Enterprise Hard Drives

Interface

Width/Height

Rotational Speed

Capacities

Model Numbers

3.5-inch/1-inch

160 to 750 GB

WD7500AYYS

WD5001ABYS

WD5000ABYS

WD4001ABYS

WD4000ABYS

WD3201ABYS

WD1601ABYS

Note: Not all products

may be available in all

regions of the world.

With 1.2 million hours MTBF, 5-year limited warranty, 3 Gb/s SATA

technology, and enhanced vibration tolerance, WD RE2 drives offer an ideal

combination of reliability, high capacity, and optimum performance for

enterprise applications.

Product Benefits

Superior reliability - Designed and manufactured to provide server-class reliability in high

duty cycle environments. With 1.2 million hours MTBF, these drives have the highest available

reliability rating on a high-capacity drive.

High capacity - Up to 750 GB of storage packed with server-class features and low

cost-per-gigabyte value.

Fast - With a 3 Gb/s data transfer rate, native command queuing (NCQ), and 16 MB cache,

these drives deliver optimum performance.

RAID-specific, Time-Limited Error Recovery (TLER) - Significantly reduces drive fallout

caused by the extended hard drive error-recovery processes common to desktop drives.

Rotary Acceleration Feed Forward (RAFF™)- Provides enhanced vibration tolerance by

optimizing operation and performance when the drives are used in vibration-prone, multidrive

systems such as rack-mounted servers or network storage.

5-year limited warranty

Applications

Servers, network attached storage, scientific computing, life sciences, video surveillance,

enterprise backup, software build systems, document and image management, audio/video

media applications, other demanding write-intensive applications.

The WD Promise

WD understands the importance of the information you save to your hard

drive and we are committed to protecting that data with exceptionally reliable

products, advanced data protection technology, and superior customer support.

No one does more to safeguard your data than WD.

7200 RPM

SATA

WD RE2

Enterprise Hard Drives

Enterprise-class

1.2 million hours MTBF

24 x 7 reliability

Enterprise Hard Drives

For service and literature:

support.wdc.com

www.westerndigital.com

Western Digital, WD, and the WD logo are

registered trademarks in the U.S. and other

countries; and the FIT Lab logo and RAFF are

trademarks of Western Digital Technologies,

Inc. Other marks may be mentioned herein

that belong to other companies. Product

specifications subject to change without

notice.

Western Digital

20511 Lake Forest Drive

Lake Forest, California 92630

U.S.A

2879-701176-A11 Jun 2008

800.ASK.4WDC North America

949.672.7199 Spanish

+800.6008.6008 Asia Pacific

+31.20.4467651 EMEA

Drive Specifications

160 GB 320 GB 400 GB 500 GB 750 GB

Formatted capacity1160,041 MB 320,072 MB 400,088 MB 500,107 MB 750,156 MB

User sectors per drive 312,581,808 625,142,448 781,422,768 976,773,168 1,465,149,168

Model number WD1601ABYS WD3201ABYS WD4000ABYS WD5000ABYS WD7500AYYS

WD4001ABYS WD5001ABYS

Actuator latch/auto park Yes Yes Yes Yes Yes

Bytes per sector (STD) 512 512 512 512 512

Dedicated landing zone Yes Yes Yes Yes Yes

Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch

Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s

Native Command

Queuing Yes Yes Yes Yes Yes

RoHS compliant2Yes Yes Yes Yes Yes

1 One gigabyte (GB) = one billion bytes. One terabyte (TB) = one trillion bytes. Total accessible capacity varies depending on operating environment.

2WD products manufactured and sold worldwide after August 1, 2005, meet or exceed Restriction of Hazardous Substances (RoHS) compliance requirements as

mandated by the European Union for electrical and electronic products. The RoHS Directive 2002/95/EC of the European Parliament, which is effective in the EU

beginning July 1, 2006, aims to protect human health and the environment by restricting the use of certain hazardous substances in new equipment, and consists of

restrictions on lead, mercury, cadmium, and other substances.

3Effective maximum SATA 3 Gb/s transfer rate.

4Maximum drive capacity model.

5After 24 power-on hours.

6No non-recoverable errors during operating test or after non-operating tests.

720 KHz cutoff.

8Sound power level.

WD RE2

Enterprise Hard Drives

Environmental Specification6

Shock

Note: Half-sine wave, measured in 2 ms duration and without

isolation.

Vibration

Operating Temperature and Humidity

Non-Operating Temperature and Humidity

Acoustics (Average) 4

Operating (2 ms) 30G (write), 65G (read)

Non-operating (1 ms) 250G

Operating

Random 0.004 g2

/Hz (10 to 300 Hz)

0.008 g2

/Hz (300 to 500 Hz)

Linear 20–300 Hz, 0.75G (0 to peak)

Non-operating

Random 0.05 g2

/Hz (10 to 300 Hz)

0.01 g2

/Hz (300 to 500 Hz)

Linear 20–500 Hz, 4.0G (0 to peak)

Temperature 5°C to 55°C

Humidity 5–95% RH non-condensing

Thermal gradient 20°C/hour (maximum)

Temperature –40°C to 65°C

Humidity 5–95% RH non-condensing

Thermal gradient 30°C/hour

Idle mode 728 dBA

Performance seek mode834 dBA

Quiet seek mode 30 dBA

Performance Specifications

Physical Dimensions

Average latency 4.2 ms

Buffer 16 MB

Cache

Read Adaptive

Write Yes

Data transfer rate

Buffer to host33 Gb/s (maximum)

Buffer to disk498 MB/s (sustained)

Drive ready time 12.0 sec (average)

Error rate

(non-recoverable) <1 in 1015 bits read

LBA support Yes

MTBF51,200,000 hours

Rotational speed 7200 RPM

Seek time

Full stroke 21 ms (average)

Read 8.9 ms (average)

Track-to-Track 0.6 ms (average)

Limited warranty 5-year

Height 1.028 in (25.4 mm)

Length 5.787 in (147.0 mm)

Width 4.0 in (101.6 mm) ±0.01 in

Weight 4 1.61 lb (0.73 kg) ±10%
