Wells H-115 Manuale utente

WELLS

R A I S I N G T H E S T A N D A R D

H-33 AND H-115

HOTPLATES

WE L L S M A N U F A C T U R I N G

H-33 AND H-115 HOTPLATES

Wells Hotplates H-33 and H-115 are

dependable and easy-to-use. Flat, spiral elements

provide a wider cooking area for more surface

contact and are self-cleaning. Drip trays are easily

removable for cleaning.

I T E M N O .

Features

• The six-inch diameter, flat, spiral elements

allow for more surface contact.

• The elements are self-cleaning.

• Drip trays are chrome-plated and removable

for easy cleaning.

• An infinite control switch with positive-off position

controls the element.

• Control knobs are front-mounted with a

protective guard ring to help prevent accidental

temperature changes.

• The H-33 and H-115 Hotplates are Underwriters

Laboratories, Inc. LISTED and meet the National

Sanitation Foundation and Canadian standards.

• A one-year warranty against defects covers

parts and labor.

Accessories / Options

Legs, set of four, metal, 4” adjustable, 20563

Legs, set of four, plastic, 1", 21109

Specifications

Dimensions: Inches MM

Overall Dimensions (H-33):

Width 12 5/8 321

Depth 12 5/8 321

Height (incl. 4” legs) 10 254

Overall Dimensions (H-115):

Width 14 3/4 375

Depth 23 9/16 598

Height (incl. 1” legs) 7 178

Temperature Settings: OFF/LO to HI

Number of Controls: Model Number

H-33 1

H-115 2

Weights: Lbs. KG

H-33:

Installed 11 5

Shipping 14 6

H-115:

Installed 18 8

Shipping 21 10

H-33

ID WLS0-413 SPEC SHEET 7/3/00, 9:33 AM1

* *

R

R

R

R

H-33 120 1500 12.5 SINGLE NEMA 5-15P

H-115 120 1650 13.8 SINGLE NEMA 5-15P

MODELS VOLTS WATTS AMPS PHASE POWER SUPPLY CORD

WELLS

A SP E CIA LT Y EQU I P M E NT C OM PA N Y • 20 00 WE L LS M ANUFA CTU R I N G • P R I NTE D IN T H E U.S . A.

6/00 • REV(H) • PART NO. 38859

WELLS MANUFACTURING COMPANY

2 ERIK CIRCLE, PO BOX 280, VERDI, NV 89439 U.S.A.

USA PHONE: (775) 689-5700 • FAX: (775) 689-5972

FOR ORDERS ONLY: (888) 356-5362 • FAX: (800) 356-5142 • www.wellsbloomfield.com

MODELS

H-33, H-115

H O T P L AT E S

WE L L S M A N U F A C T U R I N G

POWER

SUPPLY

CORD

POWER

SUPPLY

CORD

MODEL H-33

MODEL H-115

14 3/4

(375)

23 9/16

(598)

12 5/8

(321)

12 5/8

(321)

6

(152)

6

(152)

4

(102)

1

(25)

H - 3 3 A N D H - 1 1 5 E L E C T R I C A L S P E C I F I C AT I O N S :

NOTE: Specifications are subject to change without notice.

DIMENSIONS:

LISTED STD.4 LR 10836

E6070

INCH

(MM)

ID WLS0-413 SPEC SHEET 7/3/00, 9:33 AM2
