Brushcutter VB 260 L
• Forged steel crankshaft and connecting rod for long life and unwavering performance over
time.
• Starter housing and nose cone in aluminium for maximum strength, even when tackling heavy
workloads.
• Equipped with generously proportioned clutch giving improved control of the machine (tool
stays motionless at idling speed), increased protection to the engine, and better results when
cutting long grass.
• Flywheel with large fins designed to provide optimum cooling, even in high ambient
temperatures.
• Self-lubricating sheath protecting the transmission and guaranteeing fewer vibrations, for
increased working comfort.
• Carburettor filled by primer with fuel mixture to ensure easy starting with a limited number of
pulls, even after lengthy periods of inactivity.
• Tap ‘n Go head fitted as standard: no disruption of work, with line feed induced automatically
by tapping the head on the ground.
• Superior quality anti-vibration system with 5 self-lubricating bushes along the bore of the shaft
arm tube and 1 anti-vibration mount at the aluminium nose cone, for maximum operating
comfort.
• Easy access to air filter, with no tools needed, ensuring maximum convenience for cleaning
and maintenance purposes.
Brushcutter VB 260 L
QUALITY MARKS
EMAK - 2-stroke
1.0 HP - 0.8 kW / 25.4 cm3
0.75 L
rigid / 26 mm
single
1 mount on nose cone
+ 5 self-lubricating bushes in tube
yes
5.6 Kg
Tap’n go” head Ø 130 mm,
Ø 2.4 mm line
38 cm
single
61319001E2
183 x 22 x 30
50 / 183 x 108 x 128 (30 pz)
183 x 108 x 88 (20 pz)
700
600
8026619022693
PRODUCT DATA
TECHNICAL SPECIFICATIONS
Engine
Power / Displacement
Fuel tank capacity
Transmission / Tube diameter
Handle
Anti-vibration system
Clutch
Weight
Standard cutting tools
Cutting diameter
Harness
Product Code
Dimensions, single pack (cm)
Quality / Dimensions, pallet (cm)
Quality / Truck, 1360 cm
Quality / 40’ ctr, palletized
EAN Code
