WaterQuest 14' Square Stern Manuale utente

WaterQuest

Canoe Models:

14’

14’ Square Stern

15.6’ Deluxe

15.6’ Square Stern

OWNER’S MANUAL

1790 Sun Dolphin Drive

Muskegon, Michigan 49444

phone 231-733-2725

fax 231-739-4502

email [email protected]

website www.klindustries.com

The Perfect Family Recreational Canoe

Congratulations on the recent purchase of your new WaterQuest canoe! You have purchased a canoe from one of the nations leading

manufacturers of small boats. Your canoe represents years of commitment to product design, excellence in engineering and quality in

manufacturing. With proper care and maintenance your canoe should last for many years to come. Please call our helpful and knowledgeable

Customer Support Department if you have any questions or concerns.

MATERIALS

Your canoe is manufactured from High Density Polyethylene (HDPE). It is a very durable material. Our specially formulated HDPE has an

ultra-violet inhibitor blended throughout the material to reduce color fade and maintain its strength. Polyethylene is a somewhat flexible

material with some memory. This means it has a tendency to return to its original molded shape if distorteded.

BOAT SET-UP

Recommended Motor & Battery

Square Stern models come equipped with a built-in motor transom designed for an electric trolling motor.

Maximum motor size: 40 lb. thrust standard shaft length.

Many trolling motors come with “alligator clips” or “ring connectors” for direct connection to a battery.

Recommended battery: 12 Volt DC.

NOTE: Be sure to connect the same color wires together. The RED wire on the plus is positive (+) and the BLACK wire is

negative (-). Consult the trolling motor instructions for more details or call Customer Service.

Important: Motors should always be removed when transporting or storing.

Battery Location

The battery may be placed either between the back seat and the stern of the boat or behind the center seat. It is recommended

securing the battery to the boat with a strap.

Paperwork

The following documents should come with your new canoe.

Warranty Registration Card

To properly register your boat with KL Industries for warranty validation please fill out the warranty registration form online

at www.klindustries.com. Please review our full warranty statement. If you are unable to register your boat online please contact our

Customer Support Department at 231-733-2725. The serial number can be found on the outside of the hull in the back just under the

gunwale. See Photo #1.

Photo #1 Serial Number

Location

Manufacturers Statement of Origin (MSO)

Some states may require a MSO for proper registration of your canoe. Please check with your local dealer or state licensing bureau.

Owners Manual

Keep your owner’s manual for future reference. It is a good idea to write down the following information:

Serial Number ________________________________________________

Date of Purchase ______________________________________________

Purchased from ______________________________________________

Applying Decals

Before applying boat registration decals (if required), clean the area with alcohol or any solvent that does not leave a residue. Make sure solvent is

put aside and is dry. Using a propane torch, lightly pass the flame back and forth over the area where the decals will be applied. Don’t try to heat

the surface. This process will enhance the adhesion of the decals.

BEFORE LEAVING SHORE & SAFETY PROCEDURES

• It is recommended to keep paddles onboard even if you are using a motor.

• Make sure the battery weight is distributed evenly onboard.

• Check the weather conditions especially wave conditions in open water. Anticipate changing weather conditions and act

accordingly.

• Review the maximum capacities on the capacity plate. Ensure you are safely within these limits.

• Make sure all passengers are wearing Personal Flotation Devices.

• Take an extra paddle.

• Let someone know where you are going and when you will return.

CARE AND MAINTENANCE

With minimal care and maintenance, your boat has been designed to provide you with many years of enjoyment.

• Your canoe can be cleaned with warm water and any standard detergents. More difficult stains, such as brackish watermarks, may be cleaned

with a petroleum based cleaner. Read the manufacturers' instructions carefully before using any cleaner.

• Periodically check the integrity of all fasteners to ensure proper use.

• Polyethylene is a somewhat flexible material with some memory. This means it has a tendency to return to its original molded shape if distorted.

If this occurs follow these steps:

1. Relieve the pressure that caused the dent or distortion by supporting the boat differently or removing gear.

2. Place the boat in the warm sun. Usually the south side of a building is the warmest spot. As the boat warms up usually (but not always) the

boat will return to its original molded shape. This may take a few hours or a couple of weeks depending upon outside temperatures and the

degree of distortion.

STORAGE

• If possible, it is best to store your canoe inside for the winter otherwise store upside down. Do not store the canoe on sawhorses right side up. If

it’s stored upside down, position the supports about 1/3 of the way in from each end. Do not pile gear on top of the canoe.

• Motors should always be removed when storing.

OPTIONAL ACCESSORIES

ITEM # ITEM DESCRIPTION

ACPDBK Paddles (set of 2)

This durable and lightweight paddle will help you get where you’re going.

It has an aluminum shaft with T-handle and an extra tough blade.

Order online at www.klindustries.com Paddles

Please have serial number available when ordering.

PARTS LIST

CANOE 15.6' DELUXE AND SQUARE BACK

ITEM # PRODUCT DESCRIPTION

3913 Rivet for End Cap (requires 10 per end cap)

3914 Rivet for End Cap (requires 1 per end cap)

11880 End Cap - square back

4054 Transom - black (square back only, requires 2)

1635 Black Canoe Rub Rail (requires 2, must ship via truck)

3913 Rivets for Rub Rail (requires 14 per side)

11882 Canoe Bow Seat

3936 Bolt (requires 4)

3849 Nut (requires 4)

11884-85 Canoe Mid Seat W/Lid

3936 Bolt (requires 4)

3849 Nut (requires 4)

11885 Cooler Lid

0229 Latch, Canoe Center Seat

12024 Bolt for latch (requires 1)

0098 Nut for latch (requires 1)

12505 Plug (requires 2)

11883 Canoe Stern Seat

3936 Bolt (requires 4)

3849 Nut (requires 4)

5164 Deck plate - 4" dry storage

15001 Waterquest Decal - Side

CANOE 14' STANDARD AND SQUARE BACK

ITEM # PRODUCT DESCRIPTION

11881 End Cap (deluxe requires 2, square back requires 1)

3913 Rivet for End Cap (requires 10 per end cap)

3914 Rivet for End Cap (requires 1 per end cap)

11880 End Cap - square back

4054 Transom - black (square back only, requires 2)

1636 Black Canoe Rub Rail (requires 2, must ship via truck)

3913 Rivets for Rub Rail (requires 14 per side)

21841 Canoe Bow Seat

3936 Bolt (requires 4)

3849 Nut (requires 4)

21840 Canoe Mid Seat W/Lid

3936 Bolt (requires 4)

3849 Nut (requires 4)

12505 Plug (requires 2)

21841 Canoe Stern Seat

3936 Bolt (requires 4)

3849 Nut (requires 4)

15001 Waterquest Decal - Side

Comfortably

molded

seats aid in

flotation

Rugged

UV-stabilized

Fortiflex®High

Density

Polyethylene hull

Drink

holders

molded into

every seat

Cooler under

center seat

Protective

rubrail

Bow and stern

tie-down eyelets

Built-in

transport

handles

Dry storage

holds wallets,

sunglasses,

jewelry, cell

phone,

cameras, etc.

Specifications

Length 15’6” 472 cm

Width 42” 107 cm

Height 18.5” 47 cm

Weight 95 lbs. 43 kg

Capacity 800 lbs. 363 kg

Comfortably

molded

seats aid in

flotation

Rugged

UV-stabilized

Fortiflex®High

Density

Polyethylene

hull

Drink

holders

molded into

every seat

Cooler under

center seat

Protective

rubrail

Bow tie-down

eyelets

Built-in

transport

handles

Dry storage

holds wallets,

sunglasses,

jewelry, cell

phone,

cameras, etc.

Motor is not

standard. Can

be added as an

option.

Specifications

Length 15’6” 472 cm

Width 42” 107 cm

Height 18.5” 47 cm

Weight 97 lbs. 43 kg

Capacity 800 lbs. 363 kg

Please Choose Your Model

15.6’ Deluxe Canoe 15.6’ Square Stern Canoe

Comfortable

molded

seats aid in

flotation

Rugged

UV-stabilized

Fortiflex®High

Density

Polyethylene hull

Drink

holders

molded into

every seat

Protective

rubrail

Bow and stern

tie-down eyelets

Built-in

transport

handles

Specifications

Length 14’ 472 cm

Width 38” 97 cm

Height 15.5” 39 cm

Weight 84 lbs. 38 kg

Capacity 765 lbs. 347 kg

Comfortable

molded

seats aid in

flotation

Rugged

UV-stabilized

Fortiflex®High

Density

Polyethylene

hull

Drink

holders

molded into

every seat

Protective

rubrail

Bow tie-down

eyelets

Built-in

transport

handles

Motor is not

standard. Can

be added as an

option as a

Sturdy square

back transom

Please Choose Your Model

14’ Canoe 14’ Square Stern Canoe

Six built-in rod

holder locations.

Six built-in rod

holder locations

Specifications

Length 14’ 427 cm

Width 38” 97 cm

Height 15.5” 39 cm

Weight 84 lbs. 38 kg

Capacity 765 lbs. 347 kg

WARRANTY

Please call us at 231-733-2725 if you have questions or a problem with your boat. Do not return the boat to the

retailer.

KL Industries, Inc. warrants to the original owner of any KL Industries boat. Any part of the boat that is defective in

material or workmanship will be repaired, without charge, at the purchasers’ local dealer or at KL Industries.

For personal use, this warranty shall apply for a period of two years on the deck and hull and two years on parts from

the date of retail sale. Any warranties from suppliers of component parts supersede KL Industries’ warranty. This warranty

covers use under normal conditions and does not cover damage caused by accidents, alteration, or misuse.

Freight to and from a local dealer or manufacturing plant is at the owners’ expense.

Warranty is not valid unless registration card is returned within 30 days of retail purchase.

Warranty

Rev.2 3/11
