Westinghouse LTV-17v1 Istruzioni per il montaggio

Westinghouse Digital Electronics

POWER INDICATOR

KEYPAD

CONNECTION PANEL

CONGRATULATIONS on pur-

chasing a state of the art LCD

TV! This Quick Connect Guide

will help you get started in 3

easy steps. On the back you will

find information to maximize

your LCD TV experience.

For complete installation,

usage instructions, and

safety precautions please refer

to the User’s Manual.

17”

QUICK

CONNECT

GUIDE

CONNECT THE BASE

AND POWER

Attach Base Stand

to LCD Stand Neck

by aligning holes

and tabs, pressing in

and snapping into

place. Remove connection

panel dust cover on back of

LCD. Connect A/C Power to

power adapter kit by using

enclosed A/C power cable.

Insert smaller end of adapter

cord into DC 19V Input on con-

nection panel.

CONNECT THE

TUNER

Connect either analog cable or

TV antenna wire to the cable

ready NTSC tuner input labeled

“Antenna” on the connection

panel.

Note: this step can be skipped if

you do not use these options.

CONNECT A PC

Connect a PC to the VGA

connector and the 3.5 mm audio

cable to the audio input labeled

"Audio In" located on the

connection panel.

Press Power on the keypad to

turn on the LCD. The power

indicator on the front panel of

the LCD glows blue.

Note: If error message

"Input Signal Not Found" is

displayed the front panel of

the LCD glows orange.

www.westinghousedigital.com

REMOVABLE STAND FOR OPTIONAL WALL MOUNTING

LTV-17v1 LCD TV

23GO!

Digital Cable/

Satellite Receiver Good Better Best

DVD Player Good Better Best

Game Console Good Better Best

VCR Good Better Best

YPbPr

Video S-VideoTV Tuner

VIDEO INPUTS

MAXIMIZE

YOUR LCD TV

EXPERIENCE

You can attach your LCD TV to

a variety of electronic devices

including a digital cable or

satellite set top box, a game

console, a VCR, or a computer.

The chart shows our recom-

mendations for the best quality

picture for these commonly

used devices. If you have trou-

ble connecting these or other

devices, please refer to the

User’s Manual.

Audio Input

(R/L)

YPbPr /

S-Video In

(Component)

Antenna

Video In

TYPICAL SETUP

•Progressive scan DVD players with YPbPr

•Game console action using Video

•VCR viewing and editing with S-Video

PC RGB

Input

(Analog)

Audio

Input

Audio

Output

PC INPUTS

RGB

(VGA)

Monitor Best

DID YOU KNOW THAT

YOUR LCD TV ALSO HAS:

• Picture-in-Picture in VGA mode only

CHECK OUT

www.westinghousedigital.com for our:

• Versatile Wall Mounting options

reserved. Specifications subject to change without notice.

, Westinghouse and You can be sure... if it's Westinghouse are

trademarks of Westinghouse Electric Corporation and are used

under license.

MA-PS-0106-0401 www.westinghousedigital.com

•Set computer resolution to 1280 x 1024

Note: The audio input is shared between Video and S-Video.

Use the Source button on the remote

control or keypad to cycle between the

TV, S-Video, Video, YPbPr, or PC inputs.
