Volvo VOLVO NAVIGATION SYSTEM (VNS) Manuale utente
VOLVO NAVIGATION SYSTEM (VNS)
Volvo Car
Corporation
WEB EDITION
Types of roads Color
Freeways Orange
Main roads Dark gray
Secondary main roads Gray
Normal roads Light gray
Local roads White
Text and symbols on the screen
Direction to take at next guidance point
Distance to the next guidance point
Name of next street or road
Stored location
Symbol for Final destination
Remaining time to destination
Starting point
Remaining distance to destination
Intermediate destination
Speed limit at the vehicle’s current location [18]. Not on models
with RSI.
Compass
Traffic information (not available in all markets)
Extent of street/road with traffic problem (not available in all mar-
kets)
Current road (the vehicle’s current location [18])
Symbol for a Point of Interest – POI (Restaurant with seafood)
Final destination
Route
The vehicle’s current location
Completed section of the route
Next guidance point
Map scale
VOLVO NAVIGATION SYSTEM (VNS) WITH RTT
VNS is a navigation system developed by
Volvo that is designed to help guide you to
the destination of your choice and provide
information along the way.
RTT1 (Real Time Traffic) is an information system
developed by Volvo, which can detect roads/
streets with traffic disruptions and make it possi-
ble to select an alternative route past the problem
area.
The system includes features that enable you to
set itineraries, search for certain types of points of
interest along your route, store special destina-
tions, obtain traffic informaton en route, etc.
The system indicates the vehicle’s current loca-
tion, and shows part or all of the route to your
destination, depending on the settings you have
made. If at any time you should decide to deviate
from the route originally set by the system, a new
route to the destination will automatically be cal-
culated.
By enabling you to reach your destination quickly
and by the most direct route, Volvo's navigation
system also helps contribute to improving the
environment.
NAVTEQ DATABASE End-User License Agree-
ment
See the information on page 78.
1 Option. Not available in all markets.
Contents
2
01
01 Quick guide
Getting started............................................ 8
02
02 Getting to know your
navigation system
This manual............................................... 14
Before you begin....................................... 15
DVDs and the screen................................ 17
System overview ...................................... 20
Navigation system controls...................... 23
Voice control............................................. 26
On-screen keyboard................................. 29
Maps, types of roads and the compass... 32
Main menu, Scroll menu........................... 35
Menu selections........................................ 37
03
03 Planning your trip
Setting a destination................................. 42
Itinerary..................................................... 49
Current position........................................ 52
Settings..................................................... 53
Demo........................................................ 61
Contents
3
04
04 Traffic information
Introduction............................................... 64
Reading information.................................. 66
Dealing with traffic problems.................... 68
05
05 Symbols on the map
Points of interest (POIs)............................ 72
06
06 Questions & Answers
Frequently asked questions...................... 76
EULA – License agreement....................... 78
Contents
4
07
07 Index
Index......................................................... 82
Contents
5
6
Getting started.......................................................................................... 8
Q U I C K G U I D E
01 Quick guide
Getting started
01
8
Activating the system
With the ignition switched on (see the section
"Ignition modes" in the Owner's Manual):
1. Press the remote key fully into the ignition
slot to activate ignition mode I.
2. If the navigation system does not start
within a few seconds, press NAV on the
center console control panel.
Disclaimer
When the system is started, it displays the
following text, which must be confirmed:
•Press the OK button.
For additional information, see page 15.
NOTE
The system can be used even when the
engine is not running. To help avoid bat-
tery drain, the system should be turned off
when it is not in use.
Demo mode (simulated guidance)
The system has a Demonstration mode that
can be used to help acquaint you with the
navigation system, see page 61.
Navigation system options
The Volvo Navigation System can be oper-
ated in several ways:
•With the right side steering wheel keypad
•With the controls in the center console
•With a remote control
•With voice commands
See page 23 for a description of the func-
tions.
The navigation system also contains options
for adjusting map, guidance, and system set-
tings. For detailed information, see page 53.
Main commands
The controls in the steering wheel keypad are
used in both of the following examples (Guid-
ance to a street address and Guidance to
Points of Interest (POI)).
•Navigate and make selections by turning
the thumb wheel (1).
•Confirm a selection by pressing the
thumb wheel (written in the following
examples as "+ OK").
•Go back in the menus or cancel by press-
ing EXIT.
Controls in the center console
The following apply if the center console con-
trols are used instead of the steering wheel
keypad:
