Videofield XTO-IP Manuale utente

XTO-IP ALARM PANEL

INSTALLATION MANUAL

DOC. - REF. 230-XTO-IP-AUS

MODIF. DATE : NOVEMBER 2016

FIRMWARE VERSION : XLP.04.04.00.XXX AND LATER

XTO-IP Alarm panel

INSTALLATION MANUAL

Description

The XTO-iP is a fully wireless alarm system. It is powered by standalone Lithium batteries. This panel has

been designed for outdoor installations, with its weatherproof casing and extended operating temperature

range.

With the Motion Viewers™ and Videofied®range of products, the XTO-iP panel provides video verification

in case of intrusion.

Technology

The XTO-iP alarm panel, like all Videofied devices, uses the S2View®patented technology. Which is an

interactive wireless and AES encrypted technology ensuring signal integrity and optimal security.

The reliability of the signal is guaranteed thanks to the two-way radio frequency transmissions with all the

peripherals of the Videofied®product line.

The integrated antennas allow the system to be totally wireless, thus preventing from the system beeing

inelegant and cumbersome, and eliminating the installation problems.

The jamming detection feature identifies any intentional jamming from a third party. On the other hand, the

supervision feature consists of transmitting signals between every device of the system and the alarm panel

XTO-iP. Through the supervision, the detectors transmit every 8 minutes a presence signal.

The entire RSI VIDEO TECHNOLOGIES team wishes you a successful installation.

INTRODUCTION

XTO-IP Alarm panel

INSTALLATION MANUAL SUMMARY

Introduction............................................................................................................2

Summary..................................................................................................................3

1. XTO-iP panel setup..........................................................................................................4

1.1 SIM card installation.............................................................................................................4

1.2 Panel bracket mounting..........................................................................................................4

1.4 Powering and initialization......................................................................................................5

1.5 Pairing the keypad..................................................................................................................6

1.6 Cover locking..........................................................................................................................6

2. XTO-iP panel programming.....................................................................................................7

3. XTO-iP features guide......................................................................................................13

3.1 Get to access level 4...........................................................................................................13

3.2 How to Arm/Disarm the system.............................................................................................13

3.3 Arming and Siren Mode Configuration.................................................................................14

3.4 Manage badges and access codes........................................................................................15

3.5 Delete the keypad or any other device..................................................................................17

3.6 Read the event log.................................................................................................................18

3.7 Golden rules...........................................................................................................................18

4. Transmitted events list......................................................................................................19

5. 2G3G error codes............................................................................................................20

6. Technical specification and security notes....................................................................21

INSTALLATION MANUAL 1. XTO-IP PANEL SETUP

XTO-IP Alarm panel

1.2 Panel bracket mounting

The four screwholes here opposite are intended to

mount the bracket, the latter beeing used to attach

the panel to the wall or a pole.

Mounting the panel is not required for programming.

Screwholes

1.1 SIM card installation

Before removing the front cover from its box, Put the SIM

card on the plastic base (Take care to respect the right

direction).

DO NOT insert or remove the SIM card while the panel is

powered.

INSTALLATION MANUAL 1. XTO-IP PANEL SETUP

XTO-IP Alarm panel

1.3 Powering and initialization

• The panel is powered either with 4 LSH20 Lithium batteries.

• Always replace all 4 batteries at once. Mixing new and used batteries can severely damage the panel (risk of explosion).

• Press and hold the PROGRAMMING BUTTON for 10 seconds, until the indicator LED blinks twice.

• The panel is now reset, a CMA, XMA or XMB has to be enrolled to configure the panel.

Programming button

INSTALLATION MANUAL 1. XTO-IP PANEL SETUP

XTO-IP Alarm panel

1.5 Cover locking

Place and screw the cover on

its support.

• Press the XTO programming button and release for the enrollment of a programming

keypad.

• Insert all LS14500 Lithium batteries into the keypad.

• Do not mount the keypad. It will display one of the following screens:

1.4 Pairing the remote keypad

YLGHR¿HGFRP <=========XX=========>

• Press on both

CLR

and

ESC NO

keys at the same time

and release. The indicator

LED on the keypad will blink rapidly. Wait for the keypad to pair.

• If the keypad doesn’t pair up with the panel and shows «XX», it certainly means

that it is still paired to another system and needs to be reset. Take the batteries out,

and press repeatedly on the keypad tamper switch. Then proceed to the above

steps.

Screw locking

INSTALLATION MANUAL 2. XTO-IP PANEL PROGRAMMING

XTO-IP Alarm panel

Keypad Display Actions and comments

KEYPAD 1

RECORDED

RADIORANGE TEST?

RF TEST

x/9

RF TEST

9/9

RADIORANGE TEST?

INSTALLER CODE

4 TO 6 DIGITS

THEN OK/YES

INSTALLER CODE :

< - LANGUAGE : - >

ENGLISH (UK)

The system can also be programmed in : french, italian,

german, dutch, spanish, swedish, portuguese, danish,

czech and polish.

The language can be changed at any time once the panel

is programmed in the MAINTENANCE menu.

The Radio Range test must be run during the device

learning process in order to ensure proper pairing with

the control panel. This test measures the strength of

communication between the device and the control

panel. The keypad will display a real time radio range

value on a scale of 9.

To receive the most accurate results you must run the

radio range test for at least 30 seconds.

Result must be 8 out of 9 or better for reliable

transmission.

Using the Alphanumeric Keypad, enter the Installer Code

of your choice.

The Installer Code will be used for all future maintenance

and conﬁguration.

This code is important to keep track of.

There is no back door or Default codes to the

system

Please refer to the restriction rules for codes (Chapter 4.5).

Some codes are already used by default and therefore

cannot be used.

OK or YES

Please wait

OK or YES

ESC

for language selection

OK or YES

CONFIRM CODE

OK or YES

INSTALLATION MANUAL 2. XTO-IP PANEL PROGRAMMING

XTO-IP Alarm panel

Keypad display Actions and comments

CODE NAME :

OK or YES

ACCESS 1

REGISTERED

You may name the installer code using the Alphanumeric

Keypad.

If using automatic setting (called installer default list),

enter the name of the list.

Warning : If the wrong installers list name is used it

cannot be set later, the system must be defaulted.

Leaving the name blank by pressing

ESC NO

, it will be

named ‘ACCESS 1’ by default.

Please wait

ADJUSTING DATE

AND TIME

DATE (YEAR):

12/ /

To set the year

OK or YES

DATE (MONTH):

13/01/

To set the month

OK or YES

You may proceed in the same way for:

Day, Hour and Minutes.

13/10/14 10:47

ENTRY COMPLETE !

ACCOUNT NUMBER :

CONNECTED TO

021,72567$7,21"

OK or YES

Use the Alphanumeric Keypad to enter in a 4-8 digit

account number provided by the Central Station.

ACCOUNT NUMBER :

567001

OK or YES

ESC

INSTALLATION MANUAL 2. XTO-IP PANEL PROGRAMMING

XTO-IP Alarm panel

TEST (hour) :

04:

CODE/STATE

MODIFICATION?

Test Periodicity: 1 hour, 12 hours, 24 hours, 48 hours, 7

days or no tests.

We suggest a 24 hours periodic test call.

PERIODIC TEST

PERIODIC TEST :

24 HOURS

To select periodicity

OK or YES

7(67PLQXWHV

04:15

OK or YES

CODE/STATE

MODIFICATION

Keypad display Actions and comments

The CODE/STATE MODIF. menu is to conﬁgure the

transmitted events to the monitoring station, use the

arrow keys to toggle between events and

OK or YES

modify.

ALARM: event transmitted upon occurrence.

ALARM/END: event is transmitted on occurrence and

on event restoral.

NOT TRANSMITTED: event is not transmitted, however

it will appear on the keypad.

Please liaise with your Monitoring Station to ensure

that the requested events to transmit are correctly

set.

(YHQWVOLVW

ESC

SERVER

ADDRESSES ?

OK or YES

Wait

ESC

INSTALLATION MANUAL 2. XTO-IP PANEL PROGRAMMING

XTO-IP Alarm panel

IP1 ADDRESS



DOMAIN NAME 1 PORT 1

888

SERVER

ADDRESSES ?

SERVER

ADDRESSES ?

The IP1 address, Domain name 1 and/or Port 1 are provided by the monitoring station.

Leave Port details at 888 unless otherwise instructed.

Press

OK or YES

to enter/modify the parameter then

OK or YES

for validation.

WARNING : You will use either an IP address or a Domain name but not both, leave the

Domain name blank if an IP address has already been entered.

Press on the right arrow to conﬁgure IP/Domain name 2 and PORT2 (for the back-up server),

and IP/Domain name TMT and PORT TMT (to conﬁgure remote maintenance server).

OK or YES

ESC

OK or YES

APN CODE

LQWHUQHWHQWUHSU

USER NAME

RUDQJH

PASSWORD

RUDQJH

The APN Code (Access Point Name), User Name and Password are supplied by the

mobile operator. Please make sure you have entered the code exactly as indicated by your

local SIM card operator.

Press

OK or YES

to enter/modify the parameter then

OK or YES

for validation.

Note: When entering your SIM card settings, both APN codes, username and password

ﬁelds are case sensitive! It makes a diﬀerence between UPPER and lower case letters.

To switch between UPPER and lower case, use the M/m key from CMA keypad or hold a

digit key (0-9) for XMA/XMB.

ESC

2G3G

PARAMETERS ?

2G3G

PARAMETERS ?

2G3G LEVEL ?
