Volvo XC 60 Manuale utente

QUICK GUIDE

WELCOME TO YOUR NEW VOLVO!

This folder contains a selection of the most common functions in your car. The owner's manual and other

manuals contain safety instructions and all warning, important and note texts.

The following symbols mean:

Different parts are pointed out in the overview images.

Step–by–step instructions.

It is particularly important to read the owner's manual.

Warning, important and note texts, which must be read, are included on the last page.

Options are marked with an asterisk *.

The owner's manual is available as a printed manual and digitally in the car's screen, on the Web and as a

mobile app. The mobile app contains the whole owner's manual as well as instruction films and has several

search paths with text and illustrations. The mobile app can be downloaded to mobile devices from App Store or

Google Play.

In addition, learn more about your car at www.volvocars.com.

Climate system controls

Headlamp control

Combined instrument panel

Infotainment system

Phone*

Internet*

External audio device

Buttons in the centre console

Settings in the menu system

Workshop/booking service*

ECO*

Adjusting the seat

Adjusting the steering wheel

Power operated tailgate*

03 Your driving environment Refuelling

Car care

Storage spaces

AUX/USB* and 12 V sockets

04 Functions in your car

05 Tips

Start/Stop function*

Pedestrian protection*

02 Driver support in your car

Remote control key

Keyless* lock system

Starting and switching off the engine

Parking brake

Wipers

Tyre pressure monitoring*

01 Starting and driving

How does the remote control key work? 01

Unlocks doors and tailgate and disarms the alarm. The

function can be set in MY CAR.

Locks doors and tailgate and arms the alarm.

Approach light duration.

One press unlocks the tailgate and one long press

opens the power tailgate*.

Information*.

Panic function.

The remote control key can store settings for,

amongst other things, door mirrors and power

driver's seat* – see owner's manual.

What do the remote control key indicator

lamps* show? 01

Green continuous light: The car is locked.

Yellow continuous light: The car is unlocked.

Red continuous light: The alarm has been triggered

since the car was locked.

Red light flashing alternately in both indicator lamps:

The alarm was triggered less than 5 minutes ago.

How does the Keyless* lock system work?

The remote control key can remain in a pocket, for

example.

Lock and arm the alarm

– Depress the button on the rear section of the handle.

Unlock and disarm the alarm

– Grip a door handle and open the door in the usual way

or press lightly on the tailgate's rubberised pressure

plate.

How do I start and switch off the engine?

Starting

Push the remote control key into the ignition switch

(does not apply to Keyless drive*).

For manual gear changing, depress the clutch pedal.

For automatic gear changing, depress the brake

pedal.

Briefly press the START/STOP ENGINE button.

Switching off

Briefly press the START/STOP ENGINE button.

Take the remote control key out from the igni-

tion switch (does not apply to Keyless drive*).

How do I use the parking brake? 01

Activate

– Press the control PUSH LOCK/PULL RELEASE – the

symbol starts to flash. Once there is a constant glow

the parking brake is activated.

To disengage

Depress the brake pedal.

Pull the control PUSH LOCK/PULL RELEASE.

Disengage automatically

– Drive away (for cars with automatic gearbox, the

seatbelt must be buckled).

How do I start the windscreen wipers and rain

sensor*?

Move the lever downward to start the windscreen wipers

and upward for a single sweep.

Rain sensor On/Off.

Regulates the sensor sensitivity or the intermittent

delay.

Wiper, rear window - intermittent/normal.

To lift up the wiper blades they must be in service

position – see owner's manual.

How do I use the Start/Stop function*? 02

Manual gearbox

Stop the engine: Declutch, move the gear lever into

neutral position and release the clutch pedal.

Start the engine: Depress the clutch pedal.

Automatic gearbox

Stop the engine: Stop the car with the foot brake and then

maintain the brake pressure.

Start the engine: Release foot pressure on the foot brake.

Illuminated button lamp indicates that the function is

active.

It is important to understand this function – see

owner's manual.

Collision Warning with Auto Brake and Cyclist and

Pedestrian Detection, which can warn, brake and/or stop

for vehicles, cyclists and pedestrians.

The function is only an aid and does not work in all

situations – for example, it does not see cyclists from the

side and pedestrians who are shorter than 80 cm or who

are partially obscured.

How does the pedestrian protection work*? 02

Calibration is always required after changing tyres or

changed tyre pressure. In the event of lamp illumination

the tyre pressure needs to be checked and the system

calibrated. Proceed as follows:

With the ignition switched off, inflate all tyres in

accordance with the tyre pressure label on the driver's

side door pillar.

Start the car. In the normal view for the MY CAR

source, press OK/MENU.

Select Tyre monitor > Calibrate tyre pressure and

press OK/MENU.

Recalibration is carried out while the car is being

driven.

How do I calibrate the tyre pressure

monitoring system (TM)*? 01

How do I adjust the seat?

Raise/lower the front of the seat cushion.

Raise/lower the seat.

Move the seat forward/backward.

Tilt the backrest.

Lumbar support* adjustment.

Storing settings for power seat*.

Memory buttons for power seat*.

Store setting:

Hold the button depressed to store settings while

depressing one of the memory buttons. Hold the buttons

depressed until a signal is heard and text is shown in the

combined instrument panel. This stores the position of the

seat as well as the door mirrors. The position of the lumbar

support is not stored.

The position for the door mirrors, and the memory

settings (not lumbar support) for the power seat,

can also be stored in the remote control key* – see

owner's manual.

How do I adjust the steering wheel?

Release the steering wheel lock.

Adjust the steering wheel forward/backward and up/

down.

Lock the steering wheel.

How do I regulate the temperature? 04

Turn for individual temperature in the left/right-hand

area of the passenger compartment. The screen

shows the selected temperature.

Press AUTO for automatic control of air distribu-

tion and other functions. The screen shows AUTO

CLIMATE.

Tip: AUTO mode is recommended for optimum climate

comfort. When fan speed and air distribution are regulated

the AUTO mode will be deactivated.

How do I defrost the windscreen? 04

Press to activate the windscreen's electric heating* -

symbol (1) in the screen illuminates.

The next press also activates maximum airflow against

windscreen and side windows - symbols (1) and (2)

illuminate.

The next press switches off both of the functions – no

symbol illuminates.

Without electrical heating: Press to activate/deactivate

the airflow.

How do I open and close the power operated

tailgate*?

Opening

– Press lightly on the rubberised pressure plate under

the outside handle. Alternatively, a long press on the

lighting panel button or the remote control button until

the tailgate starts to open.

Closing

– Press the button and the tailgate closes automatically.

The tailgate can also be opened/closed manually.

How is the trip computer operated?

OK - opens the combined instrument panel's menu,

confirms messages or menu selections.

The thumbwheel browses between menu options or

trip computer options.

RESET resets data in the selected trip computer step

or goes back in the menu structure.

How do I reset the trip meter? 04

Turn the left-hand stalk switch thumbwheel to show

trip meter T1 or T2.

Give a long press on the RESET button in order to

reset the trip meter shown.

How does the headlamp control's auto mode

work?

AUTO mode provides the following options:

• The daytime running lights automatically switch

between daytime running lights and dipped beam.

• Main beam can be activated when dipped beam is

switched on.

• Active high beam (AHB)* – that dims and activates main

beam automatically, or adapts the main beam pattern to

the traffic conditions – can be used.

• Tunnel detection* is activated.

How do I switch on and off the Infotainment

system?

A short press activates the system.

A long press (until the screen switches off)

deactivates.

To switch off the audio: Give a short press – the next press

reactivates.

Note that the whole of the Sensus system (including

navigation* and phone functions*) is started/switched off

at the same time.

How do I navigate in the infotainment system?

Press RADIO, MEDIA, MY CAR, NAV*, TEL* or * to

select main source. In this mode, the normal view of

the last active source is shown.

Press OK/MENU or the thumbwheel* in the steering

wheel to access the selected source's main menu.

Turn TUNE or the thumbwheel to navigate in the

menus.

Press OK/MENU or the thumbwheel to make a

selection in the menus.

Briefly press EXIT to go back in the menu system,

cancel a function or delete entered characters.

Give a long press on EXIT to go back to normal view,

or to go from normal view to the main source view.

Tips:

To go to the shortcut menu from normal view, press once

on the main source button. Press again to go back to

normal view.

For more information about operating the system –

see owner's manual.

In the normal view for the phone source, press

OK/MENU.

Select Make car discoverable and confirm with

OK/MENU.

Activate Bluetooth®in the mobile phone. Search for

and connect the car to the phone.

Follow the instructions in the mobile phone and the

screen.

The phone is now connected and can be controlled from

the car.

How do I connect a Bluetooth®phone*?

If registering the phone does not succeed – see

owner's manual.

How do I connect to the Internet*? 04

For more information about connection - see

owner's manual.

Connect the mobile phone via Bluetooth®or activate

tethering in the phone for Wi-Fi connection. For car

modem connection, fit the SIM card into the reader in

the glovebox.

In the normal view for the MY CAR source, press

OK/MENU, select Settings > Internet settings >

Connect through. Select a connection option.

Wi-Fi: connect to a network and enter its password.

Car modem: enter the SIM card's PIN code.

What services do I get with Volvo ID*? 04

For more information about Volvo ID - see owner's

manual.

Volvo ID is your personal ID registered to the car which

can give you access to various services such as My Volvo

Web and the ability to send an address from the map

service on the Internet directly to the car.

Press twice on the connection button .

Select Apps > Settings and follow the onscreen

instructions.

Altri manuali per XC 60

Altri manuali Volvo Automobile

Volvo

Volvo V70 SPORT Manuale utente

Volvo

Volvo 850 Manuale utente

Volvo

Volvo XC90 - ANNEXE 951 Manuale utente

Volvo

Volvo 2009 S40 Manuale utente

Volvo

Volvo V70 SPORT Guida rapida

Volvo

Volvo 1998 C70 Manuale utente

Volvo

Volvo 1996 960 Istruzioni per il montaggio

Volvo

Volvo 164 1969 Manuale utente

Volvo

Volvo V70 SPORT Manuale utente

Volvo

Volvo XC90 Excellence Manuale del proprietario

Volvo

Volvo 760 GLE Turbo 1986 Manuale utente

Volvo

Volvo 2004 V70 Guida rapida

Volvo

Volvo S60 S60R Manuale utente

Volvo

Volvo S40 2005 Manuale

Volvo

Volvo 240 Manuale utente

Volvo

Volvo C70 Manuale utente

Volvo

Volvo 2007 S80 Manuale utente

Volvo

Volvo V60 Manuale utente

Volvo

Volvo V50 Manuale utente

Volvo

Volvo S90 - ACCESSORY PANEL Manuale utente

Volvo

Volvo 2006 S80 Manuale utente

Volvo

Volvo XC90 - ANNEXE 951 Manuale utente

Volvo

Volvo C70 Manuale utente

Volvo

Volvo C70 2012 Manuale utente

Manuali Automobile popolari di altre marche

Toyota

Toyota 2000 Tundra Manuale utente

CITROËN

CITROËN DS4 DSign Manuale utente

Lexus

Lexus 2015 CT 200h Manuale utente

Cadillac

Cadillac CTS 2008 Manuale utente

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuale utente

Porsche

Porsche Boxster S Manuale utente

GMC

GMC 2010 Savana 1500 Cargo Manuale utente

KIAM

KIAM SPORTAGE 2014 Manuale elenco delle parti

GMC

GMC 2013 Terrain Istruzioni per il montaggio

GMC

GMC T-Series 1999 Manuale utente

Mercury

Mercury 1998 Mystique Manuale utente

Mercury

Mercury 2007 Mariner Manuale utente

Mazda

Mazda 2007 Mazdaspeed 3 Guida

Mazda

Mazda 2014 CX-5 Manuale utente

GMC

GMC Chevrolet Express 2022 Manuale utente

GMC

GMC 1997 Jimmy Manuale utente

Chevrolet

Chevrolet 2012 Malibu Manuale utente

Cadillac

Cadillac 2010 Escalade Manuale utente
