TOP AND CABINET PARTS
1
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
11−08 Litho in U.S.A. (drd)(bay) Part No. W10222396 Rev. B
AUTOMATIC
WASHER
TOP AND CABINET PARTS
2
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
W10200331
English/French
W10200662
Spanish
Use & Care Guide
W10200828
English/French
W10200829
Spanish
Feature Sheet
W10200856
English/French
W10200857
Spanish
W10062856
Energy Guide
W10177829
Wiring Diagram
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
4313896 Manual, Washer
2 Top
W10194572
White
W10205691
Red
3 62750 Spacer, Cabinet To
Top (4)
4
W10192089
Dispenser, Bleach
5 Cabinet
63424 White
W10205707
Red
6 62780 Clip, Top & Cabinet
& Rear Panel (2)
7 8318084 Switch, Lid
8 3351614 Screw, Ground
9 90767 Screw, 8−18 x 3/8
10 8540229 Filter, RFI
11
W10217789
Harness, Jumper
12 9724509 Bumper, Lid (2)
13
W10119828
Screw, Lid Hinge
Mounting (4)
14 8319539 Bearing, Lid
Hinge (2)
15 8559336 Hinge, Lid (L.H.)
16 91770 Hinge, Lid (R.H.)
17 Lid
W10171313
White
W10205703
Red
18 3390631 Screw,
10−16 x 3/8 (4)
CONTROLS AND REAR PANEL PARTS
3
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
4
CONTROLS AND REAR PANEL PARTS
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1
W10180973
Harness, Wiring
(For Detail See
Pages 9 & 10)
2 8536939 Clip, Knob
3 8055003 Clip, Harness &
Pressure Hose
4 3400073 Screw, Ground
5 8568314 Strap, Console (2)
6
W10194451
Panel, Rear
7 62747 Pad, Rear Panel
8
W10189267
Drain Hose
Assembly
(Includes Item 33)
9
W10177827
Timer, Control
(60 Hz.)
(Motor Not A
Service Part)
10 3351614 Screw, Ground
11 90767 Screw, 8−18 X 3/8
12
W10177795
Switch, Auto
Load Sensing
13 8566003 Bracket, Control
14 8578842 Cord, Power
(Includes Item 15)
15 3952821 Strain Relief,
Power Cord
16 Cap, End (L.H.)
(Includes Item 19)
8566035 White
W10205959
Red
17
W10188372
Shield, Suds
18
W10175893
Valve, Water Inlet
19 8312709 Clip, Console
20
W10176591
Flowmeter
21
W10185367
Clamp, Hose
22
W10166732
Hose, Flowmeter
To Tub Ring
23
W10117298
Clamp, Hose
24
W10166731
Hose, Valve
To Flowmeter
25 3347868 Cable Tie
26 8519200 Support, Rear
Panel
27 Cap, End (R.H.)
(Includes Item 19)
8566032 White
W10205953
Red
28
W10180780
Switch, Rotary
29 8577378 U−Bend,
Drain Hose
30 3363366 Clamp, Hose
31 8317496 Clamp, Hose
32 3951449 Hose, Pump To Tub
(Includes Item 30)
33 8541668 Clamp, Hose
34 3949187 Switch, Rotary
35 62863 Screw, 10−16 x 3/8
36 3400818 Screw, Timer
Mounting
37 9740848 Screw, 8−18 x 1/2
38
W10179666
Switch, Water
Temperature (ATC)
39
W10196933
Panel, Console
40
W10034730
Knob, Timer
41 8566018 Dial, Timer
42
W10034380
Knob, Control
5
AGITATOR, BASKET AND TUB PARTS
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
6
AGITATOR, BASKET AND TUB PARTS
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION
1 8575076 Dispenser
2 358237 Screw & Washer
(5/16−24 x 1)
3 3363003 Clothes Mover
4 3951632 Agitator
5
W10167984
Tub Ring & Gasket
6 3359585 Seal, Tub Ring
7 3354845 Clip, Agitator
8 8543666 Washer, Agitator
9 3951682 Cam, Driven
10 3366877 Dog, Agitator
Clutch (4)
11 3952374 Bearing−Driven
Cam
12 21366 Nut, Spanner
13 8526016 Basket & Balance
Ring
14 2219077 Clip, Pressure
Switch Hose
15 387240 Balance Ring
16 63849 Tub
17 389140 Block, Basket
Drive
18 383727 Gasket, Centerpost
19
W10211144
Hose, Pressure
Switch
20 3951744 Agitator
(Complete)
22 3951608 Spacer, Thrust
23 3354733 Cap, Barrier
24
W10072840
Seal, Inner Cap
26 3949550 Washer
BRAKE, CLUTCH, GEARCASE, MOTOR AND PUMP PARTS
7
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 388952 Brake & Drive
Tube (Complete)
(Refer to Page 11
For Further
Breakdown)
2 63292 Washer, Spin
Tube Thrust
3 62697 Ring, Spin
Tube Support
4 63283 Ring, Retainer
5 3951311 Clutch (Complete)
6 3951308 Band & Lining,
Clutch (Includes
Items 7 & 8)
7 62646 Cap, Clutch
Spring (2)
8 3946792 Spring, Clutch
9 3360630 Gearcase
(Complete)
(Refer To Page 12
For Further
Breakdown)
10 3357334 Screw, Gearcase
To Base (3)
11 62611 Plate, Motor
Mount To
Gearcase
12 62691 Grommet, Motor (4)
13 3364003 Coupling, Motor
& Isolation
14 8577374 Seal
15 3355454 Clip,
Anti−Rattle
16 3400516 Screw
17
W10086010
Retainer, Motor (2)
18 3362089 Shield, Tub
To Motor
19 661600 Motor, Main
Drive
20 62850 Switch, Main
Drive Motor
21 8546127 Retainer, Pump (2)
22 3363394 Pump (Complete)
23 3387485 Screw, 10−16 x 5/8
24 3946532 Shield, Motor
25 62863 Screw, 10−16 x 3/8
26 8572717 Capacitor
27 3949496 Clamp, Capacitor
MACHINE BASE PARTS
8
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION
1 3400076 Screw, Bracket
Mounting
(10−32 x 5/8)
2 64067 Bracket, Spring
Outer (2)
3 63907 Spring
Suspension,(3)
4 8575214 Support & Brake,
Tub
5 64065 Bracket, Spring
Outer (L.F.)
6 63466 Link, Leveling
Mechanism (2)
7 62597 Spring, Leveling
Mechanism
8 62837 Pin, Knurled
9 62596 Foot, Rear (2)
10 8546455 Bearing,
Centerpost (2)
11 357409 Seal, Centerpost (3)
12 388492 Spring,
Counterweight
13 62568 Pad, Plate
14 3946509 Plate, Suspension
(Includes Item 13)
15 3363660 Pad, Base
16 3946512 Base Assembly
(Includes Items 6,
7, 8, 9, 13, 14,
15 & 22)
17 3359452 Nut, Lock (2)
(3/8−16)
18
W10001130
Foot, Front (2)
19 8577376 Seal, Centerpost
20 285203 Centerpost
Bearing Kit
(Includes Items
10, 11 & 19)
21 63134 Ring, Sound
Deadening
22
W10145155
Retainer,
Suspension Spring
WIRING HARNESS PARTS
9
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
WIRING HARNESS PARTS
10
For Models: WTW57ESVW0, WTW57ESVH0
(White) (Red)
W10222396
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 3349557 Retainer, Harness
2 388498 Clip, Harness
3 3347812 Clip, Harness
4 3352501 Clip, Harness
(Push−In)
5 90016 Clip, Harness
(Half−Harness)
6 3390496 Clip, Harness
7 389379 Retainer, Harness
8 Timer, Block
Disconnect
3948614 Natural
352089 Black
9 62889 Receptacle,
Terminal
(3−Way)
10 353424 Plug, Terminal
(3−Way)
11 62505 Block, Disconnect
(Motor 2 Speed)
12 3347243 Block, Disconnect
13 63523 Protector
14 717252 Connector
(2−Way)
15 3352944 Clip, Harness
16 3390423 Block, Disconnect
(12−Way)
17 3347730 Receptacle
(6−Way)
18 3948617 Connector (T.P.A.)
(3−Circuit)
19 3360056 Plug (T.P.A)
(3−Circuit)
(Pressure Switch)
20 Block, Connector
3354925 Natural
3354926 Red
FOR COMPLETE WIRING HARNESS REFER TO
CONTROL AND REAR PANEL PARTS PAGE
