Thereare2styrofoamboxeswithinthecartonbox.
a) Thefirstboxcontains6objectives(3pcsplanobjectives10X,25X&40Xwithsingle
coloredringand3pcsplanphasecontrast10X,25X&40Xwithdoublecoloredringsand
marked PHP2”),1trinocular,2eyepieces,1centeringtelescope,3filters,1sparefuse
and1 sparelamp.
b) TheSecondboxcontains1bodyframe,1phasecontrastcondenser,3differentsize stage
bracketsholders.
Installationsteps
Thenumberinthefollowing installationstepsisshownintheinstalling diagram,suchas 1”is
Body”inFig.2
(1)Unpackthisunit,takeoutthebodyframe1 and place itonastableworkbench,andremovethe
supportingpackageandthedustcap(bag).
(2)Takeoutthephasecontrastcondenser4.Loosenthescrew onthecondenserholder3 and
theninstallthecondenserintotheholder,tightenthescrewagain.AsshowninFig. 3.
(3)Takeoutthestagebracket2 (whenthestagebracketisusedtocarryaspecimenorobservetissue
intheculturedish),putthedesiredspecificationstagebracketflatlyinthestagemoving device
rack ②.AsshowninFig. 3.
(4)Removethedustcapofeyepiece tube,inserttheeyepiece 5 intotheeyepiecetube,andturnthe
eyepiecessothatitfitstheeyepiece tubewell.
(5)Thereare6objectives.Thosewithsinglecoloredringareplanobjectivesandwithdouble
coloredringsarephasecontrastobjectiveswhicharealsomarked PHP2”.Installthemontothe
nosepiece.Usercanonlymount5objectivesontothenosepiece atanyonetime.Installthem
clockwiseintheascending orderofmagnificationAsshowninFig.4.
(6)Connectthepowercordtothepowersupplysocketofthebody.
(7)Checkiftheaboveinstallationissecureandsafe.
(8)Inspectandgathertheaccessoriesandtoolsenclosedinthepackageandkeeptheminasafe
place toavoidmisplacement.
Fig.3
