Whirlpool ADP 8623 Manuale utente

5019 100 91141

(We reserve the right to make technical modifications)

PROGRAMME CHART

ADP 8623

1) Programme recommended when using detergents of type A (non enzyme-based detergents).

2) Programme recommended when using detergents of type B (enzyme-based detergents).

Reference programme for Test Institute and energy label.

*) Values for normal conditions. Values may vary in relation to usage, e.g.: different loads, water temperatures, water hardness and power supply voltage.

Rinse aid level indicator

Add rinse aid.

Salt level indicator

Add regeneration salt.

Programme progress indicator

Pre-wash

Only lights up for programmes with prewash

(the symbol “+” in the table below indicates that

detergent must be added).

Rinse / Washing

Drying

Programme end

Half Load / Multizone button

Load the upper or lower rack only.

This function can be used with any programme.

Press once = upper rack

Press twice = lower rack

Press 3 times = Off (half load function

deactivated).

Delayed start button

Starts the dishwasher at the set time.

It is possible to programme a delay of

3 - 6 - 9 hours.

Start button indicator lamp

Switches on when the dishwasher is operating.

Flashes when a fault occurs.

Switches off at the end of the programme.

Programme

Symbol and

temperature

Load

Crockery and cutlery

Detergent Consumption *

Normal load Consumption *

Half load

Pre-wash

(small

compartment)

Pre-wash

(large

compartment)

Water

(Liter) Energy

(kWh) Time

(Min.) Time

(Min.) Energy

(kWh) Time

(Min.)

Prewash Crockery to be washed later. - - 5,0 0,02 9 4,2 0,02 9

Rapid 40° C Lightly soiled crockery with no dried-on food. - + 13,0 0,85 30 13,0 0,75 30

Eco 50° C 2) Normally or heavily soiled crockery with dried-on food. + + 17,0 1,35 85 14,2 1,28 83

Universal 65° C Normally soiled crockery. - + 13,0 1,45 73 11,0 1,38 71

Normal 65° C 1) Normally or heavily soiled crockery. + + 21,0 1,64 93 17,0 1,55 90

Intensive 70° C Normal or heavily soiled, pans and saucepans. + + 21,5 1,70 93 18,2 1,60 90

Quick Reference Guide GB

Crockery holders:

•Down: cups and long-stemmed

glasses.

•Up: plates.

Glass holder:

•The glass holder can be moved

sideways.

•Below: small glasses.

•Above: long-stemmed glasses.

Half Load / Multizone button:

If only the upper rack is to be loaded,

remove the cutlery basket from the

lower rach and place it in the upper

one.

Height adjustment:

(The dishwasher is delivered with the

upper rack in the top position).

The rack height can also be changed

when loaded.

•To lower: pull out the two side

handles and gently lower the rack.

•To raise: pull up the two side

handles until the rack clicks into

place.

•The rack must be level on both

sides.

Lower rack

Half Load / Multizone button:

Loading the lower rack only: greater

washing power, particularly for plates

and saucepans.

Cutlery basket:

The cutlery basket can be removed to

increase available space.

Plate holders:

•The plate holders may be removed

to increase available space.

•To remove: pull the handle up.

•To reposition: simply insert in the

required position (normal or

crosswise).

Daily check list

1. Arrange crockery so that items do

not touch each other.

2. Load cups at an inclination to

facilitate water circulation.

3. In general, place the cutlery in the

basket with the handles positioned

downwards, but ensure that sharp

knives and forks that might cause

injury are placed in thebasket with the

handles positioned upwards.

4. Make sure the water jet can reach

all loaded items and that the spray

arms turn freely.

5. Turn on the water supply tap before

starting the dishwasher.

Important:

•Switch off the dishwasher: once the

“Start”indicator lamp has

switched off. If you switch off the

dishwasher during a wash cycle,

when switched on again the

dishwasher resumes the cycle from

where it was interrupted.

•If a fault occurs or you wish to

change the current programme,

press the “START”button for about

5 seconds until the Start indicator

lamp switches off ! Refer to the

“Troubleshooting Guide”in these

user instructions to remedy any

problems.

•If regeneration salt is to be

added, IMMEDIATELY start a

washing programme, to

eliminate any residual salt.

Upper rack
