Volcano Fine Lavatube Manuale utente
USER GUIDE
Welcome to the VOLCANO Fine Electronic Cigarettes® family and thank you for your purchase!
Here you will nd all the information that you need to get your kit up and running.
If after reading through this you still need some help, we welcome you to visit our website
for more useful videos, tips, and information...and as always...happy vaping.
http://www.volcanoecigs.com/how-to
CONGRATULATIONS
DEVICE ANATOMY
Battery Compartment
This is where the battery is housed.
Power - Activation Button
This button powers the device on/o and
activates the unit during use.
LED Screen
This is the LED screen for displaying power features.
A
B
C
D
A
B
C
D
Tube Tank
This is the heating element /
eliquid well.
Drip Tip
This is a removeable mouthpiece.
E
E
FEATURES
2 Power Modes: The device can be set to either Average Voltage, or vRMS (recommended setting).
Within these modes the device can be set to either Variable Voltage or Variable Watage.
1
2Device Memory: All device settings are stored in internal memory. The LAVATUBE® remembers
the output settings as well as the voltage or wattage it was set to before being powered o.
Variable Voltage: In voltage mode, the voltage is changed in .1 volt increments.
3
4Variable Wattage: In wattage mode, the wattage is changed in .5 watt Increments.
INSTALLING / REPLACING BATTERY - STEP 1
1Unscrew and remove the LAVATUBE head unit.
1
INSTALLING / REPLACING BATTERY - STEP 2
2Install an AW IMR High Drain Rechargeable LiMN battery into the LAVATUBE.
2
INSTALLING / REPLACING BATTERY - STEP 3
3Reassemble the LAVATUBE® by screwing the battery compartment back onto the head unit.
3
TURNING DEVICE ON, CHECKING VOLTAGE AND OHMS: - STEP 1
1To turn the device on/o, click the activation button 5 times rapidly
(approximately a half of a second in-between clicks)
1
2To check the battery level, the LAVATUBE® is capable of reading and displaying the current
voltage the battery is outputting on it’s own. To do this, simply press and hold the minus button
for approximately 5 seconds. The display will briey show the battery voltage between a range
of 4.2v (fully charged battery)to 3.2v (depleted battery that must be recharged).
*When the battery is too low to eectively power the LAVATUBE®, the screen will display “LO”
when you press the activation button. At this point, you will need to either switch out the
battery for a fresh one or recharge the battery that is currently being used.
2
TURNING DEVICE ON, CHECKING VOLTAGE AND OHMS: - STEP 2
3To check the Ohms of the heating element attached, press and hold the plus button for
approximately 5 seconds. The screen will briey show the heating elements ohm resistance
level before reverting back to the general power settings screen.
TURNING DEVICE ON, CHECKING VOLTAGE AND OHMS: - STEP 3 3
