Wagan 2450 Manuale utente

Item No. / Artículo No: 2450

Cordless Spotlight Compressor™

with Emergency Car Starter

con Encendedor de autos para emergencias

User’s Manual / Manual de Usuario

We are constantly improving our products so speciﬁcations are subject to change

without notice. Visit our website for the latest product information.

Estamos mejorando nuestros productos constantemente, por lo tanto, las

especiﬁcaciones están sujetas a cambios sin previo aviso. Visite nuestro sitio

web para obtener la información más reciente de los productos.

Cordless Spotlight Compressor™ by Wagan Tech®

1www.wagan.com

1. Durable Rubber Housing

2. Air Pressure Gauge

3. Power Switches

4. Adjustable Spotlight

5. 12 V DC Socket

6. 3-LED Reading Light

7. Air Hose Compartment

8. Air Hose

Wagan Tech and wagan.com are trademarks used by Wagan Corporation.

User’s Manual—Read before using this equipment

www.wagan.com

Thank you for purchasing the Cordless Spotlight Compressor™ by

Wagan Tech®. With normal care and proper treatment, it will provide years

of reliable service. Please read and understand all instructions before using

this unit. Failure to follow all instructions listed below may result in electric

shock, ﬁre and/or serious personal injury.

Features

• 260 PSI high power air compressor

• Accurate air compressor gauge

• Recharge and start an auto battery in minutes

• Super bright adjustable-angle ﬂashlight

• 3 LED reading light

• Use as a power source for many electronic appliances

GENERAL SAFETY RULES

KEEP THIS PRODUCT OUT OF REACH OF CHILDREN and SAVE THESE

INSTRUCTIONS FOR FUTURE REFERENCE.

• Do not operate this product in explosive atmospheres, such as in the

presence of ﬂammable liquids, gases, or dust. The battery can create

sparks which may ignite the dust or fumes.

• Do not abuse the DC or AC adaptors. Never use the adaptors to carry

the unit. Keep cords away from heat, oil, sharp edges, or moving

parts. Replace damaged cords immediately. Damaged cords may

create a ﬁre.

Cordless Spotlight Compressor™ by Wagan Tech®

3www.wagan.com

Use and Care

• Check for misalignment or binding of moving parts, breakage of parts,

and any other condition that may affect the operation of the unit. If

damaged, have the unit serviced before using.

• During operation, the unit may feel warm. Discontinue its use if it

becomes too hot.

• Battery operated products with integral batteries must be recharged

only with the speciﬁed charger for the battery. A charger that may be

suitable for one type of battery may create a risk of ﬁre when used

with another battery.

Service

• The battery is not intended to be removed from the unit by the user.

• The halogen and LED bulbs are not designed to be removed by users.

Do not attempt to change or modify them.

• The service of this unit must be performed only by qualiﬁed repair

personnel. Service or maintenance performed by unqualiﬁed

personnel may result in risk of injury.

DANGER SHOCK HAZARD! Keep battery charger and adapter away from

water and other liquids. Never operate if cord is damaged or product is not

working properly. Unplug when not in use.

SPECIFIC SAFETY RULES

• The compressor needs to be charged before the ﬁrst use. See the

section “Recharging the unit” for more details.

• Before attempting to start a vehicle, this unit must be removed from the

vehicle’s 12 V socket. See the section “Using the Jumper” for details.

Wagan Tech and wagan.com are trademarks used by Wagan Corporation.

User’s Manual—Read before using this equipment

www.wagan.com

• The unit is designed to recharge 12 V batteries with a low voltage

between 10.4 and 10.5 volts. If the vehicle’s battery is severely

drained, call a service center or tow truck.

• Do not attempt to reverse the polarity of the unit. 25A fuses are used

in a protection system which regulates the discharge and recharge of

this unit.

• For optimum performance, store in temperatures between 32°F–110°F

(0°C–43°C). Temperatures below 45°F (7°C) and above 85°F (30°C)

will require at least an additional 10 minutes of recharging before

starting engine.

• Car Alarms: If you have a car alarm, put it into “valet mode” before

attempting to use the unit. Many popular car alarm models cut off the

power to the vehicle’s electrical system. The unit will not work while

this type of alarm is engaged.

OPERATION

Using the Air Compressor

CAUTION: Check item to be inﬂated for manufacturer’s recommended

maximum inﬂation pressure. Avoid over inﬂation. Most tires are properly

inﬂated between 24–35 PSI. Some truck and bicycle tires require 40 PSI

or more.

A. To Inﬂate Tires:

1. Open the air hose storage compartment (lifting up the spotlight

lantern) and extend the air hose.

2. Make sure locking thumb lever is at up position. If necessary, use

valve stem adapter. Insert stem connector to valve stem and press

down the locking thumb lever to engage. Make sure connector is

pushed to valve stem as far as possible.

Cordless Spotlight Compressor™ by Wagan Tech®

5www.wagan.com

3. Set the compressor on/off switch to “ON” by changing from

position “O” to “—”.

4. Monitor pressure on air pressure gauge.

5. When desired pressure is reached, turn off the compressor.

6. Turn the locking thumb lever to up position and remove stem

connector from valve stem. Also remove the valve stem adapter.

7. Store the compressor hose in its storage compartment.

Note: In the event that the tire is completely ﬂat, raise the vehicle

using a recommended jack before inﬂating the tire.

B. To Inﬂate Plastic Inﬂatable Products

(recreational balls, air mattresses, rubber rafts, etc.):

1. Check manufacturer’s speciﬁcation on item to be inﬂated for

correct inﬂation pressure.

2. Open the air hose storage compartment (lifting up the spotlight

lantern) and extend the air hose.

3. Make sure locking thumb lever is at up position. If necessary, use

valve stem adapter. Insert stem connector to valve stem and press

down the locking thumb lever to engage. Make sure connector is

pushed to valve stem as far as possible.

4. Insert other end of valve stem adapter into inﬂatable air valve stem

as far as practical.

5. Set the compressor on/off switch to “ON” by changing from

position “O” to “—”.

6. Monitor pressure on air pressure gauge.

7. When desired pressure is reached, turn off the compressor.

Wagan Tech and wagan.com are trademarks used by Wagan Corporation.

User’s Manual—Read before using this equipment

www.wagan.com

8. Turn the locking thumb lever to up position and remove stem

connector from valve stem. Also remove the valve stem adapter.

9. Store the compressor hose in its storage compartment.

Using the Jumper

IMPORTANT: Before attempting to start vehicle, this unit must be removed

from the vehicle’s 12 V socket.

1. Turn off all lights and all other accessories (radio, etc) in the vehicle.

Tip: keep one small vehicle light or dial turned on to aid in determining

if the battery is charging.

2. Make sure the vehicle’s 12 V Socket is clean and free of debris.

3. Put the lighted end of the male-to-male car power cord into the

vehicle’s 12 V socket.

4. Put the end of the male-to-male 12 v car power card with no LED light

into unit’s 12 V socket.

5. The indicator light on the 12 V connector will illuminate indicating

that the power is ﬂowing. The light or dial left on in the vehicle should

brighten as well. Leave the unit connected to the vehicle’s 12 V socket

for about 35 minutes.

6. If the light or dial does not brighten, turn the ignition key ONLY as

far as the accessory position (see vehicle owner’s manual.) In some

vehicles, this is necessary for the 12 V socket to operate.

7. If the light or dial still does not brighten, turn off the light or dial, and

allow this unit to remain on the 12 V socket for at least 35 minutes.

Remove it from the 12 V and attempt to start the vehicle.

8. If the vehicle does not start, DO NOT attempt to start the engine more

that twice. Call a service center or tow truck.

Cordless Spotlight Compressor™ by Wagan Tech®

7www.wagan.com

Using as a DC 12 V Power Source

• The compressor’s 12 V DC Power Socket mimics the 12 V socket of a

vehicle.

• Any accessory you would normally plug into your vehicle’s 12 V socket

(cell phone, digital camera, ﬂashlight, radio, etc.) can be powered

from the compressor’s 12 V socket, using the compressor’s built-in

battery as the power source.

• This unit’s 12 V DC socket is center pin positive (+). Most 12 V DC

accessories come with this conﬁguration, but not all. Before connecting

any accessory to the compressor’s 12 V socket, check the accessory

owner’s manual for the polarity of the accessory.

• If the accessory is center pin positive, simply plug it into the 12 V

socket.

• For the DC accessories that are NOT center pin positive, you must use

a DC to DC adapter (not included).

Using the Spotlight or the LED reading light

A. Spotlight: locate the on/off switch on the handle of the unit. Change it

from “O” to “I” position.

B. LED Reading light: locate the on/off switch on the handle of the unit.

Change it from “O” to “II” position.

Note: The halogen and LED bulbs are not designed to be removed by

users. DO NOT attempt to change or modify them.

Wagan Tech and wagan.com are trademarks used by Wagan Corporation.

User’s Manual—Read before using this equipment

www.wagan.com

RECHARGING THE UNIT

Recharging from a 12 V DC Source

(Car, Truck, Boar, 12 V DC Charger)

Important: Do not leave this unit plugged into the 12 V socket when the

vehicle is not running as it may drain power from the car battery. When

charging in a vehicle, leave the engine running or charge while driving.

1. Connect the DC adaptor in the unit’s charging socket.

2. Connect the other end of the adaptor in the vehicle’s 12 V socket

(cigarette lighter) and let it charge for about 8 to 10 hours.

Recharging from an AC Power Source

1. Connect the AC adaptor in the unit’s charging socket.

2. Connect the other end of the adaptor to any household wall outlet. Let

the unit charge for about 25 to 27 hours.

Note: The Wagan Cordless Spotlight Compressor should be charged at least

once every 4 months regardless of usage to maintain charge. Draining a

lead acid battery completely will damage the battery. This is not covered by

the warranty if this occurs. Led acid batteries do not have memory, so the

unit can be charged periodically.

Cordless Spotlight Compressor™ by Wagan Tech®

9www.wagan.com

SPECIFICATIONS

Power Supply Battery Two 6V, 6AH lead-acid batteries

Power Supply DC Output 12 volts nominal

Air Compressor 260 PSI

Power Supply Boost Rate 300 amp peak

Power Supply Charging Time • 28 hours for the ﬁrst time

charging with AC charger

• 24–26 hours to recharge

with AC charger

• 8–10 hours to recharge

with 12 V DC charger

Altri manuali per 2450

Indice

Lingue:

Altri manuali Wagan compressore d'aria

Wagan

Wagan 2253 Manuale utente

Wagan

Wagan 2253 Manuale utente

Wagan

Wagan Quick Flow 2020 Manuale utente

Wagan

Wagan 2050 Manuale utente

Wagan

Wagan Quick Flow 3-in-1 Air Compressor Manuale utente

Wagan

Wagan Dynamite Power Air Compressor Manuale utente

Wagan

Wagan SKU 47801 Manuale utente

Wagan

Wagan Quick Flow 3-in-1 Air Compressor Manuale utente

Wagan

Wagan 2450 Manuale utente

Wagan

Wagan 7312 Manuale utente

Wagan

Wagan 2262 Manuale utente

Wagan

Wagan 3-In-1 Air Compressor with Inflator/Deflator Manuale utente

Wagan

Wagan 2592 Manuale utente

Wagan

Wagan Hi Speed Air Compressor Manuale utente

Wagan

Wagan 9916 Manuale utente

Wagan

Wagan Hi Speed Air Compressor Manuale utente

Wagan

Wagan 2450 Manuale utente

Wagan

Wagan 2014 Manuale utente

Wagan

Wagan Cordless Spotlight Compressor Manuale utente

Manuali compressore d'aria popolari di altre marche

Sparmax

Sparmax DC-25XR Manuale utente

KAESER

KAESER M122 Manuale utente

GMC

GMC GAC1500 Manuale utente

Briggs & Stratton

Briggs & Stratton Air Compressor Manuale utente

Fini

Fini F3GST2TK Manuale utente

Industrial Air

Industrial Air CP1580325 Manuale di programmazione

Campbell Hausfeld

Campbell Hausfeld RP3300 Guida rapida

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manuale utente

Hitachi

Hitachi EC99S Manuale dell'operatore

Parkside

Parkside PKO 270 A1 Manuale utente

Sullair

Sullair 185 Manuale utente

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manuale utente

Ferm

Ferm CRM1046 Manuale utente

BE AC153 Manuale utente

RIDGID

RIDGID OF25150A Manuale utente

Johnson Controls

Johnson Controls QUANTUM LX Manuale

Sears

Sears Craftsman 919.167463 Manuale utente

Ring Automotive

Ring Automotive RAC700 Manuale utente
