Wacom INTUOS 4 Manuale utente

General speciﬁcations for all Intuos4 tablets

Resolution 5,080 lpi

Pressure levels 2,048

Accuracy (pen) +/- 0.25 mm (0.010 in)

Accuracy (lens cursor) +/- 0.15 mm (0.006 in)

Tilt range (all pens) +/- 60 degrees

(+/- 50 degrees on Intuos4 S tablets)

Reading height 10 mm (0.39 in)

Maximum report rate 200 points per second

Interface USB 1.1 to USB mini-B

(Intuos4 S, M and L tablet models)

USB 1.1 (Intuos4 XL)

Bluetooth 2.1 + EDR (Intuos4 Wireless)

Cable length 2.5 m (8.2 ft), detachable on S, M, Wireless

and L tablet models

Power requirements DC 5V, less than 300 mA, from primary USB

port or powered USB hub

Certiﬁcation FCC class B, CE, VCCI Class B, BSMI,

and compliance C-Tick, MIC, GOST-R, RoHS EU, Chinese

RoHS, Industry Canada Class B

Intuos4.

The pen tablet generation for photo-

graphers, illustrators, 3D-designers

and ﬁne artists who want to release

their full creative potential.

Discover why it sets new

benchmarks for the whole pen

tablet category:

• Natural: New Wacom Tip Sensor

with 2,048 levels of pressure

sensitivity

• Flexible: Ambidextrous design

• Comfortable: User-deﬁned Touch

Ring with toggle functionality

• Individual: 8 customisable

ExpressKeys™ including

OLED-displays on M, Wireless, L

and XL tablet models

• Intuos4 Wireless: Easy

connection to any Bluetooth

enabled computer while moving

freely up to 33 ft (approx. 10 m)

• Well-equipped: Grip Pen with

pen stand, colour identiﬁcation

rings, thick-bodied replacement

grip, 5 standard nibs, 1 stroke nib,

1 ﬂex nib, 3 felt nibs

• New radial menus for fast access

to shortcuts

• Consistent: New surface

structure and design for easy

strokes

• Reliable: 2 years warranty

• State of the art: Supports

Microsoft® Windows® 7, Windows®

XP™(+SP2) and Windows® Vista |

Mac OS X 10.4.8 or higher

Killer instinct.

And where it comes to life.

Character designer: Matt Ciofﬁ

Intuos4 S tablet

157.5 x 98.4 mm (6.2 x 3.9 in)

309.0 x 208.0 x 12.0 mm

(12.2 x 8.2 x 0.5 in)

approximately

800 g (1.76 lb) approximately

no ExpressKey™ displays

PTK-440-EN/4 949268 614382

Intuos4 M tablet

223.5 x 139.7 mm (8.8 x 5.5 in)

370.0 x 254.0 x 12.0 mm

(14.5 x 10.0 x 0.5 in)

approximately

1.0 kg (2.2 lb) approximately

8, next to ExpressKeys™

PTK-640-EN/4 949268 614467

Intuos4 Wireless tablet

203.2 x 127.0 mm (8.0 x 5.0 in)

363.0 x 253.0 x 15.0 mm

(14.3 x 10.0 x 0.6 in)

approximately

900 g (2.0 lb) approximately

(with battery)

8, next to ExpressKeys™

PTK-540WL-EN/4 949268 615402

Intuos4 L tablet

325.1 x 203.2 mm (12.8 x 8.0 in)

474.0 x 320.0 x 14.0 mm

(18.6 x 12.6 x 0.5 in)

approximately

1.8 kg (3.96 lb) approximately

8, next to ExpressKeys™

PTK-840-EN/4 949268 614542

Intuos4 XL tablet

462.0 x 304.8 mm (19.2 x 12.0 in)

623.0 x 462.0 x 28.0 mm

(24.5 x 18.2 x 1.1 in)

approximately

3.0 kg (6.60 lb) approximately

8, next to ExpressKeys™

PTK-1240-D/4949268 614368

(DTP model) & PTK-1240-C/

4949268 614320 (CAD model)

Available as DTP or CAD model.

Active area (W x D)

Physical size (W x D x H)

Weight

Touch Ring

ExpressKeys™

ExpressKey™ displays

Product Code / EAN Code

Wacom Europe GmbH • Europark Fichtenhain A9 • 47807 Krefeld • Germany • www.wacom.eu

names are trademarks and/or registered trademarks of their respective owners. Modiﬁcations and errors excepted.

BRO-I4DCC-EN

Intuos4 Airbrush

(optional accessory)

162.5 x 17.5 x 32.5 mm

(L x W x D)

(6.40 x 0.69 x 1.28 in)

23 g (0.81 oz)

approximately

1 standard nib,

1 stroke nib,

1 ﬂex nib,

1 felt nib.

ﬁngerwheel

approx. 1,024 levels

of resolution

KP-400E

4949268790512

Intuos4 Inking Pen

(optional accessory)

151.5 x 12.5 mm (L x D)

(5.97 x 0.49 in)

12 g (0.42 oz)

approximately

2 standard nibs,

3 inking cartridges.

KP-130

4949268790536

Intuos4 Art Pen

(optional accessory)

156.2 x 15.5 x 15.8 mm

(L x W x D)

(6.15 x 0.61 x 0.62 in)

20 g (0.7 oz)

approximately

2 chisel-shaped

standard nibs,

2 chisel-shaped

felt nibs, 3 standard art

nibs, 3 felt art nibs.

360 degrees

of barrel rotation

KP-701E

4949268790529

Intuos4 Classic Pen

(optional accessory)

150.7 x 12.2 mm (L x D)

(5.94 x 0.48 in)

12 g (0.42 oz)

approximately

1 standard nib,

1 stroke nib,

1 ﬂex nib,

1 felt nib.

KP-300E

4949268790505

Intuos4 Lens Cursor

(optional accessory)

159.0 x 66.0 x 33.8 mm

(L x D x H)

(6.26 x 2.60 x 1.33 in)

75 g (2.65 oz)

approximately

Supplied as standard

with Intuos4 XL CAD

model.

KC-210

4949268790482

Physical size

Weight

Includes

Additional feature

Product Code /

EAN Code

Intuos4 Grip Pen

156.5 x 14.9 mm (L x D)

(6.17 x 0.59 in)

18 g (0.63 oz)

approximately

thick-bodied

replacement grip, box

content S, M, Wireless,

L, XL (DTP version):

5 standard nibs,

1 stroke nib, 1 ﬂex nib,

3 felt nibs; box content as

accessory: 1 standard

nib, 1 stroke nib, 1 ﬂex

nib, 1 felt nib.

KP-501E

4949268790499

Intuos4 Mouse

(optional accessory)

102.9 x 61.8 x 38.6 mm

(L x D x H)

(4.05 x 2.43 x 1.52 in)

83 g (2.9 oz)

approximately

5 mouse buttons

and 1 ﬁnger wheel

KC-100

4949268790475
