VK VK200 Manuale utente
1
Hello,
Thank you for purchasing VK cellular phone.
Thank you again for choosing VK product and we hope you have greatest success
in your business with VK200.
Please read Safety Precaution prior to use.
The content of this manual and functions of cellular phone are subject to change
depending on the software version and conditions in business.
3
CONTENTS
2
Contents
PRIOR TO USE 6
Safety Precaution
Unpacking
Optional Items
Phone Layout and Keys Function
Keys Description
LCD Icon Description
Inserting SIM Card and Battery
Charging Battery
Reference About Battery Charging
Handset Power off Status
Handset Power on Status
7
13
13
14
15
18
19
21
22
22
23
BASIC FUNCTIONS 24
Basic Operation
Switching On/Off
Making a Call
Answering a Call
Hanging up
Options During a Call
Missed Calls
Volume Adjustment
Etiquette Mode
Using Ear-microphone
Standby Screen Function
Contacts
Storing Phone Numbers
Search Phone Number
Contacts Menu Function
25
25
25
27
27
28
31
31
32
32
33
34
34
38
41
BASIC FUNCTIONS
Menu Function of Selected Items
Character Input Mode
T9 Mode
ABC Mode
Numeric Mode
Symbolic Mode
Changing Text Input Mode
46
49
49
52
54
54
55
MENU FUNCTIONS 56
Menu Tree
Message
Short Message
Multimedia Message
Voice Message
Info. Message
Memory Status
Calls
Call History
Network Services
Gallery
Video-Clip
57
62
62
69
75
76
77
78
78
82
86
86
89
54
MENU FUNCTIONS
Animation
Sound
Music
T-Flash Manager
Memory Status
Camera
Video-Clip
Settings
Settings
Display
Sound
Phone Setting
92
95
97
100
103
105
106
106
109
110
113
113
116
119
MENU FUNCTIONS
Security
PC Connection
Organizer
Calendar
Alarm
Memo
Calculator
Unit Converter
World Time
Stop Watch
MP3 Player
Music Play
Edit Playlist
123
126
128
128
132
135
136
137
137
138
139
139
141
MENU FUNCTIONS
Joy World
Internet
Game
143
143
148
OTHER FUNCTIONS 150
PCSync Installation Guide
Safety Information
Using the Batteries
Safety Information
Care and Maintenance
FDA Consumer Update
FCC RF EXPOSURE INFORMATION
Radio Frequency (RF) Signals
Glossary
151
153
155
157
162
163
174
176
179
CONTENTS
7
PRIOR TO USE
Safety Precaution
Unpacking
Optional Items
Phone Layout and Keys Function
Keys Description
LCD Icon Description
Inserting SIM Card and Battery
Charging Battery
Reference About Battery Charging
PRIOR TO USE
Safety Precaution
Maintaining Safe Use of and Access to Your Phone
The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Important Information
This user guide contains important information on the use and operation of this phone.
Please read all the information carefully for optimal performance and to prevent any
damage to or misuse of the phone. Any changes or modifications not expressly approved in
this user guide could void your warranty for this equipment. FAILURE TO FOLLOW THE
INSTRUCTIONS OUTLINED MAY LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
Always store your phone away from heat.
Never store your phone in settings that may expose it to temperatures less than 32 F or
greater than 104 F, such as outside during a snowstorm or in your car on a hot day.
Exposure to excessive cold or heat will result in malfunction, damage and/or catastrophic
failure.
98
PRIOR TO USE
Be careful when using your phone near other electronic devices.
RF emissions from your mobile phone may affect nearby inadequately shielded electronic
equipment. You should consult with manufacturers of any personal medical devices such as
pacemakers and hearing aides to determine if they are susceptible to interference from your
mobile phone. Turn off your phone in a medical facility or at a gas station. Never place your
phone in a microwave oven as this will cause the battery to explode.
IMPORTANT! Please read the TIA SAFETY
INFORMATION on page 137 before using your phone.
Safety Information
Please read and observe the following information for the safe and proper use of your
phone and to prevent any unanticipated damage by accident. Also, keep the user s manual
in an accessible place all the times after reading it.
Unplug the power cord and charger during a lightning storm to avoid electric shock or
fire.
Do not use your phone in high explosive areas as the phone may generate sparks.
Do not put your phone in a place subject to excessive dust, and keep the minimum
required distance between the power cord and heat sources.
Unplug the power cord prior to cleaning your phone, and clean the power plug pin when
it is dirty.
Do not damage the power cord by bending, twisting, pulling, or heating. Do not use the
plug if it is loose as it may cause fire or electric shock.
Hold the power cord plug firmly to plug and unplug the power cord. Ensure the plug is
firmly connected. If it is not firmly connected, it may cause excessive heat or fire.
Do not place any heavy item on the power cord. Do not allow the power cord to be
crimped as it may cause fire or electric shock.
Be careful not to let the battery contact metal conductors such as a necklace or coins.
When shorted, it may cause an explosion.
Do not disassemble or impact to the battery as it may cause electric shock, short-circuit,
and fire. Store the battery in a place out of reach of children.
1110
PRIOR TO USE
Using a damaged battery or placing a battery in your mouth may cause serious injury.
Do not place items containing magnetic components such as a credit card, phone card,
bank book and a subway ticket, near your phone. The magnetism of the phone may
damage the data stored in the magnetic strip.
Do not hold or let the antenna come in contact with your body during a call.
Talking on your phone for a long period of time may reduce the call quality due to heat
generated during the use.
Do not allow excessive vibration or impact to the phone.
When you do not use the phone for a long period time, store it in a safe area with the
power cord unplugged.
Cautions for Travel Adaptor and Battery
Adoptor (Battery Charger) Cautions
Using the wrong Travel Adaptor could damage your phone and void your warranty.
Ther travel adapter is intended for indoor use only.
Do not expose Travel Adaptor to direct sunlight or use it in places with high humidity, such
as the bathroom.
“IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE INSTRUCTIONS and DANGER
- TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW
THESE INSTRUCTIONS”
“For connection to a supply not in the U.S.A., use an attachment plug adaptor
of the proper configuration for the power outlet.”
“This power unit is intended to be correctly orientated in a vertical or floor
mount position.”
1312
Unpacking
Cellular Phone
User’s Manual Ear-microphone
1. Handset
3. Accessories
Battery Travel adapter
Data Cable
2. Battery and Travel Adapter
PRIOR TO USE
Actual product may look different from the above picture.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.
Do not disassemble.
Do not short-circuit.
Do not expose to high temperature : 60 (140 ).
Do not incinerate.
Battery Disposal
Please dispose of your battery properly or bring to your local wireless carrier for recycling.
Do not dispose in fire or with hazardous or flammable materials.
1514
Phone Layout and Keys Function
PRIOR TO USE
Left soft key
Enter the left bottom menu of the display.
Send/Dial key
Make/Answer a calls.
When this button is pressed in standby mode, the last number you
dialed will be redialed.
Navigation key
Up : MP3 Player
Down : Gallery
Left : Message
Right : My Favorite
WAP/OK key
Enter WAP from standby mode.
Access function indicated on the bottom of the display.
Keys Description
Volume
Keys Charger
connection Cover
Earpiece
Front Cover Display
Camera
Navigation key
Right soft Key
End/Power
on-off key
Alphanumeric
Keys
Left soft Key
Sand/Dial Key
WAP/OK key
Special Function Keys
1716
Right soft key
Enter the Right bottom menu of the display.
In standby mode enters Contacts.
End/Power on-off key
End a call. Hold down to switch the phone on and off.
In menu mode, cancels input and returns the phone to standby mode.
Alphanumeric keys
Enter number and characters.
PRIOR TO USE
key
Hold down to activate Manner mode on/off.
key
Hold down to activate Lock mode on/off.
Volume key
Adjust the button volume from standby mode. Conversation volume
adjustment while speaking on the phone.
1918
LCD Icon Description
PRIOR TO USE
Inserting SIM Card and Battery
1. Turn off the power of cellular phone.
Remove the battery cover as shown in the figure below.
2. Face the gold color contact point of SIM card towards the cellular
phone and push in the SIM card into the slot.
3. Push in the battery as shown in the figure below.
Align the battery as shown in the figure.
Shows the received signal strength. [Strong
:
Weak
:]
Appears when a call is in progress.
Appears when you set the alarm to ring at a specific time.
Appears when you have new or unread message.
Appears when you set the alert type for incoming calls to
vibration.
Appears when you set the key pad lock function.
Shows the level of your battery.
