Vinpower VENSOLPTR Manuale utente

Model Number VENSOLPTR VENSOL‐100

Disc Capacity 1 disc 100 discs

Print Method Solvent Inkjet

Printing Technology Ultra Hi-Definition printing

Advanced MicroPiezo®

6 color printing technology

Ink Palette Black, Cyan, Light Cyan, Magenta, Light Magenta, and Yellow

Ink Configuration Continuous Ink System (CIS) with 100ml tanks

Waste Ink tank included

Ink Type Eco Solvent

Maximum Resolution (dots per inch) 5760 x 1440 optimized dpi

Color Management ICC Profiles

Media Type (Disc Loader Mode) N/A Standard 120mm Blu-rays, CDs and DVDs

Media Type (Manual Mode) Paper, Bond, Vinyl

Standard 120mm Blu-rays, CDs and DVDs

Mini discs (optional)

ID Cards (optional)

Minimum System Requirements for PC CPU: Pentium 4, 2.4GHz

RAM: 512MB

3 x Hi-Speed USB 2.0

Operating Systems Windows 7, Windows Vista, Windows XP

Software Included Printer driver

Disc Design Software

Ink Density Changer Software

Pandora Auto-Printer Software

Warranty 6 months parts & labor against manufacturer defect, excluding the Print Heads. 3 months on the Print Heads.

Warranty excludes physical damage or defect due to neglect or deliberate damage caused by the user.

Power Requirements Rated voltage: 120 VAC

Rated frequency: 50 - 60 Hz

Rated current: 0.6 Amp

220~240V (upon request)

Weight and Dimensions (W x D x H) Dimension: 20 x 11 x 7.5 inches

Weight: 16 lb

Dimension: 21 x 23.25 x 8.25 inches

(19.50” H with input rods and output bin installed)

Weight: 25 lb

Temperature Operating: 50 ° to 95 °F (10 ° to 35 °C)

Storage: -4 ° to 140 °F (-20 ° to 60 °C)

Relative Humidity Operating: 20 - 80%

Storage: 5 - 85%"

Safety Approvals Safety standards UL60950-1, CSA C22.2 No. 60950-1

EMI FCC Part 15 subpart B class B

CAN/CSA-CEI/IEC CISPR 22 class B

Website: www.vinpowerdigital.com Tel: +1.626.282.3300 Fax: +1.626.282.6690 Address: 817 SouthAvenueAlhambra, CA 91803 U.S.A. Email: [email protected]
