Vivo MOUNT-PC10BU Manuale utente

Black Clamp-on Desk and Wall PC Mount with USB

Scan the QR code with your mobile device or follow the link

for helpful videos and specifications related to this product.

Instruction Manual

SKU: MOUNT-PC10BU

[email protected]om www.vivo-us.com 309-278-5303

Chat live with an agent!

GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

https://vivo-us.com/products/mount-pc10bu

PACKAGE CONTENTS

TOOLS NEEDED

WARNING!

A (x1)

PC Mount

B(x1)

USB Cover

S-A (x4)

ST4.8x38mm

Screw

S-C (x2)

ST4.2x15mm

Screw

S-D (x2)

M8 Nut

S-B (x4)

Concrete Anchor

C (x12)

Pad

D (x2)

Lower Clamps

If you do not understand these directions, or if you have any doubts about the safety of the

installation, please call a qualified technician. Check carefully to make sure there are no missing or

defective parts. Improper installation may cause damage or serious injury. Do not use this product

for any purpose that is not explicitly specified in this manual. Do not exceed weight capacity.

We cannot be liable for damage or injury caused by improper mounting, incorrect assembly or

inappropriate use.

Drill

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.

CAUTION!

DO NOT INSTALL INTO DRYWALL ALONE. VERIFY YOUR WALL CONSTRUCTION. USE WOOD STUDS TO

MOUNT. We include mounting for brick and concrete If unsure, please contact us at vivo-us.com,

email at [email protected]om, or call us at 309-278-5303.

T-B (x1)

5mm Allen

Wrench

ASSEMBLY STEPS

STEP 1

Install USB Cover (B) using ST4.2x15mm Screws (S-C). Remove protective film and attach Pads (C) to

PC Mount (A) as shown.

Level

22 lbs

(10 kg)

DO NOT EXCEED WEIGHT CAPACITY.

Failure to do so may result in serious injury.

Pencil

Phillips

Screwdriver

T-A (x1)

4mm Allen

Wrench

Thread Lower Clamps (D) onto PC Mount (A) by hand,

turning the screw and holding the lower clamps

steady. Ensure Lower Clamp (D) is extending towards

the front of the USB Cover (B).

Loosely install M8 Nuts (S-D) onto Mount (A).

S-D

S-C

STEP 2 - Option B | Wood Stud & Solid Wood Wall Installation

Solid Wood Wall Installation

For solid wood wall, place PC Mount (A) against wall and mark drilling locations. Using a 1/8” (3.5mm)

drill bit, drill holes 1.6” (40mm) deep. Insert two ST4.8x38mm Screws (S-A) into top holes, leaving 3mm

of thread exposed. Hang PC Mount (A) over screws and insert two more ST4.8x38mm Screws (S-A) into

lower holes. Tighten screws with a Phillips screwdriver.

Wood Stud Frame Installation

If wall has a wood stud frame, use a stud finder to locate the stud, then place mount against wall and

mark drilling locations for top and bottom holes on only one side of the mount. Using a 1/8” (3.5mm)

drill bit, drill holes 1.6” (40mm) deep. Insert a ST4.8x38mm Screw (S-A) into top hole, leaving 5mm of

thread exposed.

Hang PC Mount (A) over screw and insert another ST4.8x38mm Screw (S-A) into lower hole. Tighten

screws with a Phillips screwdriver.

STEP 2 - Option A | Clamp Installation

Clamp PC Mount (A) onto desktop using 5mm Allen Wrench (T-B).

Hand-tighten M8 Nuts (S-D) installed in previous step.

Loosen width adjustment screw on PC Mount (A) with a Phillips

screwdriver and pull the side bracket outwards.

Loosen set screws for lower support using 4mm Allen Wrench

(T-A) and slide the support down.

Place PC tower in PC Mount (A), slide bottom support up until

mount is fit vertically to PC, and tighten set screws using 4mm

Allen Wrench (T-A). Slide side bracket into place to hold PC,

and tighten screws using a Phillips screwdriver.

S-D

T-B

T-A

S-A

STEP 2 - Option C | Concrete Wall Installation

Concrete Wall Installation

For concrete wall installation, place PC Mount (A) against the wall and mark locations with a pencil.

Drill 1.6” (40mm) deep holes at marked locations using a 1/4” (6mm) drill bit. Insert Concrete Anchors

(S-B) into holes, and insert two ST4.8x38mm Screws (S-A) into top holes, leaving 5mm of thread

exposed.

Hang mount over two screws in the wall. Secure with two additional ST4.8x38mm Screws (S-A), and

tighten screws with a Phillips screwdriver.

S-B

S-A

STEP 3 - For Options B & C Only

Loosen set screws for lower support using 4mm Allen Wrench (T-A) and slide the support down. Loosen

two screws on top of Mount (A) (one on each side) with a Phillips screwdriver and slide side support

bracket out to maximum width.

Place PC tower in PC Mount (A), slide bottom support up until mount is fit vertically to PC, and tighten

set screws using the 4mm Allen Wrench (T-A). Slide side bracket into place to hold PC, and tighten

screws using a Phillips screwdriver.

T-A

LAST UPDATED: 10/24/2022

REV2

Open Monday - Friday 7:00am - 7:00pm CST,

our dedicated support team can oer immediate assistance with rapid response times. If any

parts are received damaged or defective, please contact us. We are happy to replace parts to

ensure you have a fully functioning product.

FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com

Love your new VIVO setup and want to share?

Tag us in your photo! @vivo_us

[email protected] AVG. RESPONSE TIME (within oice hrs): 1HR 8M

- 23% within < 15m

- 38% within < 30m

- 61% within < 1hr

- 83% within < 2hr

- 92% within < 3hr

AVG. RESOLUTION TIME (within oice hrs): < 15 M

www.vivo-us.com

Chat live with an agent!

AVG. RESOLUTION TIME (within oice hrs): 5M 4S

309-278-5303
