Vidia SJ-002 Manuale utente
juicer
SJ-002
1. You should read <Precautions for safe use>
2. You should follow <Precautions for safe use>
3. Precautions are classified as follows.
Warning When violating the labeling requirement, it may cause serious injury or death.
DO NOT PLUG IN NOR UNPLUG WITH WET HANDS. It may cause electric shock or injury.
DO NOT USE OTHER THAN 230 V AC. It may cause electric shock, fire or abnormal performance. If the voltage is
different, it may shorten the life of the motor or cause a failure.
PLUG THE POWER CORD CORRECTLY AND PUSH IT TIGHT IN A WALL SOCKET.
It may cause an electric shock or a fire.
IF UNUSUAL SOUND, SMELL, SMOKE, EXCESSIVE HEAT AND OTHER ABNORMAL SITUATION OC-
CURS WHILE OPERATING, PLEASE TURN OFF THE POWER IMMEDIATELY AND CONTACT THE LOCAL
CUSTOMER CARE CENTER. It may cause an injury or a failure.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR BY YOURSELF. DO NOT
INSERT FINGERS, FOREIGN SUBSTANCES OR OBJECTS SUCH AS PINS INTO GAPS OR HOLES IN THE
BODY. It may cause a fire, electric shock or failure. For any technical support, contact the authorized local Customer
Care Center.
WHEN THE POWER CORD AND WIRE ARE BROKEN OR DAMAGED AND THE PLUG-IN PART BECOMES
LOOSE, DO NOT OPERATE THE MACHINE. It may cause electric shock, fire or injury.
DO NOT MOISTEN THE BODY OR SPLASH WATER ON THE BODY.
Be careful not to let any liquids or other substances get into the switch on the appliance.
DO NOT OPERATE THE SWITCH WITH WET HANDS. It may cause an electric shock or fire.
FOR SAFETY, MUST DO GROUNDING CONNECTION. ALSO, DO NOT DO GROUNDING ON GAS PIPE,
PLASTIC WATER PIPE, TELEPHONE WIRE, ETC. It could cause electric shock, fire, malfunction or explosion.
Be sure to use the electrical outlet with ground connection.
NEVER DISASSEMBLE THE DRUM SET DURING OPERATION NOR INSERT FINGERS, FOREIGN OB-
JECTS SUCH AS FORKS, SPOONS, ETC. INTO HOPPER CHUTE OR JUICE OUTLET. It may cause injury,
accident or failure.
KEEP THE APPLIANCE OUT OF REACH OF CHILDREN. APPLIANCES CAN BE USED BY PERSONS WITH
REDUCED PHYSICAL, SENSORY OR MENTAL CAPABILITIES OR LACK OF EXPERIENCE AND KNOWL-
EDGE IF THEY HAVE BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING USE OF THE APPLI-
ANCE IN A SAFE WAY AND IF THEY UNDERSTAND THE HAZARDS INVOLVED. CHILDREN SHALL NOT
PLAY WITH THE APPLIANCE. CLEANING AND USER MAINTENANCE SHALL NOT BE MADE BY CHIL-
DREN. THIS APPLIANCE SHALL NOT BE USED BY CHILDREN. KEEP THE APPLIANCE AND ITS CORD
AWAY FROM CHILDREN. This appliance is not intended for use by persons lack of experience and knowledge
including children. Use of the appliance by the children concerning cause of injury, accident or failure.
IF THE SUPPLY CORD IS DAMAGED, IT MUST BE REPLACED BY THE MANUFACTURER ITS SERVICE
OR SIMILARLY QUALIFIED PERSONS IN ORDER TO AVOID A HAZARD.
NEVER ALTER THE APPLIANCE. ALSO, DO NOT DISASSEMBLE OR REPAIR BY YOURSELF.
Precautions for safe use
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 2 2015-11-18 오전 9:06:14
Warning When violating the labeling requirement, it may cause serious injury or death.
Caution When violating the labeling requirement, it may cause serious injury or damage to the appliance.
DO NOT INSERT FINGERS, FOREIGN SUBSTANCES OR OBJECTS SUCH AS PINS INTO GAPS OR HOLES
IN THE BODY. If using other object, it may cause a part damage, an injury, or a failure
WHEN DETECTING A GAS LEAK, DO NOT INSERT THE POWER CORD INTO ITS SLOT. OPEN THE WIN-
DOW TO VENTILATE FULLY AND IMMEDIATELY. It may cause injury or failure. It may cause an injury or a failure.
IF ROTATION OF AUGER IS STOPPED FROM NORMAL OPERATION, PRESS [REV] BUTTON AND HOLD
FOR 2~3 SECONDS AND THEN AFTER REVERSE OPERATION IS COMPLETELY STOPPED, PRESS [ON]
BUTTON AGAIN. If such a stop event continues during the operation, the parts may be damaged and performance
may be deteriorated due to overheating in a motor. When the problem continues, immediately stop the appliance and
contact the local Customer Care Center,.
IF THE INGREDIENTS ARE STUCK IN THE DRUM IN NORMAL OPERATION, PLEASE STOP RUNNING
AND PUSH THEM DOWN WITH THE PUSHER PROVIDED 3~4 TIMES TO AVOID PART BREAKAGE. It may
cause a part damage or slow down the performance of juicing.
DURING THE OPERATION, DO NOT ATTEMPT TO DISASSEMBLE OR ASSEMBLE THE DRUM SET OR
OTHER ATTACHMENTS. It may cause an injury or a failure. Make sure to disassemble or assemble parts under stop
mode after unplugging the power cord. Any act of event needed, switch off the power first and unplug the power cord.
DO NOT WEAR NECKTIES, LONG NECKLACES, SCARVES, ETC WHILE USING YOUR JUICER. They may
get caught in the hopper and cause injury and/or failure.
PLACE THE APPLIANCE ON A FLAT AND STABLE SURFACE TO AVOID PART BREAKAGE OR APPLI-
ANCE DAMAGE. Otherwise, it may cause an injury or a failure.
DO NOT OPERATE THE APPLIANCE FOR MORE THAN 30 MINUTES AT A TIME.
It may cause a motor failure due to overheating. Cool it down sufficiently about 5 minutes and operate it again.
DO NOT USE YOUR FINGER, KNIFE, FORK OR OTHER OBJECT TO PUSH THE INGREDIENTS DOWN.
ONLY USE THE PUSHER PROVIDED. It may cause serious injury for user or damage and a failure to the product.
DO NOT ALLOW A SEVERE SHOCK TO THE APPLIANCE OR DROP IT. It may cause an electric shock, a fire or
damage.
ALWAYS UNPLUG THE APPLIANCE AFTER EACH USE. WHEN UNPLUGGING THE POWER CORD, MAKE
SURE TO HOLD THE POWER PLUG. If holding the wire to unplug, it may cause an electric shock or a fire.
DO NOT WASH AT HIGH TEMPERATURE OF 800C(1760F) OR HIGHER. DO NOT PUT THE APPLIANCE IN
A DISHWASHER, A DRYER OR A MICROWAVE ETC. It may cause damage or a failure of parts.
THE APPLIANCE WEIGHS ABOUT 6kg. WHEN MOVING THE APPLIANCE, MAKE SURE NOT TO DROP
IT. If attempting to hold drum or the edge of the base, the base falls causing an injury, malfunction or a failure.
WHEN THE POWER CORD, WIRE WAS BROKEN OR DAMAGED OR THE PLUG-IN PART BECAME
LOOSE, DO NOT OPERATE IT.
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 3 2015-11-18 오전 9:06:14
04 |
Locking Clip
Operating
Switch
Main Body
Pulp Container
Juice
Container
Pusher
Cleaning
Brush
Terms of parts / Parts for Processor
Adjustable
Pressure Cap
Drum
Cap
Juicing Strainer
Food
Processing
Strainer
Auger
Drum
Hopper
Round
Noodle
Nozzle
Udon
Noodle
Nozzle
Flat
Noodle
Nozzle
Bread
Noodle
Nozzle
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 4 2015-11-18 오전 9:06:15
| 05
Drum
Cap
Adjustable
Pressure
Cap
Juicing
Strainer
Food
Processing
Strainer
Drum CapNozzle
Drum
Drum
Hopper
Hopper
Auger
Auger
For Juicing
For Food Processing
Round
Noodle
Nozzle
Udon
Noodle
Nozzle
Flat
Noodle
Nozzle
Bread
Noodle
Nozzle
Terms of parts / Parts for Food Processing
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 5 2015-11-18 오전 9:06:15
06 |
Use Food processing stem for grinding/noddle making and use Juicing stem for juicing of fruit and vegetable
!
Connect drum with main body by
turning locking clip clockwise
(about 60°).
1
2
How to Assembly
1
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 6 2015-11-18 오전 9:06:16
| 07
Use Food processing stem for grinding/noddle making and use Juicing stem for juicing of fruit and vegetable
2-A
Assemble as 1,
then assemble auger > strainer > drum cap > Adjustable Pressure Cap .
Place the drum cap onto the drum end and turn it
counter-clockwise until it clicks firmly into place.
Attach adjustable pressure cap to the drum cap end.
Turn to “1” or “2” for soft fruits like orange, strawberry etc.
Turn to “5” on the adjustable pressure cap for maximum pressure. This is best for
carrot, beetroot and the leafygreens. <See p19>
For juicing function
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 7 2015-11-18 오전 9:06:16
08 |
Assemble as 1, then assemble auger > food processing strainer > drum cap > nozzle
Place the auger into the drum.
Insert the processing strainer into the drum.
Place the drum cap onto the drum end and turn it counter-clockwise until it clicks firmly into
place. (Change the nozzle depends on the type of noddle.)
When grinding food materials such as grains, do not insert the nozzle.
1) Place juice and pulp container under the drum.
Juice cup does not need for food processor function.
2) Plug the power cord.
For Food Processor Function
2-B
3
Food
Processing
Strainer
Drum Cap
Nozzle
Auger
Pulp container
Juice
Outlet
Juice container
Use Food processing stem for grinding/noddle making and use Juicing stem for juicing of fruit and vegetable
!
How to Assembly
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 8 2015-11-18 오전 9:06:16
| 09
Ingredients and Food Strainer
Fruits like apple, orange, pear, grapes, strawberry, kiwi, etc.
Vegetables like tomato, avocado, aloe, kale, spinach, carrot,
sweet porato, wheatgrass, etc.
Red/green pepper, garlic, ginger, herbs, soaked rice and
beans, etc.
Pasta, Udon, Noodle Breadstick, Ice crean, Nut butter, etc.
Juicing Strainer
Choosing the Right Strainer by ingredients and Food
Food Processing Strainer
Food Processing Strainer
Drum
Hopper
1
2
Use Food processing stem for grinding/noddle making and use Juicing stem for juicing of fruit and vegetable
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 9 2015-11-18 오전 9:06:17
10 |
Making juice of fruit and vegetable
Auger-> Juicing stem->Drum cap-> Adjustable pressure cap
1) When assembling Drum cap, turn Drum cap counter-clockwise direction to tighten up on
right position
2) Assemble Adjustable pressure cap with Drum cap
1
0
1
2
34
5
Only use Juicing stem
!
Only use Juicing stem
!
As for mild and soft fruit like orange
and strawberry, turn Adjustable
pressure cap to "1" or "2" position
As for root type ingredients like
beet and carrot, turn Adjustable
pressure cap to "5" position (Refer
to Page19)
4EB010 사용설명서 Oscar DA-1200 (GG Series185x255)_V.00.indd 10 2015-11-18 오전 9:06:17
