ViewSonic VS13783 Manuale utente
ViewSonic®
Model No. : VS13783
DVP5
Pocket Camcorder
Projector
- User Guide
- Guide de l’utilisateur
- Bedienungsanleitung
- Guía del usuario
- Guida dell’utente
- Guia do usuário
- Kullanιcι kιlavuzu
- Gebruikshandleiding
- Pyководство пользователя
- 使用手冊 (繁體)
- 使用手册 (简体)
- 사용자 안내서
- ユーザーガイド
- ﻢﺪﺨﺘﺴﻤﻠﺍ ﻞﻴﻠﺪ
IMPORTANT: Please read this User Guide to obtain
important information on installing and using your
product in a safe manner, as well as registering your
product for future service. Warranty information
contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also
found on our web site at http://www.viewsonic.com in
English, or in specic languages using the Regional
selection box in the upper right corner of our website.
“Antes de operar su equipo lea cuidadosamente las
instrucciones en este manual”
ViewSonic i DVP5
Compliance Information
FCC Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy, and if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modications not expressly approved by the party
responsible for compliance could void your authority to operate the equipment.
For Canada
• This Class B digital apparatus complies with Canadian ICES-003.
• Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
CE Conformity for European Countries
The device complies with the EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC.
Following information is only for EU-member states:
The mark is in compliance with the Waste Electrical and Electronic Equipment Directive
2002/96/EC (WEEE).
The mark indicates the requirement NOT to dispose the equipment including any spent
or discarded batteries or accumulators as unsorted municipal waste, but use the return
and collection systems available.
If the batteries, accumulators and button cells included with this equipment, display the
chemical symbol Hg, Cd, or Pb, then it means that the battery has a heavy metal content
of more than 0.0005% Mercury or more than, 0.002% Cadmium, or more than 0.004%
Lead.
ViewSonic ii DVP5
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this unit near water.
6. Clean with a soft, dry cloth.
7. Do not block any ventilation openings. Install the unit in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other devices
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade and the third prong are provided for your safety. If the
provided plug does not t into your outlet, consult an electrician for replacement of the obsolete
outlet.
10. P
rotect the power cord from being walked on or pinched particularly at plugs. Convenience
receptacles and the point where they exit from the unit. Be sure that the power outlet is located
near the unit so that it is easily accessible.
11. Only use attachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the unit. When a cart is used, use caution when moving the cart/unit
combination to avoid injury from tipping over.
13. Unplug this unit when unused for long periods of time.
14. Refer all servicing to qualied service personnel. Servicing is required when the unit has been
damaged in any way, such as: if the power-supply cord or plug is damaged, if liquid is spilled
onto or objects fall into the unit, if the unit is exposed to rain or moisture, or if the unit does not
operate normally or has been dropped.
ViewSonic iii DVP5
Declaration of RoHS Compliance
This product has been designed and manufactured in compliance with Directive 2002/95/EC of the
European Parliament and the Council on restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum
concentration values issued by the European Technical Adaptation Committee (TAC) as shown
below:
Substance Proposed Maximum
Concentration Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls
(PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers
(PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex of the RoHS
Directives as noted below:
Examples of exempted components are:
1. Mercury in compact uorescent lamps not exceeding 5 mg per lamp and in other lamps not
specically mentioned in the Annex of RoHS Directive.
2. Lead in glass of cathode ray tubes, electronic components, uorescent tubes, and electronic
ceramic parts (e.g. piezoelectronic devices).
3. Lead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more
lead).
4. Lead as an allotting element in steel containing up to 0.35% lead by weight, aluminium
containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight.
ViewSonic iv DVP5
Copyright Information
Copyright © ViewSonic® Corporation, 2011. All rights reserved.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered trademarks of
ViewSonic Corporation.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions
contained herein; nor for incidental or consequential damages resulting from furnishing this
material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves the right to
change product specications without notice. Information in this document may change without
notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose
without prior written permission from ViewSonic Corporation.
Product Registration
To meet your future needs, and to receive any additional product information as it becomes
available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic®
Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may
mail or fax to ViewSonic.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
DVP5
ViewSonic Pocket Camcorder Projector
VS13783
DVP5_UG_ENG Rev. 1C 12-22-10
_______________________________
_______________________________
Product disposal at end of product life
The lamp in this product contains mercury which can be dangerous to you and the environment.
Please use care and dispose of in accordance with local, state or federal laws.
ViewSonic respects the environment and is committed to working and living green. Thank you for
being part of Smarter, Greener Computing. Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/uk/support/recycling-information/
Taiwan: http://recycle.epa.gov.tw/recycle/index2.aspx
ViewSonic DVP5
Table of Contents
Getting Started .............................................................................1
Product overview ...................................................................................................1
Package Content ...................................................................................................2
Remote Controller..................................................................................................2
Reading LED indicators .........................................................................................3
Charging the battery ..............................................................................................3
Inserting a memory card (optional) ........................................................................4
Turning on/off your projector ..................................................................................4
Setting language ....................................................................................................4
Button Operation....................................................................................................5
Reading LCD indicators .........................................................................................5
Basic Operations .........................................................................6
Recording a video clip ...........................................................................................6
Taking a still picture ...............................................................................................6
Projecting les .......................................................................................................7
Playing les in other devices ...............................................................................11
Advanced Operations ...............................................................13
Menu Setting items ..............................................................................................13
File management with a PC.................................................................................14
Flicker Setting Table ............................................................................................16
Battery Life Indicator ............................................................................................16
AV-IN recording (optional) ................................................................................17
USB Projection (optional) ................................................................................18
Specications ............................................................................23
Troubleshooting ........................................................................25
ViewSonic 1 DVP5
Getting Started
Product overview
Focus switch
Micro SD card slot
IR receiver
Power Switch
Tripod socket
Projection
Lens
HDMI out
Power/Charging LED
AV input / Headphone output
Down button
(Zoom out)
Left button
(Folder)
Right button (LED light)
Menu button
Up button (Zoom in)
Return Button
OK button
Shutter button Record button
Projection button
Camcorder
Lens
DC In/USB connector
LED Light
Speaker
Mic
ViewSonic 2 DVP5
Package Content
Remote Controller
Projection on/off
Record button
Volume control buttons
Return button
Right button
Shutter button
OK/Play/Pause button
Left button
Up button
Down button
Menu button
Projector Quick Guide CD AC power adapter
USB cable AV cable (RCA
female to mini jack)
AV cable (mini jack
to mini jack)
Remote Controller
ViewSonic 3 DVP5
1 Connect one end of the supplied AC adapter to the USB
port of the projector and the other end to a wall outlet.
OR
Connect one end of the supplied USB cable to the USB
port of the projector and the other end to a powered PC.
Make sure the projector is powered off.
2 The charging LED turns orange and the charging starts.
3 When interrupted the LED went off.
Charging status Charging time
Powered OFF, charged by AC adapter around 4 hours
Powered OFF, charged by USB around 7 hours
Powered ON and connecting with AC adapter no charging
Powered ON and connecting with USB no charging
Reading LED indicators
The Power LED is lighting orange when projector is charged.
The Power LED is lighting green when connected with AC power adapter in standby
mode or the battery is fully charged.
Charging the battery
ViewSonic 4 DVP5
Slide the Power switch to “ON” position to turn on the projector.
To turn off the projector, slide the Power switch to “OFF” position.
Inserting a memory card (optional)
1 Open the Micro SD card cover.
2 Gently push the card as indicated (golden-ngers facing
upwards) until the card reaches the end of the slot.
3 When the card is inserted successfully, the icon ( ) will
appear on screen. To remove the card, push the card to
release it and then pull it out gently.
4 Put the cover back.
Turning on/off your projector
1 Power on the projector.
2 Press the MENU button to enter the Setting screen.
3 Use the Up/Down button to select the Language item, and then Press the OK
button to conrm.
4 Use the Up/Down button to select a language.
5 When done, press the OK button to conrm the setting.
Setting language
Altri manuali per VS13783
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali ViewSonic Videocamera
ViewSonic
ViewSonic DVP5 Manuale utente
ViewSonic
ViewSonic VS13782 Manuale utente
ViewSonic
ViewSonic VS13783 Manuale utente
ViewSonic
ViewSonic 3DV5 Manuale utente
ViewSonic
ViewSonic VC415 Manuale utente
ViewSonic
ViewSonic VC320 Manuale utente
ViewSonic
ViewSonic VC3D2 Manuale utente
ViewSonic
ViewSonic 3DV5 Manuale utente
ViewSonic
ViewSonic VC310 Manuale utente
