Volvo C70 Manuale utente

WelcOme TO The glObAl FAmIly OF vOlvO

OWneRS!

Getting to know your new vehicle is an exciting experience.

Please browse through this Quick Guide to get the full benefits from

your new Volvo. For detailed information, please refer to your Owner´s

Manual.

Warning texts and other important information are only provided in the

Owner’s Manual - not in this folder. The Owner’s Manual contains the

most up-to-date information.

For additional information, contact Customer Service:

U.S.A.: 1-800-458-1552 www.volvocars.us

CANADA: 1-800-663-8255 www.volvocanada.com

vOLvO C70

quick guide

AUTOSTART

Depress the clutch and/or brake pedal. Turn

the key/keyless drive start control to position III

and release it. The engine will start automati-

cally.

KEY BLADE

Used to lock/unlock the glove compartment or

the driver’s door if the vehicle has no electrical

current.

COLD START

NOTE

After cold starts, your engine will idle at a

higher speed for a short time.

KEY & REMOTE CONTROL

Locks the doors, trunk, cabin storage

compartments, ski hatch, and arms

the alarm. If the car is locked with

the remote control while the power

retractable hard top is down, the double

locking feature activates after approxi-

mately 30 seconds. The doors can then

not be opened from inside the car.

Unlocks the doors, trunk, cabin stor-

age compartments, ski hatch, and

disarms the alarmA.

Unlocks the trunk. (Does not open the

trunk)

Approach lighting (30 secondsB)

illuminates lights in door mirrors, cabin,

footwells, license plates. Turn signals

and parking lights illuminate.

“Panic” alarm. Press and hold to

sound the alarm. Turn off alarm with

unlock button.

A. Automatic relock occurs if no door/tailgate is

opened within 2 minutes after unlock.

B. The time can be set to 30, 60, or 90 seconds.

TURN SIGNALS

A. Lane-change sequence, three flashes.

B. Full turn sequence.

Adjust tilt and telescope.

WARNING! Never adjust the steering wheel

while driving.

STEERING WHEEL ADJUSTMENT

To mechanically open the trunk.

LIGHTING PANEL

Automatic headlights. High beam

flash only.

Parking lights

Headlights: turn off when ignition is

switched off, high/low beams.

Display & instrument panel lighting

Front fog lights (option)

Rear fog light (driver’s side only)

High beam flash

Toggle between high/low beams,

home safe lighting.

REFUELING

We do not recommend washing your car in

an automatic wash during the first six months

because the paint will not have hardened

sufficiently.

Leather upholstery requires regular care. Treat

the leather with protectant cream, one to four

times a year as necessary. Consult your Volvo

retailer for leather care products.

CAR CARE

Press this button to unlock the fuel filler door.

Hang the fuel filler cap on the hook while

refueling.

BLIS – BLIND SPOT INFORMATION

SYSTEM (OPTION)

If the BLIS indicator lights illuminate occasion-

ally even when there are no other vehicles in

the blind area, this may be caused by light re-

flected from a wet road surface, the vehicle’s

own shadow against a large, light, smooth

surface, or sunlight directly in the camera

when the sun is low on the horizon.

In the event of a fault, Blind spot syst. ser-

vice required will be displayed.

AUTOMATIC CAR WASH

Remove the antenna, by turning it coun-

terclockwise, before washing the car in an

automatic car wash.

A B

WINDSHIELD WIPERS AND RAIN SENSOR (OPTION)

Single wiper sweep

Off

Intermittent wipers. Turn (B) to adjust

interval

Normal speed

High speed

Windshield and headlight washer

AUDIO SYSTEM

Activate rain sensor. Positions D-F

deactivate the rain sensor.

Turn to adjust rain sensor sensitivity.

Symbol in display (rain sensor on).

On/Off and volume. Press to turn on/off.

Turn to adjust volume. Radio and Volvo

Navigation System (option) volume are

stored individually.

FM1, FM2 or AM radio

Display

MODE, CD, Sirius satellite radio (op-

tion), AUXA.

Sound settings. Press to select e.g.,

BASS, TREBLE, etc. Turn to adjust.

MENU. AUX volume and advanced sound

settings.

A. AUX connector for e.g., MP3 player. Set MP3 player’s volume

to medium for best sound quality. The accessory iPod Music

Interface enables control of the music player using the audio

system controls or steering wheel keypad.

B. Files in MP3 and WMA formats can also be played

RADIO

Turn to select a radio station.

Search for stations with left/right arrows

or SCAN (8). Store up to 20 stations by

pressing and holding one of the preset

buttons (7) 0–9 in FM1 and 0–9 in FM2. A

stored station is confirmed in the display.

Autostore stations

Press AUTO for 2 seconds. AUTOSTORE

is displayed during the search. The 10

strongest stations are stored. Press 0–9

to select a station.

CD PLAYERB

Change CD tracks with left/right arrows

or turn (6).

Select CD (optional CD changer only)

with up/down arrows.

CD eject. Press to eject current CD.

Press and hold to eject all CDs.

CD select (optional CD changer only).

Press 1–6.

BLUETOOTH®

Make the cell phone searchable/visible.

Press the PHONE button on the audio sys-

tem control panel briefly.

Select ”Add phone” in the audio system

display.

Select the cell phone to be connected.

Enter the numbers shown in the audio sys-

tem display using the cell phone’s keypad.

AUTOMATIC CONTROL

In AUTO mode, ECC controls all functions

automatically and makes driving more pleasant

with optimal air quality.

Automatic mode

Press AUTO to maintain cabin temperature

balanced airflow, and other settings.

Temperature

Press to individually adjust the left (L) or

right (R) side. Turn the dial to the desired

temperature, which is shown in the display.

ELECTRONIC CLIMATE CONTROL—ECC (OPTION)

MANUAL CONTROL

Blower speed

Air distribution

Defroster to quickly remove mist on the

windshield and side windows.

Recirculation

Air conditioning off/on.

Heated rear window and door mir-

rors. Timer functionA.

A. Rear window 12 minutes. Mirrors 6 minutes.

TIRE PRESSURE MONITORING SYS-

TEM (TPMS)

When a low tire pressure warning message

has been displayed and the tire pressure

warning light has come on, one or more tires

has low inflation pressure.

Stop the vehicle in a safe place and check

the inflation pressure of all four tires with a

tire pressure gauge.

CD STORAGE

The deep center storage compartment has

room for 10 CD jewel cases. These cases

must be inserted with their spines upward in

order to allow room for 10 CDs.

FUEL

Low fuel level indicator

When the symbol illuminates, refuel as

soon as possible.

Fuel gauge

The fuel filler door is on the right, as indi-

cated by the arrow.

TRIP ODOMETER

Press quickly to toggle between T1 &

T2. Press and hold to reset the dis-

played odometer.

The trip odometer display shows two

separate trip odometers, T1 & T2.

DISPLAY

Information display (trip computer

information, messages, clock and am-

bient temperature).

ODOMETER AND TRIP COMPUTER

TRIP COMPUTER

Press to erase a displayed message.

Turn to show trip computer information

such as MILES TO EMPTY TANK in the

information display.

Reset current function. A long press

resets all functions.

NOTE

MILES TO EMPTY TANK is an approxima-

tion, based on recent average fuel consump-

tion.

DRIVER’S DOOR CONTROL PANEL

L R

Adjusting the door mirrors. Select

L or R. Adjust with the control.

Open/close a window partially

Open/close a window fully

AUTOMATIC WINDOW FUNCTION

When a door is opened or the power retract-

able hard top is operated, the windows open

automatically approximately 1 in. (2 cm). The

windows close again automatically.

6.5 ft

2.0 m

8 in

0.2 m

OPERATION

OPERATING THE POWER RETRACTABLE HARD TOP

PREPARATION

There should be no objects on the parcel shelf,

roof, or trunk lid.

6.5 ft (2 m) free height above the car, and

8 in. (0.2 m) behind.

Flat ground.

Ambient temperature above 14 ˚F (-10 ˚C).

Trunk lid and trunk divider closed.

The car must be at a standstill.

Always have an unobstructed view of the

power retractable hard top when it is in

motion.

The windows open automatically approximately

1 in. (2 cm) when the power retractable hard top

is operated. They close automatically.

•

TRUNK DIVIDER

Engine idling (car parked outdoors).

Press the brake pedal.

Hold down the button (see inset illustration

above) to open or pull up to close the con-

vertible hard top. Hold until a tone is audible

and the message TOP FULLY UP/TOP

FULLY DOWN is displayed.

Release the button.

The trunk divider limits the amount of cargo

in the trunk to leave space for the power

retractable hard top.

Raise the divider when loading the trunk.

Close the divider completely (3) before

operating the hard top. See the decal on

the trunk divider.

Raise or lower the folded power retractable

hard top to facilitate loading.

Press the button and wait several seconds

for the hard top to rise slightly. Open the

trunk divider, load the cargo, and close the

trunk divider again.

Press the button again to lower the folded

power retractable hard top.

LOAD ASSISTANCE

ADJUSTING THE FRONT SEAT

STORAGE SPACES, 12-VOLT SOCKET & AUX CONNECTOR (OPTION)

The front and rear 12-volt sockets function in

ignition positions Ior II. The 12 volt socket on

the right side of the trunk is always active.

AUX can be used to connect e.g., an MP3

player to the vehicle’s audio system. Use a

3.5 mm stereo mini plug.

The accessory iPod Music Interface enables

control of the music player using the audio

Access to rear seat & seat belt guide

Manual seat

A. Remove the seat belt from the guide.

B. Pull up the handle and move the seat for-

ward.

Power seat (option)

A. Remove the seat belt from the guide.

B. Pull up the handle and fold the backrest

down.

C. Press and hold the button while the seat

moves forward.

Lumbar support

Backrest tilt

Raise/lower the seat

Raise/lower the front edge of the seat

cushion

system controls or steering wheel keypad.

CAUTION

Using the 12-volt socket in the trunk with the

engine switched off will drain the battery.

Forward/rearward

Altri manuali per C70

Indice

Altri manuali Volvo Automobile

Volvo

Volvo S80 - Manuale utente

Volvo

Volvo S60 - ANNEXE 931 Manuale utente

Volvo

Volvo C40 Recharge Pure Electric 2021 Manuale utente

Volvo

Volvo S60 TWIN ENGINE Manuale utente

Volvo

Volvo V70 SPORT Manuale utente

Volvo

Volvo 2000 V40 Manuale utente

Volvo

Volvo XC60 Twin Engine Manuale utente

Volvo

Volvo S60 2021 Manuale utente

Volvo

Volvo 850 Guida all'installazione

Volvo

Volvo XC60 - ANNEXE 541 Manuale utente

Volvo

Volvo V90 - ACCESSORY PANEL Manuale utente

Volvo

Volvo S60 S60R Manuale utente

Volvo

Volvo V70 SPORT Manuale utente

Volvo

Volvo XC90 TWIN ENGINE Manuale utente

Volvo

Volvo V40 2017 Manuale tecnico

Volvo

Volvo XC70 - ANNEXE 808 Manuale utente

Volvo

Volvo XC70 - ANNEXE 808 Manuale utente

Volvo

Volvo V90 CROSS COUNTRY 2019 Manuale utente

Volvo

Volvo 2005 V70R Manuale utente

Volvo

Volvo S40 - ANNEXE 244 Manuale utente

Volvo

Volvo V70 SPORT Manuale utente

Volvo

Volvo C30 - ANNEXE 798 Manuale utente

Volvo

Volvo S60 - ANNEXE 931 Manuale utente

Volvo

Volvo C70 Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
