Webasto Black Forest ThrowBack Top Manuale utente

Thank you for your recent purchase of your new Webasto ThrowBack Top for Jeep Wrangler

Hardtop. Be sure to thoroughly read the installation instructions prior to installation.

The Webasto ThrowBack Top for the Jeep Wrangler Hardtop is intended to be used as an

everyday shield from weather conditions. This top is not intended for structural protection in

the event of an accident or roll over situation. Refer to your Jeeps owner’s manual for further

information about proper safety restraints. Always wear your seatbelt per manufacturers

recommendations and state laws.

It is strongly recommended to have two people available to assist with the installation

of the Webasto ThrowBack Top.

ThrowBack Top - Installation Instructions

Jeep Wrangler (JK) – 2 / 4 Door

2007 - 2017

ThrowBack Top Installation

Language

ENGLISH .………………………………………………………………………………….…………4

ESPAÑOL …………………………………………………………………………….…….……....13

FRANÇAIS ……………………………………………………………….....................................25

Contents

KIT CONTENTS................................................................................................................... 4

REQUIRED TOOLS.............................................................................................................. 4

INSTALLATION................................................................................................................... 5

OPERATION ....................................................................................................................... 8

CARE AND MAINTENANCE ............................................................................................. 10

LIMITED NON-TRANSFERABLE WARRANTY ................................................................... 11

ThrowBack Top Installation

Kit Contents

Required Tools

Tool Description


1/4in or 3/8in Ratchet or Bit Driver - (Also included in

optional Jeep Tool Kit)

T30 Torx® socket (1/4in or 3/8in drive)

Utility Knife

Safety Glasses (always wear proper safety equipment)

Ladder / Step Stool

Part Part Number Image Qty.

ThrowBack Top Assembly 5010061

M8 x 1.25 x 70mm Retainer Bolts

5012477

Hold Back Straps 5012479

Product Literature 5010763

ThrowBack Top Installation

Installation

For installation video please visit www.blackforestgear.com.

Step Image Description

Carefully remove the Webasto ThrowBack Top

from its packaging. Be sure to save the shipping

box and related materials for optional storage

of the Jeep Freedom Panels explained later in

step 12.

Remove Jeep Freedom Panels per the

manufacturer’s recommendations.

Steps 3-6 are for the Jeep Wrangler 4-Door only. Skip to step 7 if installing your

Webasto ThrowBack Top on a Jeep Wrangler 2-Door.

Locate the rearmost sport bar hole as shown.

This can be located by feeling through the sport

bar padding approximately 2 ¾” (70mm)

forward of hard top edge.

On the top side of the sport bar padding make

a ½” slit to allow for the ThrowBack retainer

bolt to pass-through during the following steps.

Gain access to the underside of the rear sport

bar hole. Remove the sport bar padding from

both B-pillars by gently lifting upward.

ThrowBack Top Installation

Step Image Description

Unzip and pull padding forward enough to

access the underside of described hole.

It is recommended to have two people available

to assist with this step. Carefully place the

complete ThrowBack Top into place as shown.

Using the supplied M8 bolts and previously

removed mushroom knobs, secure the

ThrowBack Top in the following sequence from

the underside the of the top. Torque M8 bolts

to 5 Nm. or 44.25 in-lbs.

Re-check M8 bolts periodically to ensure proper

torque.

1-2

3-4

5-6

Front / Sport Bar

Rear / Sport Bar

Rear / Mushroom Knobs

ThrowBack Top Installation

Step Image Description

Reinstall sport bar padding in the reverse

order of removal (steps 5 & 6).

NOTE: 4 door model only

10.

Unclip the Sun Visors and move them out of

the way. Locate the two windshield header

latches; adjust the latch handle to the full

open position to allow for engagement of

the windshield loop.

11.

Pivot each latch forward to close and secure

each latch assembly. Re-clip the Sun Visors

back into position.

12.

The Webasto ThrowBack Top packaging is

designed to stow your Jeep Freedom Panels

while not in use. Insert the supplied Freedom

Panel spacer into place as shown. Carefully

position your Freedom Panels and close lid.

This packaging is not designed to be

stackable.

Spacer

ThrowBack Top Installation

Operation

OPEN THROWBACK TOP

Image Description

Unclip the Sun Visors and move them out of the

way. Release the header latches from the

windshield loops but pulling on the buckles.

Using the ThrowBack Top front rail; lift the top up

and back towards the rear of the vehicle.

If you’re expecting a bumpy ride, wrap the

supplied Velcro® straps around each side

mechanism assembly as shown to prevent an

accidental top closure.

ThrowBack Top Installation

CLOSE THROWBACK TOP

Image Description

Be sure to remove the Velcro® straps before

attempting to close the top and stow for future

use.

Unclip the Sun Visors and move them out of the

way. Using the ThrowBack Top front rail; lift the

top up and forward towards the front of the

vehicle.

Locate the two windshield header latches; adjust

the latch handle to the full open position to allow

for engagement of the windshield loop.

Pivot each latch forward to close and secure each

latch assembly.

ThrowBack Top Installation

CARE AND MAINTENANCE

WASHING:

Use a mild soap with minimum suds, warm water, and a brush with soft bristles. DO NOT use

harsh cleaners or bleaching agents on top material, as damage may result.

RINSING:

Be sure to remove all traces of cleaner by rinsing the top thoroughly with clean water.

Remember to allow the top to dry before opening it.

-Do not use an automatic car wash or high pressure car wash with ThrowBack top

installed.

-Do not open the ThrowBack Top with temperatures below 41°F (5°C). Damage to the

top may occur.

-Do not attempt to operate the vehicle until the top has been fully attached to the

windshield frame or is fully opened.

-When removing frost, snow or ice, never use a scraper or de-icing chemicals on fabric

top.
