Volvo XC60 2013 Manuale utente

XC60 Quick GUIDE WEB EDITION

WELCOME TO YOUR NEW VOLVO!

This folder contains a selection of the most common functions in your particular car. The owner's

manual and other manuals contain important information with all warnings and safety instructions.

The following symbols mean:

Different parts are pointed out in the overview images.

Instructions step-by-step.

It is particularly important to read the owner's manual.

Important information, warnings and safety instructions that must be read are listed on the

last page.

Options are marked with an asterisk *.

In addition, learn more about your particular car at www.volvocars.com

Climate system controls

Headlamp control

Combined instrument panel

Infotainment system

Phone*

External audio device

Buttons in the centre console

Settings in the menu system

Adjusting the seat

Adjusting the steering wheel

Panorama roof*

Power operated tailgate*

03 Your driving environment

Car care

Opening all windows

Storage spaces

AUX/USB* and 12 V sockets

04 Functions in your car

05 Tips

BLIS*

Start/Stop function*

Pedestrian protection*

02 Driver support in your car

Remote control key

Starting and switching off the engine

Parking brake

Keyless key system*

Wipers

01 Starting and driving

How do I start the engine?

How does the remote control key work?

What do the remote control key indica-

tor lamps* show?

Press the remote control key into the ignition

switch.

Depress the clutch or brake pedal.

Briefly press the START/STOP ENGINE but-

ton and release - the engine starts.

Green light: The car is locked.

Yellow light: The car is unlocked.

Red light: The alarm has been triggered.

Flashing alternating red light: Alarm triggered

less than 5 minutes ago.

Unlocks the doors and boot lid and disarms

the alarm*.

Locks doors and boot lid and arms the alarm.

Approach light duration.

Only unlocks the boot lid.

Information* about the car.

Panic function

The remote control key can store settings

including door mirrors and driver's seat*.

How do I switch off the engine?

Briefly press the START/STOP ENGINE but-

ton – the engine stops.

Take the remote control key out from the igni-

tion switch.

How does the Keyless* key system

work?

The key can remain in your pocket for example the

whole time.

Lock and arm the alarm (see illustration)

–Touch the rear section of one of the outer door

handles.

Unlock and disarm the alarm

–Grip a door handle and open the door in the

usual way or press lightly on the tailgate's rub-

berised button.

How do I use the parking brake? 01

To apply

Depress the foot brake pedal.

Press the control PUSH LOCK/PULL

RELEASE - the combined instrument panel's

warning symbol starts to flash. Once there is a

constant glow the parking brake is applied.

Release the foot brake pedal.

To disengage

Depress the foot brake pedal.

Pull the control PUSH LOCK/PULL

RELEASE.

How do I start the windscreen wipers

and rain sensor*?

Move the lever downward to start the windscreen

wipers and upward for a single sweep.

Rain sensor On/Off.

Regulates the sensor sensitivity or the inter-

mittent delay.

Wiper, rear window - intermittent/normal.

WHAT DOES BLIS DO*?

Blind Spot Information System advises about

vehicles in the blind spot and rapidly approaching

vehicles.

–BLIS is activated when the engine is started and

can be deactivated/reactivated by pressing the

button.

How do I use the Start/Stop function*?

Manual gearbox

Stop the engine: Declutch, set the gear lever in

neutral position and release the clutch pedal.

Start the engine: Depress the clutch pedal.

Automatic gearbox

Stop the engine: Stop the car with the foot brake

and then maintain the brake pressure.

Start the engine: Release foot pressure on the foot

brake.

Illuminated button lamp indicates that the function

is active.

How do I adjust the seat?

Raise/lower the front of the seat cushion.

Raise/lower seat.

Move the seat forward/backward.

Tilt the backrest.

Store settings for power seat*.

Memory buttons for power seat.

Store setting:

Hold the button depressed to store settings while

depressing one of the memory buttons.

Seat settings can also be stored in the

remote control key*.

It is important to understand this function

thoroughly.

The car has Collision Warning with Auto Brake &

Pedestrian Detection, which can warn, brake and/

or stop for vehicles and pedestrians.

The function is only an aid and does not work in all

situations – for example, it does not see pedestri-

ans who are shorter than 80 cm or who are partially

obscured.

How does the pedestrian protection

work*? 02

How do I adjust the steering wheel?

Release the catch.

Adjust the steering wheel forward/backward

and up/down.

Lock the steering wheel.

How do I open and close the power

operated tailgate*?

The first press operates the sun blind – the second

the panorama roof.

Automatic maximum opening.

Manual opening.

Manual closing.

Automatic maximum closing.

Opening ventilation position.

Closing ventilation position.

How does the panorama roof* work?

Opening

–Press lightly on the rubberised pressure plate

under the outside handle. Alternatively, a long

press on the lighting panel button or the remote

control button until the tailgate starts to open.

Closing

–Press the button and the tailgate closes

automatically.

The tailgate can also be opened/closed manually.

How does the headlamp control's auto

mode work? 04

How do I defrost the windscreen? 04

How do I regulate the temperature with

ECC*? 04

Turn for individual temperature in the

left/right-hand area of the passenger

compartment. The screen shows the selected

temperature.

Press AUTO for automatic control of air distri-

bution and other functions. The screen shows

AUTO CLIMATE.

Press to activate the windscreen's electric

heating* - symbol (1) in the screen illuminates.

The next press also activates maximum air

flow against the windscreen and side

windows - symbols (1) and (2) illuminate.

The next press switches off both of the func-

tions – no symbol illuminates.

Without electric heating: Press to activate/deacti-

vate the air flow.

The daytime running lights automatically switch

between daytime running lights and dipped beam.

Main beam can be activated when dipped beam

is switched on. Active high beam (AHB)* that dims

and activates main beam automatically, or adapts

the main beam pattern to traffic conditions, can

be used. Tunnel detection* is activated.

How is the trip computer operated?

OK opens the trip computer's menu, activates

the selected option and extinguishes mes-

sages.

Thumbwheel scrolls between the trip com-

puter options.

RESET resets data in the selected trip

computer step and goes back in the menu

structure.

How do I reset the trip meter?

The gear shift indicator's arrows advise when it

is appropriate to engage a higher or lower gear

in order to obtain optimum driving economy. The

illustration shows the digital* combined instrument

panel.

How does the gear shift indicator

work*? 04

Give two presses on the left-hand stalk switch

RESET button.

Angle forward trip meter T1 or T2 with the

thumbwheel.

Give a long press on RESET to reset to zero.

Analogue combined instrument panel.

How do I switch on and off

Infotainment system?

Give a short press to activate the system.

Give a long press (until the screen switches

off) in order to switch off.

To switch off the sound (MUTE): Give a short

press - the next press reactivates.

How does the range/"km to empty tank"

work? 04

How do I change the combined instru-

ment panel's appearance? 04

The combined instrument panel shows an estima-

tion of the possible driving distance based on previ-

ous driving conditions and remaining fuel quantity.

No guaranteed range remains when "...km" is

shown. Refuel as soon as possible. The illustration

shows the digital* combined instrument panel.

Analogue combined instrument panel.

Different themes can be selected with the digital*

combined instrument panel, such as Performance

or Eco.

To change the theme:

Press the left-hand stalk switch's OK button

when the engine is running.

Turn the lever's thumbwheel in order to select

menu option Themes.

Turn the thumbwheel to select a theme and

press OK to confirm.

The theme is stored in the remote control

key*.
