Quick Start Guide

DIGITAL CAMERA

VQ7024

User's Manual

- 1-

110707

Name of Parts

The following illustrations show component list, button, and switches on the camera.

1. Shutter Button (OK)

2. Power Button

3. Self Timer Lamp

4. Flash

5. TV out

6. Lens

7. Focus Switch

8. USB Port Terminal

9. Power Lamp

10. Strap Eyelet

11. Charge Indicator

12. Joystick/OK Button

/ : Flash

/ : Display

/ : Zoom In

/ : Zoom Out

13. MENU Button

14. Battery Compartment Cover &

SD Card Socket

15. Mode/Delete Button

16. Function Switch

17. Buzzer

18. TFT Panel

19. Tripod Socket

- 2-

Indicators

1.Indicator Lamp (Green)

2.Self-Timer Lamp (Red)

3.Power Lamp

Digital Interface:

USB 1.1

Video Output:

TV out in NTSC / PAL

DIGITAL ZOOM

During shooting, user can push the joystick up or down to zoom in and zoom out.

Display Button

Push the joystick right and the current information will be showed on the TFT panel will be

displayed.

Menu Button

You can turn the menu ON or OFF by pressing the Menu button. As menu turn on, the items

appear, push the joystick up or down to select the item and then push the joystick left or right

to enter each menu item.

- 3-

Display Information

Note:

If the icon appears on the TFT panel when you take pictures in low light condition. Please

keep your hands steady, otherwise you may capture a blur picture.

- 4-

- 5-

• Getting Ready

1.Slide open battery compartment cover

2.Load batteries into the camera.

3.Slide and close the battery compartment cover.

• Taking a Picture

1.Turn on the camera.

2.Slide Function switch to (capture status).

3.Point the camera to the object, use LCD screen to form the picture.

4.Hold the camera still, gently press the shutter button to take a picture.

• Reviewing a Picture

1.Turn on the camera.

2.Slide Function switch to (playback status).

3.Push the joystick Left or Right to scroll through the pictures

or videos on the monitor screen.

• Deleting a Picture

1.Turn on the camera.

2.Slide Function switch to (playback status).

3.Push the joystick Left or right to display the picture you want to delete.

4.Press Mode button to turn on the menu and then push the joystick up or down

to select [Delete] on the screen. Press OK button.

5.When the message “Delete this file?” shows on the screen, press OK button to delete the file;

press Menu button not to delete this file; press Mode button to exit the menu.

- 6-

• Downloading Images to Your Computer

For Windows 98/ME customers:

Please install camera drive before connecting.

1.Slide Function switch to (Playback Function).

2. Then connect the camera to the computer with USB cable.

3. “USB Mass Storage drive” shows on the computer screen.

For Windows XP:

A dialogue box with options appears as shown on the Right side.

The options are Play, Find/Fix/Share Images.

Open folders to view files, take no action,

Copy images to a folder on my computer,

View a slide show of images, and etc.

Please select one of them and click on “OK”.

For Windows 2000/ME/98:

Double click on “My computer”, and then double click on Removable Disk (i:)

in the DCIM files. (All the photos and videos are stored here).

4. Press “Ctrl+A” on the keyboard to choose all the photos/videos, then press “Ctrl+C” to copy

photos, and then open a file in the computer, press “Ctrl+V” to paste the photos.

- 7-

The VistaQuest Corporation is proud that you have chosen its

product and hopes you will enjoy sharing “a clearer vision” of your memories and special

moments captured with your new camera with friends and family for many years.
