Westinghouse Component (YPbPr) connection Manuale utente

ADAPTER KIT PARTS

(INCLUDED)

CONNECTING

VIEWING

Purpose: If you have a source that requires Component connection (YPbPr) to your TV (e.g., DVD Player) then you will

need to use a VGA-Component Cable adapter kit. The following are step-by-step instructions to guide you through the set

up process. (Note: We recommend the use of Composite (Video/RCA) connection instead of component from most

analog sources; your Westinghouse TV employs superior video processing and will provide optimal video quality. Always

use HDMI when available.)

• 1 VGA-Component Cable

• 1 Mini-RCA Cable

For assistance call: 1-800-701-0680

STEP 1: Connect VGA-Component cable and Mini-RCA

audio cable to VGA port and PC audio port as shown

above.

EXAMPLE: DVD player connected via Component

(YPbPr).

STEP 2: After you complete connecting your device via

VGA-Component as shown is Step 1, Press the “Input”

button on the remote control to visibly see all your

input selections on the TV screen as shown.

STEP 3: Using the remote control, toggle and select

VGA-Component input. (Note, you are ready to begin

viewing content through the VGA-Component input.

The VGA input for PC is disabled and can be restored

using the input select function again.)

Mini RCA CableVGA-Component Cable

© 2013 Westinghouse Digital , LLC. All rights reserved. Speciﬁcations subject to change without notice. ¼and Westinghouse are trademarks of Westinghouse Electric Corporation.

MA-PS-0101-0102

COMPONENT (YPbPr) CONNECTION

Disconnect all power sources before making any connections

Débranchez toutes les sources d'énergie avant d'établir tous les rapports

Desconecte todas las fuentes de energía antes de hacer cualesquiera conexiones

Refer to User Manual for complete installtion instructions

Référez-vous au manuel d'utilisateur pour des instructions complètes d'installtion

Reﬁera al manual de usuario para las instrucciones completas del installtion

VGA-COMPONENT
