Westinghouse DPF-0804 Manuale utente

USER’S MANUAL

MANUEL DE L’UTILISATEUR

MANUAL DEL USUARIO

DPF-0804

Digital Photo Frame

Cadre Photo Numérique

Marco de Fotos Digitales

DPF-0804 UserCvr.indd 1DPF-0804 UserCvr.indd 1 2/20/2008 2:03:26 PM2/20/2008 2:03:26 PM

www.wde.com

Westinghouse Digital Electronics, LLC

Santa Fe Springs, CA SE-UM-0803-0801

DPF-0804 UserCvr.indd 2DPF-0804 UserCvr.indd 2 2/20/2008 2:03:36 PM2/20/2008 2:03:36 PM

TABLE OF CONTENTS

INSTALLATION / QUICK START…………………..…………...…..……………2

DIAGRAM OF THE DIGITALPHOTO FRAME...………………………………3

KEYPAD BUTTON FUNCTIONS...……..…………………………………………4

OSD MENU FUNCTIONS…………………………………….…………………….5

MOSAICVIEWTM AND ADDITIONAL FEATURES…………………………..…6

DIGITALPHOTO FRAME NAVIGATION…..……………....…………………...7

USING THE MINI-USB FOR FILE TRANSFER…..…………………….………8

SAVINGAND DELETING FILE FROM INTERNAL MEMORY..…….……….9

TECHINICAL SPECIFICATIONS…..…………………………………………...10

FREQUENTLY ASKED QUESTIONS….………………………………………..11

IMPORTANT SAFETY INSTRUCTIONS……………………………………….12

CLEANING THE DIGITALPHOTO FRAME…………………………………..14

PRODUCT WARRANTY….….……………………………………………………15

Congratulations on your purchase of a Westinghouse 8.0” LCD Digital Photo

Frame. We are excited to bring you a new experience in viewing your digital

memories. Contents include an AC/DC Power Supply Adapter and User’s

Manual. Please read carefully and follow all warnings and instructions in this

User's Manual and those marked on the product before you use the Digital

Photo Frame. Failing to follow warnings can result in personal injury or

damage to the Digital Photo Frame. Please keep this User’s Manual in a

convenient location for future reference.

Important: Save the original box and all packing material for future shipping

needs.

Quick Start

1. Plug the AC adapter into the Digital Photo Frame and plug it into a

power outlet.

2. Insert a memory card into one of the four slots:

Slot 1 - Compact FlashTM or Micro DriveTM

Slot2-SecureDigital

TM or MultiMedia CardTM, xD-Picture CardTM,

Memory StickTM, Memory Stick PROTM, Memory Stick DuoTM, or

Memory Stick PRO DuoTM

Or insert a USB Thumbnail Drive into the USB port.

Note: To view a sample of how the Photo Frame displays digital photos, simply

turn on the frame without inserting a memory card.

3. Turn on the Power Switch on the side of the Digital Photo Frame.

4. Once the Digital Photo Frame has turned on, it will enter into

MosaicViewTM Slide Show automatically.

5. To view photos individually, press the Exist button to enter

Thumbnail View. Using the Arrow Buttons (<<) and (>>), highlight a

photo and press the Play (4)button to view the image. To enter into

MosaicViewTM Slide Show again, click menu button, highlight “Start

Slide Show” option and then press the Play (4)button.

Note: To delete photos from the internal memory or save photos to the internal

memory, please refer to page 8 or 9.

Diagram of the Digital Photo Frame

Secure DigitalTM and Multi

Media CardTM Slot, xD-Picture

CardTM Slot, Memory StickTM,

Memory Stick PROTM, Memory

Stick DuoTM, and Memory Stick

PRO DuoTM Slot

Compact FlashTM and

Micro DriveTM Slot

Power Switch

AC Power Input

Mini USB Port for File Transfer

USB Port for USB Flash Drives

Keypad

ustable Stand

Keypad Button Functions

On Screen Display Functions

Note: To enter the On Screen Display (OSD), press the Menu button for

(except when in Slide Show). To exit the OSD, simply press the Exist button

again.

Button

Play

Command

Select

Down

Open OSD men

Exit Back to the previous page

Viewing Images Individually

Button Command

<< Go to Previous Image

Play

>> Go to Next Image

Menu Open OSD menu

ExitBack to Thumbnail View

Thumbnail View/ Select Mode Page / Card Select Page

Button Command

<< Left

Play Select

>> Right

Menu Open OSD menu

Exit Back to one page

Viewing Video Files

Button Command

<< Go to Previous Video File

Play Play / Pause Video File

>> Go to Next Video File

Menu Open OSD menu

Exit Exit to Video Selection Page

OSD Menu Functions

All function settings for the Digital Photo Frame can be controlled via the buttons located

on top of the Frame. You can access the On Screen Display (OSD) at any time, expect

when in Slide Show Mode or playing a video, by simply click the “Menu” button.

OSD Menu Sub-Menus Description and Function of Operation

MosaicViewTM Off Turning off MosaicViewTM will allow you to view

pictures one at a time during Slide Show.

Image Size Optimal Optimizes the picture to fill the whole space

Original Displays images in their original aspect ratio

Off

Fade

Shutter

Cross Comb

Mask

Brick

Dissolve

Slide Show Effect

Random

Select Style of Image Transition

3 Seconds

5 Seconds

10 Seconds

30 Seconds

Slide Show Speed

60 Seconds

Select Speed of Slide Show

OnSlide Show Shuffle Off This function allows images to be displayed in random

order.

One Selected video file will repeat continuously

All All video files will repeat continuously

Video Repeat

Off Selected video file will not repeat automatically

Start Slide Show - Unit will go into Slide Show

Copy File - This allows a file to be copied from a memory card into

the internal flash memory.

Delete File - This allows a file to be deleted from the internal flash

memory.

Rotate - Rotate photos

Zoom - Zoom in photos

Settings - Brightness/Contrast/Tint/Color/Display reset

Set Favorites - Select favorite pictures

Language -

Changes the OSD menu language: English, Italian,

German, French, Spanish, Portuguese or Dutch

Note: If a selection is grey, you will not be able to perform that function. For example, when you are

viewing pictures from a memory card, the Delete File option will be highlighted grey and will not be

available.

MosaicViewTM

What is MosaicViewTM?

MosaicViewTM is an exciting new technology developed by Westinghouse

which allows you to view multiple photos at the same time. MosaicViewTM

automatically detects different picture orientations and displays them randomly

through Slide Show.

How MosaicViewTM works:

With MosaicView™, up to 4 images can be displayed at the same time. Portrait

and landscape images are displayed in a random configuration such as a

portrait and two landscape photos or two portrait images displayed at the same

time.

The Slide Show is set to MosaicViewTM as the default setting. In addition, to

maximize the area of display, images are set to “Optimal” under “Image Size”.

Please note that some cropping of the images will occur in this mode. If you

wish to view the images in their original aspect ratio, select “Original” under

“Image Size” in the OSD. The images will maintain their native aspect ratio.

Starting a Slide Show

There are two ways of starting a Slide Show; one is pressing the play button

when viewing images individually, or by entering the OSD and selecting “Start

Slide Show”. (Note: If a memory card is inserted into the Digital Photo Frame,

selecting “Start Slide Show” will run a Slide Show of images contained in the

memory card.)

Additional Features

Setting Favorite Pictures

Marking an image as a Favorite allows you to see the image more often during

Slide Show. To do so, in Thumbnail View highlight a picture and enter the OSD

by hitting the Menu button. Select “Set Favorite” and a small check mark will

appear next to the image. To unmark a picture, repeat the same steps. When

MosaicViewTM is on, the selected favorite picture will appear individually during

slide show.

Slide Show Shuffle

Images are displayed in random order during Slide Show. You may turn this

feature “on” or “off” in the OSD under “Slide Show Shuffle”.

Rotate and Zoom

At anytime when you are viewing images individually, you can zoom or rotate a

picture. When viewing an image, push the Menu button to display the OSD.

Scroll down to Rotate or Zoom. By pushing the play button you will be able to

rotate or zoom the image.

Digital Photo Frame Navigation

Using the Play and Exist button, you will be able to advance or go back a Menu

Page within the Digital Photo Frame.

The top Menu Page is the “Select Card” Page. To enter this selection, press

the Exist button twice from Thumbnail View.

Select Card Page

SD / MMC / MS /MS Duo / XD

CF / MD

Built-in Memory

Selecting an option that is highlighted will take you to the next page.

Select Mode Page

Slide Show – Start Slide Show function

Photo – Selecting Photo will allow you to preview your photos through

Thumbnail View.

Video – Selecting “Video” will list all video files available for viewing.

Select a file and press the “Play” button to view. (No audio will be available.)

File – Selecting “File” will allow you to see information of a file.

Using the Mini-USB for File Transfer

The Digital Photo Frame comes with 128MB of built-in Flash Memory. Make

sure that the Frame is first turned off before connecting a USB cable (not

included) from a computer to the Digital Photo Frame and ensure that the

power supply is plugged into the Digital Photo Frame.

Turn on the Photo Frame. Once the computer has detected the Photo Frame,

you will be able to download compatible image or video files stored in your

computer or delete them from the internal memory of the Digital Photo Frame.

Disconnecting the Frame from a PC Computer:

1. Click the “Safely Remove Device” icon on the Task Bar located on the

bottom right corner of the computer Desktop.

2. A dialogue box (“Safely Remove Hardware”) will appear.

3. Select USB Mass Storage Device and click “Stop”.

4. On the next dialogue box, click “OK”.

5. On the final dialogue box, click “Close”. Now you can safely remove the

Digital Photo Frame.

The saved images will appear once you have turned off the Frame and turned

it back on.

Note: Attempting to disconnect the Digital Photo Frame without using

the “Safely Remove Device” procedure may cause the files in the internal

memory to be unreadable.

Indice

Altri manuali Westinghouse Cornice digitale

Westinghouse

Westinghouse DPF-0702 Manuale utente

Westinghouse

Westinghouse DPF0561 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0802 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-1021 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0802 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0801 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0702 Manuale utente

Westinghouse

Westinghouse DPF0561 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF0561 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-1021 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0703 Manuale utente

Westinghouse

Westinghouse DPF-0702 Manuale utente

Westinghouse

Westinghouse DPF-1411 - LCD Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0701 Manuale utente

Westinghouse

Westinghouse DPF-0802 - Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-1411 - LCD Digital Photo Frame Manuale utente

Westinghouse

Westinghouse DPF-0801 - Digital Photo Frame Manuale utente

Manuali Cornice digitale popolari di altre marche

LENCO

LENCO DF-830 Manuale utente

NIX

NIX Advance X10G Manuale utente

Nextar

Nextar N7S-100 Manuale utente

Sungale

Sungale TD350A Manuale utente

texet

texet DPF-830 Istruzioni per il montaggio

Philips

Philips SPF2017 Manuale utente

Philips

Philips SPF1327 Manuale utente

Philips

Philips SPF7010/10 Manuale utente

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Manuale utente

ViewSonic

ViewSonic VFM1042-52 Manuale utente

YURAKU

YURAKU YUR.PHOTO 7B4C Manuale utente

Denver

Denver PFF-710WHITE MK2 Manuale utente

Pandigital

Pandigital PAN8000DWPCF1 Manuale utente

Rekam

Rekam Deja View HD-850 Manuale utente

Majestic

Majestic DF 918HD MP3 Manuale utente

ViewSonic

ViewSonic DPF8-CAM Manuale utente

Philips

Philips SPF2527 Manuale utente

Digital Foci

Digital Foci Image Moments IMT-063 Manuale utente
