PRO‑FLO™ 300W & PRO‑FLO™ 300H

Tailgate Spreaders

#30850, 30860

Owner's Manual and Installation Instructions

Original Instructions

This manual is for WESTERN®PRO‑FLO™ 300W & PRO‑FLO™ 300H tailgate spreaders with

serial numbers beginning with 150401 and higher.

CAUTION

Read this manual before installing or

operating the spreader.

Western Products, PO Box 245038, Milwaukee, WI 53224‑9538 • www.westernplows.com

Lit. No. 43755/43757, Rev. 05 3 September 1, 2021

TABLE OF CONTENTS

INTRODUCTION ....................................................... 5

Owner's Information Form .................................... 5

SAFETY ..................................................................... 6

LOADING ................................................................. 11

Certication......................................................... 11

Approximate Material Weights............................ 11

MOUNTING THE SPREADER............................... 12

Assembly Instructions......................................... 12

Receiver Mount Spreader................................... 13

ELECTRICAL DIAGRAM....................................... 14

OPERATING THE SPREADER ............................. 16

Driving and Spreading on Snow and Ice ............ 16

Ensuring that the Spreader has Power............... 18

Starting and Stopping Motor............................... 18

Spreading Tips.................................................... 18

REMOVING THE SPREADER............................... 19

WIRELESS CONTROL PROGRAMMING AND

PAIRING ............................................................... 20

MAINTENANCE ......................................................22

Lubrication ..........................................................22

After Each Use....................................................22

At the End of Each Season or

After Extended Storage ................................... 22

Fuse Replacement..............................................22

Storage ...............................................................22

TROUBLESHOOTING............................................ 23

Lit. No. 43755, Rev. 05 5 September 1, 2021

INTRODUCTION

This manual has been prepared to acquaint you with

the safety information, operation, and maintenance of

your new tailgate spreader. Please read this manual

carefully and follow all recommendations. This will

help ensure protable and trouble-free operation of

your spreader. Keep this manual accessible. It is a

handy reference in case minor service is required.

When service is necessary, bring your spreader to

your distributor. They know your spreader best and are

interested in your complete satisfaction.

NOTE: This spreader is designed to spread snow

and ice control materials only. Do not use it

for purposes other than those specied in this

manual.

OWNER'S INFORMATION

Owner's Name: ______________________________________________________________________

Date Purchased: _____________________________________________________________________

Distributor Name: __________________________________________ Phone:_________________

Distributor Address:___________________________________________________________________

Vehicle Model:_____________________________________________ Year: __________________

Spreader Model: _________________________ Serial #:__________________________________

Spreader Weight:_____________________lb/kg

Lit. No. 43755/43757, Rev. 05 6 September 1, 2021

SAFETY DEFINITIONS

NOTE: Indicates a situation or action that can lead

to damage to your spreader and vehicle or other

property. Other useful information can also be

described.

SAFETY

WARNING/CAUTION LABELS

Please become familiar with the warning and caution

labels on the spreader.

NOTE: If labels are missing or cannot be read, see

your sales outlet.

CAUTION

Indicates a potentially hazardous situation

that, if not avoided, may result in minor or

moderate injury. It may also be used to alert

against unsafe practices.

WARNING

Indicates a potentially hazardous situation

that, if not avoided, could result in death or

serious personal injury.

Lit. No. 43755/43757, Rev. 05 7 September 1, 2021

SAFETY

SERIAL NUMBER LABEL

Code Denition

YY 2‑Digit Year

MM 2‑Digit Month

DD 2‑Digit Day

LL 2-Digit Location Code

XXXX 4-Digit Sequential Number

ZZZZZZ Assembly Part Number

Model No. 00000

Serial No. YYMMDDLLXXXXZZZZZZ

Model No. 00000

Serial No. 000000000000000000

Lit. No. 43755/43757, Rev. 05 8 September 1, 2021

CAUTION

Disconnect electric and/or hydraulic power

and tag out if required before servicing or

performing maintenance.

CAUTION

DO NOT leave unused material in

hopper. Material can freeze or solidify,

causing unit to not work properly.

Empty and clean after each use.

NOTE: Lubricate grease ttings after each use.

Use a good quality multipurpose grease.

FUSES

The electrical system may contain several blade-

style automotive fuses. If a problem should occur

and fuse replacement is necessary, the replacement

fuse must be of the same type and amperage rating

as the original. Installing a fuse with a higher rating

can damage the system and could start a re. Fuse

Replacement is located in the Maintenance section of

this Owner's Manual.

SAFETY

SAFETY PRECAUTIONS

Improper installation and operation could cause

personal injury and/or equipment and property

damage. Read and understand labels and the

Owner's Manual before installing, operating, or making

adjustments.

WARNING

• Driver to keep bystanders minimum of

25 feet away from operating spreader.

• Before working with the spreader, secure all

loose-tting clothing and unrestrained hair.

• Before operating the spreader, verify that all

safety guards are in place.

• Before servicing the spreader, wait for

auger and spinner to stop.

• Do not climb into or ride on spreader.

WARNING

Overloading could result in an

accident or damage. Do not exceed

GVWR or GAWR ratings as found on

the driver‑side door cornerpost of

the vehicle. See Loading section to determine

maximum volumes of spreading material.

CAUTION

If rear directional, CHMSL light, or brake

stoplights are obstructed by the spreader,

the lights shall be relocated, or auxiliary

directional or brake stoplights shall be

installed.

CAUTION

During the hopper spreader installation

we recommend the addition of an OSHA

compliant Backup Alarm. This alarm is

required for OSHA governed employers.

CAUTION

• Do not operate a spreader in need of

maintenance.

• Before operating the spreader, reassemble

any parts or hardware removed for cleaning

or adjusting.

• Before operating the spreader, remove

materials such as cleaning rags, brushes,

and hand tools from the spreader.

• While operating the spreader, use auxiliary

warning lights, except when prohibited by law.

• Tighten all fasteners according to the

Torque Chart. Refer to Torque Chart for the

recommended torque values.

WARNING

Vehicles <10,000 lb GVWR: Obstructing

the visibility from the vehicle's rear camera

could result in serious injury or damage. An

auxiliary camera system shall be installed

if the vehicle's rear camera is removed or

blocked.

Lit. No. 43755/43757, Rev. 05 9 September 1, 2021

VENTILATION

BATTERY SAFETY

FIRE AND EXPLOSION

Be careful when using gasoline. Do not use gasoline

to clean parts. Store only in approved containers away

from sources of heat or ame.

CELL PHONES

A driver's rst responsibility is the safe operation of

the vehicle. The most important thing you can do

to prevent a crash is to avoid distractions and pay

attention to the road. Wait until it is safe to operate

mobile communication equipment such as cell phones,

text messaging devices, pagers, or two-way radios.

CAUTION

Batteries normally produce explosive gases

which can cause personal injury. Therefore,

do not allow ames, sparks, or lit tobacco

to come near the battery. When charging or

working near a battery, always cover your

face and protect your eyes, and also provide

ventilation.

• Batteries contain sulfuric acid which burns

skin, eyes, and clothing.

• Disconnect the battery before removing or

replacing any electrical components.

WARNING

Vehicle exhaust contains lethal fumes.

Breathing these fumes, even in low

concentrations, can cause death. Never

operate a vehicle in an enclosed area without

venting exhaust to the outside.

WARNING

Gasoline is highly ammable and gasoline

vapor is explosive. Never smoke while

working on vehicle. Keep all open ames

away from gasoline tank and lines. Wipe up

any spilled gasoline immediately.

SAFETY

PERSONAL SAFETY

• Remove ignition key and put the vehicle in PARK

or in gear to prevent others from starting the

vehicle during installation or service.

• Wear only snug-tting clothing while working on

your vehicle or spreader.

• Do not wear jewelry or a necktie, and secure long

hair.

• Wear safety goggles to protect your eyes from

battery acid, gasoline, dirt, and dust.

• Avoid touching hot surfaces such as the engine,

radiator, hoses, and exhaust pipes.

• Always have a re extinguisher rated BC handy,

for ammable liquids and electrical res.

Lit. No. 43755/43757, Rev. 05 10 September 1, 2021

CAUTION

Read instructions before assembling.

Fasteners should be nger tight until

instructed to tighten according to torque

chart. Use standard methods and practices

when attaching spreader including proper

personal protective safety equipment.

TORQUE CHART

1/4-20 10

1/4-28 12

5/16-1

50 212

5/16-2

70 240

3/8-16 269 376

3/8-24 29

7/16-1442

7/16-20

9/16-12

9/16-18

5/8-11

5/8-18

3/4-10

3/4-16

7/8-9

7/8-14 47

091-8

1-12 70

1/2-13

1/2-20

11.9

13.7

24.6

27.3

43.6

26.9

53.3

148

49.4

69.8

77.9

106.4

120.0

8.4

9.7

17.4

19.2

30.8

35.0

49.4

55.2

75.3

85.0

M6 x 1.00

M12 x 1.75

M8 x 1.25

M14 x 2.00

M10 x 1.50

M27 x 3.00

M22 x 2.50

M30 x 3.50

M24 x 3.00

M20 x 2.5011.1

19.5

38.5

107

7.7

613

778

1139

1545

450

428

562

796

1117

M33 x 3.50

M36 x 4.00

2101

2701

1468

1952

325

M16 x 2.00 231167

M18 x 2.50 318222

Recommended Fastener Torque Chart

Size Size

Torque (ft-lb)

Grade

Metric Fasteners Class 8.8 and 10.9

These torque values apply to fasteners

except those noted in the instructions.

Torque (ft-lb)

Grade

Size Size

Torque (ft-lb)

Class

8.8

Class

10.9

Torque (ft-lb)

Class

8.8

Class

10.9

Inch Fasteners Grade 5 and Grade 8

NOISE

Airborne noise emission during use is below 70 dB(A)

for the spreader operator.

VIBRATION

Operating snowplow vibration does not exceed

2.5 m/s2to the hand‑arm or 0.5 m/s2to the whole

body.

SAFETY

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Western Spargitore

Western

Western LOW-PRO 300 Istruzioni operative

Western

Western Striker 98805 Manuale utente

Western

Western PRO-FLO Manuale utente

Western

Western PRO-FLO 2 Manuale utente

Western

Western ICE BREAKER Hopper Spreader Manuale utente

Western

Western Drop 250 Istruzioni operative

Western

Western LOW-PRO 300G Istruzioni operative

Western

Western 110 Manuale utente

Western

Western Striker 98810 Manuale utente

Western

Western tornado Manuale utente

Western

Western WB-160D Istruzioni operative

Western

Western Tornado 78000-1 Manuale utente

Western

Western 1000 Manuale utente

Western

Western Striker Series Manuale utente

Western

Western ICE BREAKER Manuale utente

Western

Western WB-100B Istruzioni operative

Western

Western Striker 98825 Manuale utente

Western

Western PRO-FLO 2 Manuale utente

Western

Western LOW-PRO Istruzioni operative

Western

Western 78600 Manuale utente

Western

Western PRO-FLO Manuale utente

Western

Western Tornado 78000-1 Manuale utente

Western

Western tornado Manuale utente

Manuali Spargitore popolari di altre marche

PEQUEA

PEQUEA GT-100 Manuale utente

Herculano

Herculano H2RS9 Manuale utente

Epoke

Epoke SKE8 Manuale utente

GEA

GEA EL44 Scheda tecnica

Boss Snowplow

Boss Snowplow TGS 800 Manuale utente

Fisher

Fisher EMERSON 168 Series Manuale utente

Fisher

Fisher POLY-CASTER 78601 Manuale utente

TurfEx

TurfEx RS7200 Manuale del proprietario

Ferris

Ferris Pathfinder Series Manuale utente

Fayat Group

Fayat Group DYNAPAC S100 Guida alla risoluzione dei problemi

Art's-Way Manufacturing

Art's-Way Manufacturing X700 Manuale di installazione e funzionamento

EASTMAN

EASTMAN CR 500 Manuale utente

Nogueira

Nogueira RoyalFlow-600 Manuale utente

Buyers

Buyers TGS05B Manuale utente

Magnum

Magnum V-BOX PV Series Supplemento

Meyer's

Meyer's VB280 Manuale utente

SnowEx

SnowEx VX-4210 Manuale utente

Kramer

Kramer VM-400HDCP Manuale utente
