Viking Designer DFB450 Manuale utente

Viking Range Corporation

111 Front Street

Greenwood, Mississippi 38930 USA

(662) 455 1200

For product information,

call 1 888 VIKING1 (845 4641)

or visit the Viking Web site at

vikingrange.com

F20622A EN (061110)

Professional & Designer Series

Dishwasher Door Panel

Viking Door Panel Installation

3

Door Panel Installation (Professional/Designer)

2

Installation

(Purchased Separately)

D

D

D

C

C

Plastic

Retainers

Dishwasher Door

Door Skin

D

1

step

CC

C

C

Dishwasher Door

Plastic

Retainers

Door Skin

2a

step

DD

D

D

D

Torx Driver

#8 1 3/4” long,

flat head,

Stainless Steel

Torx Screw

(4 supplied)

WARNING

The door skin must not obstruct the fan

exhaust vent.

Position door skin on front of dishwasher

door. Snap the plastic retainers on the door

skin into the holes (C) on dishwasher door.

While holding the door skin in position,

carefully open the dishwasher door Using

either the 4 flat head or 4 truss head screws

provided*, secure the door skin to the 4

holes (D) on the dishwasher door

2b

step

D

D

D

D

Carefully tighten all 4 screws and check to

ensure that the panel is square with the

dishwasher door Note: Verify the operation

of the door counterbalance springs after

installation of the door skin.

The unit comes with everything needed to make installing the door panel easy

What you will need:

OR

#8 1 3/4” long,

Stainless Steel

Truss Head Screw

(4 supplied)

*Note: Use the set of screws which matches

the screws already installed on the door
