Western Digital My DVR Expander Manuale utente

External Storage

•Easy to set up, easy to use – Just plug it in to your

eSATA-enabled DVR and start recording even more TV shows,

sporting events, and movies.

• Compatible – My DVR Expander has been tested for

compatibility with Scientific Atlanta 8300 series and has been

TiVo verified™ compatible with TiVo®Series3™ and TiVo®HD

DVRs. Check with your cable service provider to confirm

compatibility with their system.

• Quiet and Cool – A unique no-fan passive cooling system and

special hard drive design makes it quiet for the living room or

bedroom.

•Low–intensity LED – Designed with a soft amber LED

indicator, ideal for the living room or bedrooms.

My DVR Expander

Record More TV Shows

Quiet and Cool

Instant Storage

Record more, delete less –

Never miss your favorite show.

*Not intended to be an archival or portable storage device. The DVR Expander is designed to expand the recording capacity of

a single DVR. The total program hours that can be stored depends upon the format and data rate of the programming source,

operating environment and other factors. Your results may vary.

Record more – delete less. Add My DVR Expander from

WD to your eSATA-enabled DVR and you’ll instantly add

space for up to 120 hours of high-definition or 600 hours of

standard definition TV.*

Physical Specifications

Product Specifications

Product Dimensions

Packaging Specifications

Retail UPC Codes

500 GB 1 TB

Formatted capacity 500,107 MB 1,000,204 MB

Usersectors perdrive 976,773,168 1,953,525,168

Data transferrate 3 Gb/s (maximum)

RoHS compliant

Yes

Limited warranty

1 year

Height 6.78 in. (172.2 mm)

Length 5.63 in. (143.0 mm)

)mm7.65(.ni32.2htdiW

Weight 2.9 lb. (1.32 kg)

English Metric

Retail box size

Face Width 11.625 in295.3 mm

mm3.411ni5.4htpeDflehS

mm2.302ni0.8thgieHecaF

Retail box weight (max) 4.55 lb. 2.06 kg

Mastercartonsize 19.19 inx 11.94 inx 8.88 in487.43 mm x 303.28 mm x 225.55 mm

Mastercartonweight 19.40 lb 8.80 kg

44no

tracretsamrepsegakcaP

0404tellaprepsnotracretsaM

Pallet load size 48 in. x 40 in. x 49.4 in. 1219 mm x 1016 mm x 1255 mm

Pallet load weight 826 lb 374.67 kg

ZN/SUAACIREMANAP

Capacity

Order Number UPC Code Order Number UPC Code

500 GB WDG1S5000VN 7 18037 12306 6

1 TB WDG1S10000VN 7 18037 74560 2 WDG1S10000VA 7 18037 74561 9

Environmental Specifications

Power Specifications

Operating temperature5°Cto35°C

Non-operating temperature –20°C to 65°C

AC input voltage 100–240V

AC input frequency 47–63 Hz

As used for storage capacity, one megabyte (MB) = one million bytes, one gigabyte(GB) = one billion bytes, and one terabyte

(TB) = one trillion bytes. Total accessiblecapacity varies depending on operating environment. As used for buffer or cache, one

megabyte (MB) = 1,048,576 bytes. As used for transfer rate or interface, megabyte per second (MB/s) = one million bytes per

second, and gigabit per second (Gb/s) = one billion bits per second. Effective maximum SATA 3 Gb/s transfer rate calculated

according to the Serial ATA specification published by the SATA-IO organization as of the date of this specification sheet. Visit

www.sata-io.org for details.

WD hard drive products manufactured and sold worldwide after June 1, 2006, meet or exceed Restriction of Hazardous

Substances (RoHS) compliance requirements as mandated by the European Union for electrical and electronic products. The

RoHS Directive 2002/95/EC of the European Parliament, which is effective in the EU beginning July 1, 2006, aims to protect

human health and the environment by restricting the use of certain hazardous substances in new equipment, and consists of

restrictions on lead, mercury, cadmium, and other substances.

The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital, WD, and the WD logo are registered

trademarks inthe U.S. and othercountries; and

My DVR Expanderis a trademark of Western Digital

Technologies, Inc. Othermarks may be mentioned

hereinthat belong to othercompanies. Product

specifications subject to change without notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California U.S.A. 92630

4879-705015-A03 Apr2009

800.

ASK

WDC

North America

800.832.4778 Spanish

+800.6008.6008 Asia Pacific

00800.27549338 Europe

(toll free where available)

+31.880062100 Europe/Middle East/Africa

My DVR Expander
