VXI BlueParrott B250-XT Manuale utente
Compatible with most Bluetooth phones & Bluetooth enabled computers (Windows®or Macintosh®)
USER GUIDE
3
TABLE OF CONTENTS
VXi BlueParrott®B250-XT+ User Guide
4Package Contents
5Safety Instructions/
Glossary
6Charging the Headset
7Battery Power Indicators
8Headset Controls
9On/Off/Standby
10 Pairing with a Phone
11 Pairing with a Computer
12 Multiple Device Pairing
13 Multipoint Mode
15 Proximity Pairing
16 Microphone Positioning
17 Making a Call
18 Answering a Call
19 Operation While Using the
Charger/Adapter
20 Additional Functions
Last Number Redial
Rejecting a Call
Voice Dial
Transfer Audio
Turn Indicator Lights
On/Off
Automatic Bluetooth
Connection
22 Reset Paired Devices List
23 Call Waiting/
Rejecting a Call
24 Specifications
25 Functions & Indicators
29 Warranty
30 FCC Notice to Users
31 IC Notice to
Canadian Users
VXi BlueParrott®B250-XT+ User Guide
4
PACKAGE CONTENTS
1
2
4 5
1. B250-XT+ Wireless Headset
with Leatherette Ear Cushion
2. Windscreen
3. Foam Ear Cushion
4. Auto (DC) Charger
5. AC Charger
6. User Guide (not shown)
3
5
VXi BlueParrott®B250-XT+ User Guide
SAFETY INSTRUCTIONS / GLOSSARY
SAFETY INSTRUCTIONS
• Avoidhearingdamage.Setvolumeatlowestcomfortablelevel.Ifyouexperienceringinginyourearsorvoices
sound muffled, stop using the headset. Avoid turning up volume to block noisy surroundings (it’s possible to
adapt to volume that is too high).
• Checkwithlocalandstatelawsregardingcellphone/headsetusagewhileoperatingamotorvehicle.
• Donotimmerseanypartofthisproductinwater.
• Plasticbagsandsmallpartsmaycausechokingifingested.Keepthemawayfromsmallchildrenandpets.
• Useonlythepowercordsincludedwiththisproduct.
• Avoidtemperaturesexceeding140°F(willcauseequipmentfailure).
GLOSSARY OF TERMS
On: Headset is on, but there is no connection to the phone (red light will flash).
MFB: Abbreviation for “Multifunction Button.”
Multipoint Mode: Multipoint Mode allows you to pair and switch between two Bluetooth devices.
Paired: Two Bluetooth devices agree to communicate with one another.
Standby Mode: Headset is on, Bluetooth link is active, and the user is not on a call (blue light will flash).
Talk Mode: Headset is in use with the cell phone while the cell phone is on an active call (blue light will flash).
VXi BlueParrott®B250-XT+ User Guide
6
CHARGING THE HEADSET
Connect charger cord into the headset’s
charging port. The MFB’s indicator light
may turn green for several seconds while
the headset determines the level of charge
the battery is holding. Do not remove the
headset from the charger. If the headset is
not fully charged, the indicator will turn RED
within a short period (less than 3 minutes).
When the indicator turns green—and stays
green—the unit is fully charged. A fully
discharged battery will need approximately
3.5 hours to achieve a complete charge.
AC Charger
Headset Charging Port
Auto (DC) Charger
7
BATTERY POWER INDICATORS
While charging, the MFB’s indicator light shows the
level of battery power on your B250-XT+ as follows:
Green light: Fully charged. Over 20 hours’ talk
time.
Red light: Less than a full charge.
For best performance, keep charging headset when
not in use.
VXi BlueParrott®B250-XT+ User Guide
Indicator Light
8VXi BlueParrott®B250-XT+ User Guide
HEADSET CONTROLS
Volume Increase: Quickly press and release
the Volume Up/Mute button. Repeat until
desired volume is attained.
Volume Decrease: Quickly press and release
the Volume Down button. Repeat until desired
volume is attained.
Microphone Mute/Un-Mute: While in
standby or on a call, hold down the Volume
Up/Mute button for 2 seconds until you hear a
beep. A mute reminder will be heard every 10
seconds. Repeat button press to un-mute.
Multifunction Button (MFB) &
Indicator Lights
Volume Up / Mute
Volume Down
9
ON / STANDBY / OFF
VXi BlueParrott®B250-XT+ User Guide
Turn Headset On: Hold down the MFB for approximately 2–3 seconds until you hear a voice
prompt, “Power on.” The red light will flash once every second.
Standby Mode: Once the headset is turned on (after the initial pairing), it will attempt to connect
to the last device that it was paired with, putting itself into standby mode. (The headset can also
beputintostandbymodewithaquickpressandreleaseoftheMFB).Thebluelightwillflashindi-
cating an active Bluetooth link. The headset will have a voice prompt, “Your headset is connected.”
Turn Headset Off (conserves battery power): Hold down the MFB for approximately 4–5 seconds
until you hear a voice prompt, “Power off.” A red light will flash 4 times and the headset will turn off.
VXi BlueParrott®B250-XT+ User Guide
10
PAIRING WITH A PHONE
Keepheadsetandphonenolessthan3inchesandnomorethan3feetapartwhilepairing.Keep
other Bluetooth devices at least 50 feet away, or turn them off. NOTE: The headset can be paired
with up to 8 different devices but can only be connected to one at a time. It can only switch back
and forth between 2 devices in Multipoint Mode.
1. Turn headset off (page 9).
2. Hold down the headset’s MFB until the lights alternate red and blue or you hear the audio
prompts “Power On” and then “Discovering.” IMPORTANT: Wait for both audio prompts or the
alternating blue and red lights. This may take up to 10 seconds. Then release the MFB.
3. Put your cellular phone into Bluetooth Search/Scan Mode per the manufacturer’s instructions.
4. Wait while the devices discover each other: This could take up to 2 minutes. Once the phone
discovers the headset, select “Pair” on the phone and enter a pass code of “0000” if in-
structed. Once pairing is complete the alternating lights will stop flashing and the phone may
prompt you to connect to the headset. Select “Yes” on the phone to connect to the headset.
When connected, you will hear the voice prompt, “Your headset is connected,” and the blue
light will flash indicating that the headset is in Standby Mode and is ready to make or receive
calls.
