NMP-700

NETWORK MEDIA PLAYER

ViewSonic’s NMP-700 X86-based Network Media Player features

an Intel Mobile Core 2 Duo processor, 2GB of memory, and

an Intel X4500MHD graphics card for power digital signage

messaging. Connect to any display having VGA and HDMI inputs.

This cost-effective solution integrates into your existing network

and supports a wide variety of digital display components and

applications. With a 160GB hard drive and hardware video

decode, local playback of high-denition video les are not

an issue. It is powerful enough to deliver smooth playback

of graphics and video content up to 1080p Full HD, yet small

enough to install anywhere.

X-86 Based Network

Media Player

Intel Core 2 Duo T6400 Processor and Intel X4500MHD Graphics Card

X86 design based on the latest Intel technology

Versatile output formats: Dual VGA and HDMI

Embedded Microsoft Windows XP OS

Industrial grade media player

Reliable watchdog timer

For more product information, visit us on the web at ViewSonic.com

Sales: (888) 881-8781 • [email protected] • ViewSonic.com

Specications subject to change without notice. Selection, offers and programs may vary by country; see your

ViewSonic representative for complete details. Corporate names, trademarks stated herein are the property of their

NMP-700 NETWORK MEDIA PLAYER

PRODUCT TYPE X86-based network media player

CPU Intel Core 2 Duo Mobile T6400 2.0GHz 2MB L2 Cache 800MHz FSB

CORE LOGIC Intel GM45 Express Chipset

GRAPHICS Intel X4500MHD

OPERATING SYSTEM Windows embedded standard

MEMORY (RAM) 2GB DDR-2 SO-DIMM format

BIOS AMI

STORAGE 160GB

NETWORK Gigabit (10/100/1000 Mbits/sec) LAN

REAR PANEL INPUT/OUTPUT USB port (x2), DC jack (20VDC), VGA port (x2), HDMI port,

RJ45 LAN, RS-232 port, audio out, mic in, Kensington®lock

FRONT PANEL INPUT/OUTPUT Power button, HDD LED, power indicator, USB port (x2)

EXPANSION Mini card slot

PRE-INSTALLED SOFTWARE APPLICATIONS Optional

WATCH DOG TIMER 1~255 sec

SUPPORTING PROTOCOLS TCP/IP, HTTP

DISPLAY VGA (x2), HDMI

AUDIO RCA stereo analog

DECODING Video MPEG-1, 2, 4, Macromedia®Flash

Audio Realteck HD Audio Codec

OPERATING CONDITIONS Temperature 32º–122ºF (0º–50ºC)

Humidity 95% (non-condensing)

DIMENSIONS (W x H x D) Physical 6.5" x 1.9" x 6.2" (166mm x 48mm x 157mm)

WEIGHT Net 2.7 lb. (1.2 kg)

Gross 5.2 lb. (2.4 kg)

REGULATIONS UL/cUL, FCC-15B, CE, CB, RoHS

PACKAGE CONTENTS Network media player, AC adapter, mounting bracket,

Quick Start Guide, Driver CD

WARRANTY One-year limited warranty on parts and labor.

ViewSonic®recommends our

commercial displays, open frame

display or any ViewSonic large screen LCD or LCD TV

and digital signage software for use with the NMP-700

to give you the best possible digital signage results.

ViewSonic Corporation’s QMS & EMS have been registered

to ISO 9001 & ISO 14001, respectively, by TUV NORD.
