TOP AND CABINET PARTS
1
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
5−06 Litho in U.S.A. (drd) Part No. 8181315
AUTOMATIC
WASHER
TOP AND CABINET PARTS
2
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10044800
Installation
Instructions
3955884 Use & Care Guide
3957874 Feature Sheet
W10023650
Energy Guide
8578911 Wiring Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
4313896 Manual, Washer
2 Top
8543451 White
8543452 Biscuit
3 62750 Spacer, Cabinet To
Top (4)
4 357213 Nut, Push−In (2)
5 Cabinet
63424 White
3954357 Biscuit
6 62780 Clip, Top & Cabinet
& Rear Panel (2)
7 8566266 Dispenser, Bleach
8 3351614 Screw, Ground
9 3357011 Screw, 10−16 x 1/2
10 9724509 Bumper, Lid (2)
11 8318084 Switch, Lid
12 3390631 Screw,
10−16 x 3/8 (4)
13 355274 Screw, Lid Hinge
Mounting (4)
14 21097 Pad, Lid Hinge (2)
15 8559336 Hinge, Lid (L.H.)
16 91770 Hinge, Lid (R.H.)
17 8319539 Bearing, Lid
Hinge (2)
18 Lid
8580057 White
8580058 Biscuit
CONTROLS AND REAR PANEL PARTS
3
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
4
CONTROLS AND REAR PANEL PARTS
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 3976300 Washer, Water
Inlet Hose (4)
(1−1/16 x 5/8)
2 3400073 Screw, Ground
3 Hose, Water
Inlet (2)
8571377 Blue Coupler
8571378 Red Coupler
4 9740848 Screw, 8−18 x 1/2
5 8568314 Strap, Console (2)
6 8318015 Panel, Rear
7 62747 Pad, Rear Panel
8 8559373 Drain Hose
Assembly (Includes
Items 27 & 28)
9 8577356 Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
10 3351614 Screw, Ground
11 90767 Screw, 8−18 x 3/8
12 8577844 Switch, Water Level
13 8544893 Bracket, Control
14 3956162 Cord, Power
(Includes Item 15)
15 3952821 Strain Relief,
Power Cord
16 Cap, End (L.H.)
8271365 White
8271368 Biscuit
17 8572717 Capacitor,
Motor Start
18 8578343 Valve, Water Inlet
W/Bi−Metal
20 8318046 Clip, Capacitor
21 301958 Clamp, Hose
22 8317974 Hose, Vacuum
Break
23 370450 Clamp, Hose
24 387606 Break, Vacuum
25 303294 Edge Protector
26 8519200 Support, Rear
Panel
27 8541667 Clamp, Hose
28 8541668 Clamp, Hose
30 3363366 Clamp, Hose
31 8317496 Clamp, Hose
32 3951449 Hose, Pump To Tub
(Includes Item 30)
33 8055003 Clip, Harness
& Pressure Hose
35 8578338 Switch, Water
Temperature
36 3400818 Screw, Timer
Mounting
37 3949187 Switch, Rotary
39 Panel, Console
8578785 White
8578786 Biscuit
41 8541669 Bucket, Drain Hose
(Left Half)
42 8541658 Bucket, Drain Hose
(Right Half)
44 Knob, Timer
8566022 White
8566025 Biscuit
45 8566018 Dial, Timer
46 8536939 Clip, Knob
47 Knob, Control
8565944 White
8565947 Biscuit
49 388326 Screw, 8−18 x 1.25
(Panel to Top)
50 62863 Screw, 10−16 x 3/8
51 Cap, End (R.H.)
8271359 White
8271362 Biscuit
52 8577378 U−Bend,
Drain Hose
53 8539874 Shield, Suds
54 3347868 Cable Tie
55 3958077 Wiring Harness
(For Detail See
Pages 9 & 10)
5
AGITATOR, BASKET AND TUB PARTS
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
AGITATOR, BASKET AND TUB PARTS
6
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
Illus. Part
No. No. DESCRIPTION
1 8575076 Dispenser,
Fabric Softener
2 358237 Screw & Washer
(5/16−24 x 1)
3 3363003 Clothes Mover
4 3951632 Agitator
5 8528150 Tub Ring & Gasket
6 3976308 Gasket, Tub Ring
7 3354845 Clip, Agitator
8 8543666 Washer, Agitator
9 3951682 Cam, Driven
10 3366877 Dog, Agitator
Clutch (4)
11 3952374 Bearing, Cam
Driven
12 21366 Nut, Spanner
13 8526016 Basket & Balance
Ring
14 2219077 Clip, Pressure
Switch Hose
15 8519788 Balance Ring
16 63849 Tub
17 389140 Block, Basket
Drive
18 383727 Gasket, Centerpost
19 3347780 Hose, Pressure
Switch
20 3951744 Agitator
(Complete)
22 3951608 Spacer, Thrust
23 3354733 Cap, Barrier
24 3348855 Seal, Inner Cap
26 3949550 Washer
BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS
7
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 388952 Brake & Drive
Tube (Complete)
(Refer to Page 11
For Further
Breakdown)
2 63292 Washer, Spin
Tube Thrust
3 62697 Ring, Spin
Tube Support
4 63283 Ring, Retainer
5 3951311 Clutch (Complete)
6 3951308 Band & Lining,
Clutch (Includes
Items 7 & 8)
7 62646 Cap, Clutch
Spring (2)
8 3946792 Spring, Clutch
9 3360630 Gearcase
(Complete)
(Refer To Page 12
For Further
Breakdown)
10 3357334 Screw, Gearcase
To Base (3)
11 62611 Plate, Motor
Mount To
Gearcase
12 62691 Grommet, Motor (4)
13 285753 Coupling, Motor
& Isolation
14 3946532 Shield, Motor
15 3355454 Clip,
Anti−Rattle
16 3400516 Screw
17 3349637 Retainer, Motor (2)
18 3362089 Shield, Tub
To Motor
19 8528157 Motor, Main
Drive
20 3952056 Switch, Main
Drive Motor
21 8546127 Retainer, Pump (2)
22 3363394 Pump (Complete)
23 3387485 Screw, 10−16 x 5/8
MACHINE BASE PARTS
8
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
Illus. Part
No. No. DESCRIPTION
1 3400076 Screw, Bracket
Mounting
(10−32 x 5/8)
2 64067 Bracket, Spring
Outer (2)
3 63907 Spring
Suspension,(3)
4 8575214 Support & Brake,
Tub
5 64065 Bracket, Spring
Outer (L.F.)
6 63466 Link, Leveling
Mechanism (2)
7 62597 Spring, Leveling
Mechanism
8 62837 Pin, Knurled
9 62596 Foot, Rear (2)
10 8546455 Bearing,
Centerpost (2)
11 357409 Seal, Centerpost (3)
12 388492 Spring,
Counterweight
13 62568 Pad, Plate
14 3946509 Plate, Suspension
(Includes Item 13)
15 3363660 Pad, Base
16 3946512 Base Assembly
(Includes Items 6,
7, 8, 9, 13, 14
15 & 22)
17 3359452 Nut, Lock (2)
(3/8−16)
18
W10001130
Foot, Front (2)
19 8577376 Seal, Centerpost
20 285203 Centerpost
Bearing Kit
(Includes Items
10, 11 & 19)
21 63134 Ring, Sound
Deadening
22 63806 Retainer,
Suspension Spring
WIRING HARNESS PARTS
9
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
WIRING HARNESS PARTS
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 3349557 Retainer, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
(Push−In)
5 90016 Clip, Harness
(Half−Harness)
6 3390496 Clip, Harness
7 389379 Retainer, Harness
8 Timer, Block
Disconnect
3948614 Natural
352089 Black
9 62889 Receptacle,
Terminal
(3−Way)
10 353424 Plug, Terminal
(3−Way)
11 62505 Block, Disconnect
(Motor 2 Speed)
12 3347243 Block, Disconnect
13 63523 Protector
14 717252 Connector
(2−Way)
15 3352944 Clip, Harness
16 3390423 Block, Disconnect
(12−Way)
17 3347730 Receptacle
(6−Way)
18 3948617 Connector (T.P.A.)
(3−Circuit)
19 3360056 Plug (T.P.A)
(3−Circuit)
(Pressure Switch)
20 Block, Connector
3354925 Natural
3354926 Red
FOR COMPLETE WIRING HARNESS REFER TO
CONTROL AND REAR PANEL PARTS PAGE
10
For Models: WTW5500SQ0, WTW5500ST0
(White) (Biscuit)
8181315
