Western Digital Scorpio Blue WD1200BEVE Manuale utente

WD Scorpio Blue

Interface

Width/Height

Rotational Speed

Capacities

Model Numbers

EIDE Drives

WD2500BEVE

WD1600BEVE

WD1200BEVE

WD800BEVE

WD600BEVE

To make drive selection simple, we’ve gathered all our popular 5400 RPM

WD Scorpio drives under one umbrella we call WD Scorpio Blue. Built to

Western Digital’s awarding winning quality standards, these drives are

available in a full range of performance features.

Product Features

Massive capacity — Whether they are in an external drive or a notebook computer,

320 GB WD Scorpio Blue 2.5-inch drives offer the most available capacity for

space-hungry operating systems like Windows Vista™, plus plenty of room left over for

photos, music, and video.

Quiet — In a notebook drive, silence is golden. WD’s exclusive WhisperDrive™

combines state-of-the-art seeking algorithms to yield one of the quietest 2.5-inch hard

drives on the market. These algorithms also optimize the way a drive seeks for data,

which significantly improves power consumption. So now silence (and longer battery

life) is golden.

Reliable and Rugged — WD’s ShockGuard™technology protects the drive

mechanics and platter surfaces from shocks. WD’s SecurePark™parks the recording

heads off the disk surface during spin up, spin down and when the drive is off. This

ensures the recording head never touches the disk surface resulting in improved

long-term reliability due to less head wear and improved non-operational shock

tolerance.

Fast and efficient — With 5400 RPM spin speed, 12 ms access time, and up to

3 Gb/s SATA interface speed, even the most demanding customer will appreciate the

performance achieved by WD Scorpio Blue drives.

Tested for Compatibility — We perform tests on hundreds of systems and a

multitude of platforms in our FIT Lab™and Mobile Compatibility Lab to give our

customers confidence that our drives will work in their systems.

WD Scorpio Blue is part of WD's complete lineup of mobile hard drives.

WD Scorpio®

Blue

Mobile Hard Drives

Big capacity for

performance computing

SATA or EIDE

2.75 in./0.37 in.

69.85 mm/9.5 mm

Note: Not all products may

be available in all regions of

the world.

40 to 320 GB

5400 RPM

SATA Drives

WD3200BEVT

WD2500BEVS

WD1600BEVS

WD1200BEVS

WD800BEVS

WD600BEVS

WD400BEVS

™

WD Scorpio Blue

Drive Specifications

Performance Specifications

Limited Warranty6

40 GB 60 GB 80 GB 120 GB 160 GB 250 GB 320 GB

Formatted capacity140,020 MB 60,022 MB 80,026 MB 120,034 MB 160,041 MB 250,059 MB 320,072 MB

User sectors per drive 78,140,160 117,210,240 156,301,488 234,441,648 312,581,808 488,397,168 625,142,448

WD model number

SATA WD400BEVS WD600BEVS WD800BEVS WD1200BEVS WD1600BEVS WD2500BEVS WD3200BEVT

EIDE WD600BEVE WD800BEVE WD1200BEVE WD1600BEVE WD2500BEVE

SATA Hard Drives

Bytes per sector (STD) 512

Form factor 2.5-inch

Interface SATA 1.5 Gb/s

Interface (320 GB only) SATA 3 Gb/s

RoHS compliant2Yes

SATA Hard Drives

Average latency 5.5 ms

Cache

Read Adaptive

Write Yes

Data transfer rate

Buffer to disk 933 Mbits/s(maximum)3

Buffer to host 1.5 Gb/s (maximum)

Buffer to host (320 GB only) 3 Gb/s (maximum)

Drive ready time 4.0 sec (average)

Error rate (non-recoverable) <1 in 1014 bits read

Rotational speed 5400 RPM

Load/unload cycles5600,000

Limited warranty 3 years

EIDE Hard Drives

Bytes per sector (STD) 512

Form factor 2.5-inch

Interface 44-pin EIDE

RoHS compliant2Yes

EIDE Hard Drives

Average latency 5.5 ms

Cache

Read Adaptive

Write Yes

Data transfer rate (buffer to host)

Mode 5 Ultra ATA4100 MB/s

Mode 4 Ultra ATA466.6 MB/s

Mode 2 Ultra ATA433.3 MB/s

Mode 2 Ultra DMA416.6 MB/s

Mode 4 Ultra PIO416.6 MB/s

Buffer to disk 600 Mbits/s (maximum)

Drive ready time 4.0 sec (average)

Error rate (non-recoverable) <1 in 1014 bits read

Rotational speed 5400 RPM

Load/unload cycles5600,000

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital, WD, the WD logo, and

WD Scorpio are registered trademarks; in

the U.S. and other countries; and

WD Scorpio Blue, SecurePark, FIT Lab,

ShockGuard, and WhisperDrive are

trademarks of Western Digital

Technologies, Inc. Other marks may be

mentioned herein that belong to other

companies. Product specifications subject

to change without notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A.

2879-701278-A00 Jun 2008

800.ASK.4WDC North America

949.672.7199 Spanish

+800.6008.6008 Asia Pacific

+31.20.4467651 EMEA

WD Scorpio Blue

Mobile Hard Drives

1One gigabyte (GB) = 1,000,000,000 bytes. Total accessible capacity varies depending on operating environment.

2WD complies with the Restriction of Hazardous Substances (RoHS) Directive 2002/95/EC of the European Parliament, which is

effective in the EU beginning July 1, 2006. RoHS aims to protect human health and the environment by restricting the use of certain

hazardous substances in new equipment, and consists of restrictions on lead, mercury, cadmium, and other substances.

3Buffer to disk transfer rate for ML160 WDxxxxBEVS drives. WDxxxxBEVS ML125 drives have a buffer to disk transfer rate of 850 Mbits/

s max. ML80 WDxxxxBEVS/BEVE drives have a buffer to disk transfer rate of 600 Mbits/s max.

4Maximum burst rate running the specified PIO, DMA, or Ultra ATA transfer mode.

5Controlled unload at ambient condition.

6The term of the limited warranty may vary by region. Visit support.wdc.com/warranty for details.
