Vitamix Creations II Manuale utente

Owner’s Manual

Read and save these instructions

Vita-Mix®Corporation

8615 Usher Road

Cleveland, OH 44138-2103 U.S.A.

1-800-848-2649 / 1-440-235-4840

www.vitamix.com

CREATIONS® II

2-Part Lid: Your new machine has our latest

lid design. It is easy to put on and take o, and

easy to clean. Always use the lid and the lid

plug when the machine is in operation.

CAUTION: Lids and tampers are not

interchangeable between dierent container

styles, types, and sizes.

Snap the lid onto the container and leave in

place for a few minutes. Once the lid has been

left on the container, it will be much easier to

lock or remove.

Lid Plug: Insert through the lid and secure by

turning clockwise. Remove the lid plug to use

the tamper or add ingredients.

To Lock the Lid in Place:

1. Position lid on container with lid ﬂaps

midway between the spout and the

handle.

2. Push the lid onto the container until it

locks in place.

3. The lid must always be secured when

processing, especially hot liquids that

may scald.

PARTS & FEATURES

Lid Plug

2-Part Lid

Lid Flaps

Container

Blade

Assembly

Retainer Nut

Centering Pad

Drive Socket

Control Panel

Motor Base

Feet

Tamper

Variable

Speed Dial

WARNING

Rotating Blades Can

Cause Severe Injury.

DO NOT reach into container

while machine is running.

To Remove the Lid: Lift up on one lid ﬂap while holding the container securely.

To Remove the Lid Plug: Rotate the lid plug counterclockwise from the “locked” to “unlocked”

position and lift out.

Container: Ounces, cups, and milliliters are clearly marked. A second dry blade container is available

for purchase to grind grain and knead bread dough. The blade is marked “D.” Grinding grains will

cloud the lower three inches (8 cm) of the container.

Tamper: The tamper allows you to accelerate

the process of very thick and/or frozen mixtures

that cannot be processed in a regular blender. Using the tamper maintains circulation by preventing

air pockets from forming. While the machine is running, and only through the lid plug opening, use the

tamper to press ingredients into the blades as you make frozen ice creams and nut butters, or purée

fruits and vegetables. Refer to “How to Use the Tamper” on page 10.

Automatic Overload Protection: Your Vitamix motor is

designed to protect itself from overheating. If the motor shuts

off, follow these instructions:

• 120 Volt machines: Turn off the power switch for up

to 45 minutes to reset. Reset time will be extended if

high room temperatures exist. To reduce the reset time,

unplug the machine, remove the container, and blow air

into the center section of the bottom with a hair dryer on

the cool setting.

• 220 Volt machines: 220/240 motors are equipped with a

reset button. If the motor shuts off, press the black reset

button on the bottom of the machine.

Power Cord: Your machine is equipped with a long power

cord. Store the unused portion neatly underneath.

Bottom View / Cord Wrap: Plastic cord retainers hold the

cord securely. There is no need to unscrew the cord retainers

to let out more cord. They are flexible, and return to position

after the cord is lifted out.

PARTS AND FEATURES

Front

Back

Reset Button: On 220/240 volt machines only.

WARNING

Rotating Blades Can

Cause Severe Injury.

DO NOT reach into container

while machine is running.

Wet Blade Container: Designed for processing liquids, including juice, frozen mixtures,

sauces, soups, purees, batters, and for wet chopping. The wet blades can also grind grain

and knead dough, but they are not quite as efficient as the dry blades in this application.

If used for grinding, your container will mar and become cloudy; see instructions for dry

container use.

Dry Blade Container: These blades are clearly marked “D” and are designed specifically

for grinding dry materials such as grains, cereal, and coffee, and are also used for

kneading bread dough. The dry blades can NOT process liquids efficiently. If you grind

herbs on a regular basis, you may wish to purchase a separate dry blade container and

replace blades as needed.

ABOUT THE BLADES

The Vitamix machine comes standard with the wet blade container. The blade is identified by a “W” for

wet. This blade is used for most of your recipes. Additional containers with wet or dry blades may be

purchased separately.

CAUTION

Moving Parts

May Become

Hot With

Extended

Use.

DO NOT touch.

WARNING

HOW TO USE THE TAMPER

Rotating Blades Can

Cause Severe Injury.

• DO NOT put hands, spatulas, etc. in

the container while the machine is

running or while the container is still

on the base.

• Lids and tampers are not

interchangeable between dierent

container styles, types, and sizes.

Use the tamper that was supplied

with your machine.

Tamper Splash Disk

Tamper

Blade Assembly

Lid

IMPORTANT:

• The splash disk (near the top of the tamper) and lid

prevent the tamper from hitting the blades when the lid

is secured properly in the locked position.

• The container should not be more than two-thirds full

when the tamper is used during blending.

• To avoid overheating during blending, DO NOT use the

tamper for more than 30 consecutive seconds.

• If the food does not circulate, the machine may have

trapped an air bubble. Carefully remove the lid plug

while making sure the lid stays firmly in place. Release

the air bubble by inserting the tamper through the lid

plug opening.

• Holding the tamper straight down may not help the

ingredients circulate. If necessary, point the tamper

toward the sides or corners of the container. DO NOT try

to force the tamper deeper into the container.

CONTROL PANEL

1. On/Off Switch: Push up to turn On (|). Push down to turn Off (O).

2. High/Variable Switch: High ( ) is the fastest speed available. Switch to Variable ( ) to activate

all of the lower variable speeds.

Always make sure that the High/Variable Switch is set to Variable ( ) before pushing the On/Off

Switch to the On (|)position. Do not start your machine on High ( ) speed.

3. Variable Speed Dial: Selects many speed settings. It is active only when the High/Variable Switch

is set in the Variable ( ) position.

HINTS FOR SETTING SPEEDS

Never Start on Speeds Above 1 with Hot

Liquids to Avoid Possible Burns.

Use Caution; escaping steam or splashes

may scald.

Lock the lid. This will prevent expansion

from aecting the position of the lid

when the machine is turned on.

Start on Variable 1, slowly increase to 10.

CAUTION

Hints for Setting Speeds

Always start the machine with the left switch down in the Variable ( ) position and with the center Variable

Speed Dial on 1. Slowly turn the Variable Speed Dial to the desired speed depending on the recipe used. If a

recipe calls for processing on High ( ), slowly rotate the Variable Speed Dial to 10 and then push the

High/Variable Switch up into the High ( ) position. Do not begin processing on Variable 10 or directly on

the High ( ) setting.

Process on the High () setting for as much of the processing time as possible to make whole food juices,

soups, shakes, frozen mixtures, purées, nut butters and for grinding grains. Processing times will generally

be less than one minute (most take less than 30 seconds). High ( ) speed provides the best quality of

refinement, breaking down ice, frozen fruit, whole fruits or vegetables, and grains to a smooth lump-free

consistency.

TIP: Blending too long at too low a speed setting will overheat the machine and cause the Automatic

Overload Protection to turn the machine off. Use the High ( ) speed as often as possible to achieve the

most uniform consistency. Blending on High ( ) speed also maximizes the motor’s cooling fan to avoid

overheating.

When on the High ( ), if the food does not circulate, the machine may be overloaded or may have trapped

an air bubble. Carefully remove the lid plug while making sure the lid stays firmly in place. Release the air

bubble by inserting the tamper through the lid plug opening. If circulation problems continue, reduce the

machine speed. A lower speed may allow food to circulate when a higher speed does not. Once the food is

circulating freely, increase the speed back to High ( ) and continue processing.

OPERATING INSTRUCTIONS

Wet Blade Container

Designed for processing liquids including juice, frozen mixtures, sauces, soups, purees, batters, and for

wet chopping.

Make sure that the Variable Speed Dial is set to 1

Load the container before placing it on the motor base. Place liquids and soft foods in the container

ﬁrst, solid items and ice last. Although not necessary for blending, you may want to cut or break food

into smaller pieces for more precise measuring of ingredient

Securely fasten the 2-part lid. Always use the complete 2-part lid when blending (unless the tamper is

inserted through the lid plug opening). Especially when blending hot ingredients, make sure the lid is

securely latched.

With the motor o, set the wet blade container on the motor base by aligning it over the centering pad.

Do not ever attempt to put a container on an operating motor base or to operate a motor base without a

container properly in place

Start with the High/Variable Switch in the Variable ( ) position. Always start your machine on

Variable speed 1. Activate the machine by turning the On/O Switch to On (|) then slowly increase to the

desired speed. Your container will shift and get into an aligned position.

Take proper care when handling and processing hot ingredients and making hot soups and sauces

Due to the machine’s speed, processing times are much quicker than standard appliances. Until you are

accustomed to the machine, count your time carefully to avoid over-processing

After turning the machine o, wait until the blades completely stop before removing the lid or container

from the motor bas

Never Start on Speeds Above 1 with

Hot Liquids to Avoid Possible Burns.

Use Caution; escaping steam or

splashes may scald.

Lock the lid. This will prevent

expansion from aecting the

position of the lid when the

machine is turned on.

Start on Variable 1, slowly

increase to 10.

CAUTION

OPERATING INSTRUCTIONS

Dry Blade Container

If purchased, your dry blade container should only be used for hard, dry materials such as grain, and for

kneading dough.

Make sure that the Variable Speed Dial is set to 1.

Securely fasten the 2-part lid. Always use the complete 2-part lid when blending (unless the tamper is

inserted through the lid plug opening). Especially when blending hot ingredients, make sure the lid is

securely latched

With the motor o, set the dry blade container on the motor base by aligning it over the centering pad.

Do not ever attempt to put a container on an operating motor base or to operate a motor base without a

container properly in place.

Start with the High/ Variable Switch in the Variable ( ) position. Always start your machine on

Variable speed 1. Activate the machine by turning the On/ O Switch to On (|) then slowly increase

to the desired speed. Your container will shift and get into an aligned position.

After turning the machine o, wait until the blades completely stop before removing the lid or container

from the motor base.

Due to the machine’s speed, and the sometimes short processing times, count your time carefully to

avoid over processing

Grinding dry material for more than 2 minutes could damage your machine. Regular use may result in

cosmetic marring of the container and cause the blades to become dull over time

Grinding some herbs may release volatile oils, causing the container to discolor permanently. Others

have strong odors that may linger in the container, affecting the flavor of other foods. The grinding of

some herbs and spices may also cause the blade to dull over time, or the container to crack.

CARE AND CLEANING

Container

To prepare your new machine for initial use, follow the steps under Normal Cleaning below. This will clean

the unit, and break-in the motor.

Normal Cleaning:

1. Fill the container half full with warm water and add a couple drops of liquid dish washing detergent to

the container.

2. Snap or push the complete 2-Part lid into locked position.

3. Select variable speed 1. Turn machine on and slowly increase speed to variable speed 10, then to High.

4. Run the machine on High speed for 30 to 60 seconds.

5. Turn off the machine, and rinse and drain the container.

To Sanitize:

1. Follow Normal Cleaning instructions above.

2. Fill the container half full with water and 1 1/2 teaspoons of liquid bleach.

3. Snap or push the complete 2-Part lid into locked position.

4. Select variable speed 1. Turn machine on and slowly increase speed to variable speed 10, then to High.

5. Run the machine on High speed for 30 to 60 seconds.

6. Turn off the machine, and allow mixture to stand in the container for an additional 1 1/2 minutes.

7. Pour bleach mixture out. Allow container to air dry.

8. Do not rinse after sanitizing.

Lid, Lid Plug and Tamper

Separate the lid and lid plug. Wash the parts in warm soapy water. Rinse clean under running water, and

dry. Reassemble before use.

IMPORTANT: To ensure continued and effective performance, do not put the container, lid, lid plug or

tamper in the dishwasher.

Altri manuali per Creations II

Indice

Altri manuali Vitamix Miscelatore

Vitamix

Vitamix VM0185 Manuale utente

Vitamix

Vitamix PBS Advance 2.0series Manuale utente

Vitamix

Vitamix Venturis Series Manuale utente

Vitamix

Vitamix 5200 Manuale utente

Vitamix

Vitamix EXPLORIAN Series Manuale utente

Vitamix

Vitamix Blending Station Advance SS Manuale utente

Vitamix

Vitamix Total Nutrition Center Manuale utente

Vitamix

Vitamix Advance and Portion Blending System Manuale utente

Vitamix

Vitamix Ascent SERIES Manuale utente

Vitamix

Vitamix The Quiet One Manuale utente

Vitamix

Vitamix Barboss Advance Manuale utente

Vitamix

Vitamix XL VM0141 Manuale utente

Vitamix

Vitamix One Manuale utente

Vitamix

Vitamix PROFESSIONAL SERIES 500 Manuale utente

Vitamix

Vitamix S-SERIES Manuale utente

Vitamix

Vitamix PROFESSIONAL 750 Manuale utente

Vitamix

Vitamix Total Nutrition Center Manuale utente

Vitamix

Vitamix XTG012 Manuale utente

Vitamix

Vitamix S30 Manuale utente

Vitamix

Vitamix ADVANCE PERFORMANCE BEVERAGE BLENDING ALL... Manuale utente

Vitamix

Vitamix PROFESSIONAL SERIES 500 Manuale utente

Vitamix

Vitamix 748 Manuale utente

Vitamix

Vitamix One VM0217 Manuale utente

Vitamix

Vitamix Venturist V1200 Manuale utente

Manuali Miscelatore popolari di altre marche

ROTOR

ROTOR 1125.201 Manuale utente

Braun

Braun Multiquick 5 Vario series Manuale utente

ARENDO

ARENDO MIRA 305424 Manuale utente

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuale utente

Viconte

Viconte VC-4406 Manuale utente

Oster

Oster BLSTAB-CB0 Manuale utente

HOFFEN

HOFFEN MC-3005 Manuale utente

Black & Decker

Black & Decker BLC18750DM Manuale utente

Sunbeam

Sunbeam 4182 Manuale utente

Bialetti

Bialetti FMX35 Manuale utente

Black & Decker

Black & Decker BL8000 Manuale utente

Duronic

Duronic BL530 Manuale utente

Exquisit

Exquisit MS 3002 wes Manuale utente

Lumme

Lumme LU-KP1891A Manuale utente

Binatone

Binatone HB-735 Manuale utente

Moulinex

Moulinex LM936E10 Manuale utente

Oster

Oster VERSA Manuale di installazione e funzionamento

Ninja

Ninja NN210Q Manuale utente
