Viking Professional VDB325 Manuale utente

KITCHEN CLEANUP

Built-In 24”W. Dishwasher 325

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

All models include:

•Exclusive Vari-Pressure Intelli-Wash™

System

oExclusive variable spee 1/2

horsepower commercial-type motor

oExclusive multi-level washing with

two stainless steel wash arms

oExclusive Block-proof Flexible-

Flui ™ coupling irect water fee

•Exclusive Central Intelligence™

System

o Constant communication

o Measures water temperature an

water volume

•Exclusive Four-Stage Filtration an

Waste Removal System

o Removable coarse strainer

oExclusive Triple-Clean™filtration

with self-cleaning jets

•Exclusive Sure-Temp™ Water Heating

o 1400 watt Hy roFlo™ water heater

o Operable with “col ” groun water

• Con ensate Quick Dry

• Quiet Clean™ Performance Package

o Separate motor/pump assemblies

for washing an raining

o Multi-stage soun absorbing/heat

retaining insulation

o Blue LED power-on light in kickplate

in icates cycle is operating

• “Loa -As-You-Like” Stur i-Bilt™ Racks

o Accommo ates 15 international

place settings

o Fully exten able nylon coate racks

o One-Piece silverware/cutlery basket

o Lower rack has 4 rows of 3 position

one-piece fol - own tines

o Roller Bearing™upper rack has 3

rows of multi-position Hol Tight™

ivi ers an 1 one-piece cup shelf

•Exclusive Diamon -Brite™ stainless

steel tank an inner oor

• Cycles – Pots/Pans, Normal Wash,

Econo Wash, Light/China, Rinse/Hol

• Options – 155°F Final Rinse, Delay

Start (up to 6 hours)

Standard Features & Accessories

Model Options

R E V I S E D 7 / 1 4 / 1 0

Finish etails for VDB mo el

• Stainless Steel (SS), Black (BK), White

(WH)

Finish etails for DDB mo el

• Stainless Steel (SS), Black (BK), White

(WH)

VDB325

P ofessional

Built-In Dishwashe

DDB325

Designe

Built-In Dishwashe

KITCHEN CLEANUP

Built-In 24”W. Dishwasher 325

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

All models

Overall width 23-7/8” (60.6 cm)

Overall height (from floor) 33-7/8” (86.0 cm) min. to 35” (89.0 cm) max.

Overall depth (from rear)

To edge of side (includes door panel) 24” (61.0 cm)—includes door panel

With door open 49” (124.5 cm)

Dimensions & Speci ications

PRODUCT DIMENSIONS

R E V I S E D 7 / 1 4 / 1 0

VDB325

P ofessional

Built-In Dishwashe

DDB325

Designe

Built-In Dishwashe

23-7/8”

(60.6cm)

33-7/8”

(86.0cm)

min.

35”

(89.0cm)

max.

24”

(61.0cm)

PROFESSIONAL DESIGNER

23-7/8”

(60.6cm)

33-7/8”

(86.0cm)

min.

35”

(89.0cm)

max.

24”

(61.0cm)

KITCHEN CLEANUP

Built-In 24”W. Dishwasher 325

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 7 / 1 4 / 1 0

VDB325

P ofessional

Built-In Dishwashe

DDB325

Designe

Built-In Dishwashe

23-3/4”

(60.3 cm)

Cabinet flush

28-3/4”

(73.0 cm)

49”

(124.5 cm)

23-1/8”

(59.0 cm)

Panel flush

DESIGNER

PROFESSIONAL

Note: If the dish asher is installed in a corner, there must be a minimum clearance of 2” (5.1 cm) from the side all so the door can

open.

23-3/4”

(60.3 cm)

Cabinet flush

28-3/4”

(73.0 cm)

49”

(124.5 cm)

23-1/8”

(59.0 cm)

Panel flush

Dimensions & Speci ications

DOOR SWING

A 2” cut-out is required

for water supply and

discharge lines.

24”

(61.0cm)

24”

(61.0cm)

34”min.

(86.4cm)

35”max.

(89.0cm)

KITCHEN CLEANUP

Built-In 24”W. Dishwasher 325

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

UTILITY

REQUIREMENTS

GAS

Not applicable

ELECTRICAL

•3’9” (1.1 m),

electrical cor with 90

egree 3-prong plug

•120V/60 Hz

• Maximum amp

usage—15.0 amps

•Water-heating

element rating—

1,400 watts

PLUMBING

• 120°F (49°C) hot

water recommen e ;

ishwasher will,

however, perform

properly with col

water*

• Inlet water pressure

operating range—

10 – 125 psi (0.69 –

8.62 bar)

• Five foot (1.5 m)

brai e stainless steel

water line with 3/8”

(0.95 cm)

compression fitting

supplie with

ishwasher

• Seven-foot (2.13 m)

1/2” (1.3 cm) ID

“crimp-proof”

flexible rain hose

with clamp attache

to ishwasher;

connections provi e

for 5/8” (1.5 cm), 3/4”

(1.9 cm), or 1” (2.5

cm) cut as require

• High loop of rain

hose require ; min.

height from floor—

20” (50.8 cm)

• Check local co es

for rain air gap

requirement

*Cycle times will be

exten e

Installation Requirements

ACCESS REQUIREMENTS

All models

Cutout width 24” (61.0 cm)

Cutout height 34” (86.4 cm) min. to 35” (89.0 cm) max.

Cutout depth 24” (61.0 cm)

R E V I S E D 7 / 1 4 / 1 0

VDB325

P ofessional

Built-In Dishwashe

DDB325

Designe

Built-In Dishwashe

Compliance In ormation

WARRANTY INFORMATION*

• One-year full warranty—all components

• Lifetime limite warranty—stainless steel tanks, inner oor liner

• Five-year limite warranty—electronic control, racks, motor/pump assemblies, an water istribution system

• Ninety- ay limite warranty—cosmetic parts (painte an ecorative items)

*For complete warranty information info see Use & Care Guide. Warranty vali on Viking pro ucts shippe within the Unite States an Cana a.

KITCHEN CLEANUP

Built-In 24”W. Dishwasher 325

PLANNING AND DESIGN GUIDE

VIKINGRANGE.COM • 1-888-VIKING1

R E V I S E D 7 / 1 4 / 1 0
