Vortex Pro Binocular Adapter Manuale utente
INCLUDED:
a. Adapter Post
b. Threaded Stud
c. 1.3mm Allen Wrench
d. 2.0mm Allen Wrench
INSTRUCTIONS:
1. Remove cap covering the binocular tripod adapter socket.
2. Insert the threaded stud into the binocular tripod adapter
socket and tighten using the 2.0mm Allen wrench.
DO NOT OVERTIGHTEN.
3. Using the 1.3mm Allen wrench, tighten the set screw in
the threaded stud. DO NOT OVERTIGHTEN.
4. Attach adapter post to the tripod plate utilizing the
tripod’s 1/4-20 mount.
5. Mount the binoculars to the tripod by inserting the
threaded stud into the adapter post. Tighten by hand
using the locking knob until secure.
a.
c.
d.
b.
M-00292-0
© 2021 Vortex Optics
® Registered Trademark and TM Trademark of Vortex Optics
VIP WARRANTY
OUR UNCONDITIONAL PROMISE TO YOU.
We promise to repair or replace the
product. Absolutely free.
Unlimited
Unconditional
Lifetime Warranty
service@VortexOptics.com • 1-800-4VORTEX
Note: The VIP Warranty does not cover loss,
theft, deliberate damage, or cosmetic damage
not affecting product performance.
For the most up to date manual, visit
VortexOptics.com
