000mAh)
Spray power
Maximum spray distance is 6m
Volume
1L
Weight
345g
Working temperature
>0-40°C
Warning
•Charge up first without the bottle, then fill the bottle with water.
•Do not spray flammable liquids (petrol, alcohol etc.)
•Not suitable for spraying any chemicals such as pesticides.
•When using the product keep nozzle away from your face.
Attention
•Product cannot be used upside down.
•When the indicator light is only one light and flashing, please charge before use. Use phone charger
cable to charge. LED light will turn green when fully charged.
Dimensions
(H) 29.5 x (W) 16 x (D) 13.5cm
•1000ML Capacity
•Voltage –3.6V
•Battery –2000MAH
•Flow Rate –280-460ml a min
•Nozzle Size 1.3mm
•USB Charger (included)
•Has adjustable Spray Patterns
•Can be used for an hour on a single charge
•Has a water level
•Has a power indicator
•Can be used with natural plant fertilisers
1L Electric Water Sprayer K257 Instructions for Use
Please read and retain these instructions for future reference v001: 30/07/21
Parts
1L Electric Water Sprayer K257 Instructions for Use
Please read and retain these instructions for future reference v001: 30/07/21
Operation
1. Open the bottle body as shown, add the
required amount of water. Do not overfill. Then
tighten.
2. The sprayer will continue working after the
switch has been pressed. Press the switch again
to turn off.
3. The nozzle can be adjusted to a jet or mist
mode depending on your requirements.
After each use
•Pour out the residue in the bottle and rinse
with clean water.
•Unscrew the nozzle and rinse the residual
impurities with water.
•Pull out the water filter and rinse.
•Warning: Keep motor switch and electrical lines
away from water.
Power connection:
Insert the USB receiver into the energizing port and plug the other end into the power port.
This product is suitable for general USB interface line, which can be connected to mobile power supply,
computer, ordinary and vehicle-mounted power supply, etc.
DISPOSAL
•Coopers of Stortford use recyclable or recycled packaging where possible.
1L Electric Water Sprayer K257 Instructions for Use
Please read and retain these instructions for future reference v001: 30/07/21
•Please dispose of all packaging, paper, cartons, packaging in accordance with your local
recycling regulations.
•Plastics, polybags –this is made from the following recyclable plastic.
Code &
Symbol
Type of
Plastic
Low Density Polyethylene
Commonly
used for
Shopping bags, bread bags, squeezy bottles, stretch/pallet wrap, bubble wrap, multi-pack can holders
Notes
Usually recyclable supermarket deposit points. Check other plastic films as any non-polythene film e.g.
cling film, crisp packets film lids
•At the end of the product’s lifespan please check with your local council authorised household waste
recycling centre for disposal.
