VOGELS MOMO Motion+ 4127 Manuale utente

www.vogels.com

MOMO Motion+

MOMO 4127 MOMO 4137

MOMO 4138 MOMO 4237

Installation Manual

CONTENTS

Mounting Instructions 3

Notes 9

Contact Details 12

www.vogels.com

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

MOMO 4138

1x C103

1x C104

1x C140

1x C316

1x/2x C320

1x C327

1x/2x C327

1x C501

1x/2x C501

MOMO 4127

MOMO 4137

MOMO 4237

1x C103

1x/2x C201

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

MOMO 4138 MOMO 4138

DESK ... mm

1a 1b

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

3 FIX

4 FIX

MOUNTING

ON DESK

MOUNTING

ON DESK

MOUNTING

ON DESK

MOUNTING

ON DESK

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

5 FIX

MOMO 4127

MOMO 4137

MOMO 4237

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

MOMO 4127

MOMO 4137

MOMO 4237

DESK ... mm

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

3 FIX

4 FIX

DESK

ALLEN KEY IN

MOMO C501

ALLEN KEY IN

MOMO C501

BACK

DUAL ARM

BACK

SINGLE ARM

5 FIX

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

4a 4b

MOMO 4138

MOMO 4127

C501

C327

C316

C104

C140

C201

3a 3b

MOMO 4138

DESK

BACK

DUAL ARM

BACK

SINGLE ARM

Max 35 mm

DESK

Ø9mm 2

MOMO 4127

MOMO 4137

MOMO 4237

BACK

DUAL ARM

BACK

SINGLE ARM

C104

C140

SINGLE

ARM

DUAL

ARM

Max 35 mm

Ø9mm

MOUNTING

THROUGH DESK

MOUNTING

THROUGH DESK

BACK

DUAL ARM

BACK

SINGLE ARM

BACK

DUAL ARM

BACK

SINGLE ARM

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

MOMO 4137

MOMO 4237

C501

C327

C140

C201

1x C320

C501

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

5 6

7 8a

TILT

ADJU

TILT FRICTION

ADJU

BALANCE

TOP

www.vogels.com

Mounting Instructions

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

ADJU

BALANCE

90˚

POSITION

HEAVY MONITOR

LIGHT MONITOR

www.vogels.com

Mounting Instructions

9 10

OPEN

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

BACK

DUAL ARM

BACK

SINGLE ARM

<10

<15

<20

<25

<30

<35

<40

<45

<50

<55

<60

<65

1x C320

MOMO Motion+

MOMO 4127 / 4137 / 4138 / 4237

www.vogels.com
