Vivo STAND-FT02R Manuale utente
Rockin Fide Ba Fooes
Instruction Manual
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371- 6 4
-Model STAN FT02R
Scan the QR code with your mobile device or follow the link
to helpful videos and specifications related to this product.
Assembl Seps
Tools Requied
phillips screwdriver
ackae Conens
1
- -hps//vivo us.com/poducs/sand f02
A (x2)
Legs
B (x1)
Rocke Ba
C (x2)
Suppo Plaes
(x8)
Fla Hea Scew
E (x4)
Pa Hea Scew
F (x1)
Alle Wec
Sep 1
Attach support plates (C) to legs (A) using flat head screws (D) and
tighten using allen wrench (F).
Sep 1 (Coninued)
Sep 2
Slide rocker bar (B) into mounts on support plates (C) as shown in
diagram. Secure rocker bar (B) in place using pan head screws (E)
and tighten using allen wrench (F).
If you do not understand these directions, or if you have any
doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no
missing or defective parts. Improper installation may cause
damage or serious injury. Do not use this product for any
purpose that is not explicitly specified in this manual. We
cannot be liable for damage or injury caused by incorrect
assembly or inappropriate use.
Email: help@vivo-us.com
Live chat: www.vivo-us.com
Call: 1-800-371- 6 4
For more VIVO products, check out our
website at
www.vivo-us.com.
If any parts are received damaged or defective, please contact
us. We are happy to replace parts to ensure you have a fully
functioning product.
Safe Wanin
Conac us a
Last updated: 0 /22/18 2
