Visonic NC543W Manuale utente
Image Sensor
Image sensor: Color CMOS sensor
Minimum illumination: 0.5 lux
Night Vision Distance up to 20m
Lens
Lens type: Board lens
Aperture (F/No): 2.0
Focus length: 6.0 mm
View angle: 60°
Image Processing
Compression: MJPEG
Auto exposure control: Yes
Auto white balance: Yes
Auto gain control: Yes
Image resolution and
frame rate:
VGA (640 x 480): 30 fps
QVGA (320 x 240): 30 fps
QQVGA (160 x 120): 30fps
System
Power: DC12V
Power consumption: 9 watts maximum
Environment: Operating temperature: -14°F to 122°F
Communication
Ethernet: One RJ45 port; IEEE 802.3u compliant 10/100 Mbps fast Ethernet with Auto-MDIX
Antenna: External dipole antenna
Wireless security: WPA (TKIP/AES), WEP (64bit or 128bit), WPA2 (TKIP/AES)
Wireless: IEEE802.11b/802.11g wireless LAN
Other
Reset functions:
* System reboot
* Reset full conguration to factory default values
Reset button: Push and hold for more than 10 seconds: returns to factory default values
Audio: Two-way Audio
Web browser: * Supports Firefox, Safari, Opera, etc.
Advanced Outdoor Camera for use with PowerLink
NC543W
Outdoor Waterproof IP camera with IR Illumination
Cam3200
Wireless Pan/Tilt Network Camera
Cam3100
Wireless Network Camera
Image Sensor
Image sensor 1/4'' color CMOS sensor
Minimum illumination 0.5 lux
Lens
Lens type Board lens
Aperture (F/No.) 1.8 2.6
Focus length 4.0 mm 4.6 mm
View angle 64° 60°
Image Processing
Compression MJPEG
Auto exposure control Yes
Auto white balance Yes
Auto gain control Yes
Image resolution and frame
rate VGA (640 x 480): 30 fps, QVGA (320 x 240): 30 fps QQVGA (160 x 120): 30fps
System
Power DC12V DC5V
Power consumption 9 watts maximum 6 watts maximum
Environment Operation: Temp. 0°C - 45°C Humidity: 20% ~ 85% non-condensing
Storage: Temp. -15°C - 60°C Humidity: 0% ~ 90% non-condensing
Approvals FCC/CE class B
Communication
Ethernet One RJ45 port; IEEE 802.3u compliant 10/100 Mbps fast Ethernet with Auto-MDIX
Antenna External dipole antenna
Wireless security WPA (TKIP)
Wireless IEEE802.11b/802.11g wireless LAN
Pan-Tilt
Pan range +165° to -165° --
Tilt range +90° to -15° --
LEDs
Power LED Orange
Link/Activity LED Green
Reset button -- Push and hold for more than 5 seconds:
returns to factory default values
Other
Night vision IR LED with light sensor control
Reset functions * System reboot
* Reset full conguration to factory default values
and PowerMax are registered trademarks of Visonic Ltd. Other names are the property
of their owners. Visonic reserves the right to change information or specications without notice.
