FINISH DETAILS FOR BOTH MODELS
• Stainless Steel (SS)
R E V I S E D 9 / 1 6 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
Both ovens include
• Capacity—1.1 cu. ft. (31.2 lit.)
o 29-15/16”W. x 15-1/2”H. x
15-5/16”D.
o 13” (33.0 cm) diameter turntable
• Commercial-type styling and design
• Instant sensor settings for cooking,
reheating, and popcorn
• Four convection settings use high-
speed fan that circulates air past the
heat source and around the food;
allows multiple-rack baking
o ConvecBroil
o ConvecRoast
o ConvecBake
o Manual convection
• Low Mix Bake and High Mix Roast set-
tings offer use of convection heat to
seal and brown outside of foods while
using microwave energy to ensure the
interior is cooked
• Add-A-Minute allows you to add a
minute of extra cooking time with the
touch of one button
• Child Lock safety feature locks the
control panel to prevent unwanted
operation
• Interior light
• Cookbook included
• Built-in exhaust system
o 300 CFM blower
o Shipped assembled to recirculate;
may also be converted to vent out
the rear or vertically
• Suitable for use over 24”W. and 30”W.
Viking surface cooking products (non-
grill)
Standard Features & Accessories
Model Options
COOKING
Professional & Designer Convection
Microwave Hood
ORDERING INSTRUCTIONS
First specify model number, and then color code (VMOR205SS).
DMOR205
Designe
Mic owave Hood
VMOR205
P ofessional
Mic owave Hood
COOKING
Professional & Designer Convection
Microwave Hood
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 9 / 1 6 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Please see
Installation Notes
and Accesso ies for
important information,
including filters.
All Models
Overall width 29-1 /16” (6 .9 cm)
Overall height (from bottom) 1 -1/2” (39.4 cm)
Overall depth (from rear) 1 - /16” (38.9 cm)
Approx. ship weight 8 lbs. (38.6 kg)
Dimensions & Specifications
PRODUCT DIMENSIONS
15-5/16”
(38.9cm)
29-15/16”
(65.9 cm)
15-1/2”
(39.4cm)
15-5/16”
(38.9 cm)
29-15/16”
(65.9 cm)
15-1/2”
(39.4cm)
VMOR205
P ofessional
Mic owave Hood
DMOR205
Designe
Mic owave Hood
PROFESSIONAL DESIGNER
R E V I S E D 9 / 1 6 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
COOKING
Professional & Designer Convection
Microwave Hood
VMOR205
P ofessional
Mic owave Hood
DMOR205
Designe
Mic owave Hood
30”
(76.2 cm)
2”
(5.1 cm) min.
36” min.
(91.4 cm) or more
from cooking
surface
15.5”
(39.4 cm)
12”
(30.5 cm)
12”
(30.5 cm)
72”
(182.9 cm) min.
72”
(182.9 cm) min.
Dimensions & Specifications
CLEARANCE DIMENSIONS
DMOR205
Designe
Mic owave Hood
VMOR205
P ofessional
Mic owave Hood
COOKING
Professional & Designer Convection
Microwave Hood
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 9 / 1 6 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
30”
(76.2 cm)
Ground
receptacle
Opening for
power cord
15-1/2”
(39.4 cm)
12”
(30.5 cm)
12”
(30.5 cm)
All models
Cutout width 30” (76.2 cm) min.
Cutout height 1 -1/2” (39.4 cm) min.
Cutout depth 12” (30. cm) min.
UTILITY
REQUIREMENTS
GAS
•Not applicable
ELECTRICAL
•3.5-foot power cord
included
• 120 VAC/60 Hz
•Maximum amp
usage—
13.2 (1.6 kW)
PLUMBING
Not applicable
Installation Requirements
ACCESS REQUIREMENTS
COOKING
Professional & Designer Convection
Microwave Hood
PLANNING AND DESIGN GUIDE
V I K I N G R A N G E . C O M • 1 - - V I K I N G 1
R E V I S E D 9 / 1 6 / 1 0
© 2 0 1 0 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
Replacement Air Filter
• Recommended replacement every 6 – 12 months
Compliance Information
WARRANTY INFORMATION*
• One-year full warranty—complete product
• Five-year limited warranty—magnetron tube
• Ninety-day limited warranty—cosmetic parts such as glass, painted, and decorative items
*For complete warranty see Use & Care Guide. Warranty valid on Viking products shipped within the United States and Canada.
Installation Notes & Accessories
Model Description Approx. ship wt. lbs. (kg)
CFOR1 Air filter for 30”W. microwave hood lbs (.91)
