USER MANUAL
Congratulations on your purchase of another cutting-edge product from
White Brothers! Please read this manual completely before you ride. It will
help you to set your fork for optimum performance.
IMPORTANT CONSUMER SAFETY INFORMATION
WARNING: RIDING A BIKE IS DANGEROUS. NOT PROPERLY MAINTAIN-
ING OR INSPECTING YOUR BIKE AND ITS COMPONENTS IS EVEN MORE
DANGEROUS. IT IS ALSO DANGEROUS TO NOT READ AND FOLLOW THESE
INSTRUCTIONS.
THIS PRODUCT HAS A WEIGHT LIMIT OF 235 LBS.
1. NEVER REMOVE STEERER TUBE FROM CROWN. REMOVING IT WILL RENDER
BOTH THE CROWN AND STEERER TUBE INOPERABLE. IF SERVICE BECOMES NECES-
SARY OR REMOVAL OCCURS, PLEASE CALL WHITE BROTHERS CUSTOMER SERVICE
FOR PRODUCT EVALUATION AND DIAGNOSIS.
2. DO NOT PERFORM ANY MODIFICATIONS OR ADJUSTMENTS THAT ARE NOT OUT-
LINED IN THIS MANUAL.
3. INSPECT YOUR FORK BEFORE EVERY RIDE. INSPECT THE CROWN, TUBES, AND
AXLE SEAT AREAS FOR ANY SIGNS OF FATIGUE, BENDING, CRACKING OR OTHER
DAMAGE. MAKE SURE ALL FORK HARDWARE AND AXLE ARE TIGHT BEFORE EACH
RIDE. IF YOU NOTICE ANY TYPE OF DAMAGE, DO NOT RIDE IT. RETURN IT TO YOUR
DEALER OR TO WHITE BROTHERS FOR A COMPLETE INSPECTION AND NECESSARY
REPAIR.
4. PERFORM ALL RECOMMENDED MAINTENANCE ACCORDING TO THE MAINTE-
NANCE SECTION OF THIS MANUAL. FAILURE TO PERFORM MAINTENANCE COULD
DRASTICALLY REDUCE THE FORK’S LIFE, PERFORMANCE AND CAUSE YOUR FORK
TO BE A SAFETY HAZARD.
5. WHITE BROTHERS RECOMMENDS THAT YOU WEAR PROPER SAFETY EQUIPMENT
EVERY TIME YOU RIDE, INCLUDING AN APPROVED BICYCLE HELMET. NEVER RIDE
AT NIGHT WITHOUT LIGHTS AND REFLECTORS.
6. ALWAYS USE GENUINE WHITE BROTHERS PARTS. USE OF AFTERMARKET RE-
PLACEMENT PARTS AND UPGRADES VOIDS THE WARRANTY AND COULD CAUSE
STRUCTURAL FAILURE.
7. WHITE BROTHERS FORKS ARE DESIGNED FOR OFF ROAD USE ONLY. THEY ARE
NOT EQUIPPED WITH REFLECTORS FOR ROAD USE. IF YOU ARE GOING TO USE
YOUR FORK ON THE ROAD, HAVE A DEALER OR MECHANIC INSTALL REFLECTORS
THAT MEET THE CONSUMER PRODUCT SAFETY COMMISSION’S REQUIREMENTS.
8. ALL WHITE BROTHERS ROCK SOLID FORKS ARE DESIGNED BASED ON THE 74MM
POST MOUNT DISC BRAKE STANDARD AND ARE COMPATIBLE WITH ROTORS FROM
160MM TO 185MM. MAKE SURE TO USE THE APPROPRIATE DISC BRAKE ADAPTER
FOR THE ROTOR SIZE YOU PLAN TO USE, AS RECOMMENDED BY YOUR BRAKE
MANUFACTURER.
FORK INSTALLATION
White Brothers Rock Solid forks feature a 1.125” threadless aluminum steer
tube. Do not add threads to your White Brothers steerer tube.
1. Remove your old fork from the bicycle. Measure the diameter and length of your
old forks steerer tube to ensure that your new White Brothers steerer tube is the cor-
rect diameter and sucient length for the installation.
2. Remove the crown race from your old fork.
3. Press the crown race onto your new White Brothers fork. (See Figure #1)
4. Preassemble the fork on the bike with the headset, stem, and spacers (optional).
Refer to your stem manufacturer’s instructions to determine how much room is
needed to clamp the stem.
5. Mark the steerer tube at the top of the stem. e steerer tube will now need to be
cut to the correct length. Disassemble and cut 3mm (1/8”) below the mark. Consult
your dealer or mechanic if you don’t have the proper tools to cut the steer tube.
6. e star fangled nut must now be installed into the steer tube. If you don’t have the
set tool, we recommend dealer installation of this part. (See Figure #3)
7. Clean and grease all headset bearings and races to prepare them for assembly.
Note: Replace the bearings if there is any sign of wear or corrosion.
8. Now loosely assemble the headset, stem and handle bars as done in step four.
9. Install the headset according to the manufacturer’s instructions until there is no
play and the fork turns smoothly.
10. Install your front brake and adjust according to the manufacturer’s instructions.
11. Install the wheel on the fork and tighten the skewer the manufacturer’s specica-
tion.
12. Check to see that the brakes are adjusted and properly working. Make sure that
the brake cable does not interfere with any part of the bike and is secured to the fork
leg.
S ta r F angled N ut
S te erer T ube
S te ering S t r
F ra m
Hea
em O ptional Hea ds et S pa ce
Heads et Upper R ace
e with
ds et C ups
Headset L ower R ace
F ork C rown
LIMITED WARRANTY
Who is covered:
is warranty is extended only to the original end-use purchaser, or the person
receiving the product as a gi, and shall not be extended to any other person or
transferee. Original proof of purchase is required.
What is covered/For how long:
Your White Brothers fork is warrantied for a period of 1 year (2 years in Europe)
from the date of retail purchase. White Brothers warrants that this product, when
delivered to you in new condition, in original packaging, from a White Broth-
ers authorized reseller and used in normal conditions, is free from any defects in
manufacturing, materials, and workmanship.
What is not covered:
is warranty does not cover defects resulting from improper or unreasonable use
or maintenance; improper installation, failure to follow operating instructions;
accident; unauthorized alterations of modication of original condition; damages
caused by inadequate packing or shipping procedures; wear items including seals,
bushings, o-rings, piston bands, foam rings, stanchions, bottom out bumpers,
stripped fastener threads and heads; and products purchased from unauthorized
dealers.
What we will do:
During the warranty period, we will, at our sole option, repair or replace any
defective parts within a reasonable period of time and free of charge.
What we will not do:
Pay shipping, insurance, or transportation charges from you to us, or any import
fees, duties and taxes.
What you must do to obtain Limited Warranty Service:
Return product, with proof of purchase from an authorized White Brothers
dealer, using the following procedures:
1. Contact White Brothers for specic return and shipping instructions.
2. Label and ship the product, freight prepaid, to the address provided
by White Brothers; and
3. Place any necessary return authorization number prominently on the
outside of the carton.
MAINTENANCE
Your White Brothers fork requires periodic maintenance to ensure peak perfor-
mance and long life. Neglecting proper maintenance will reduce the fork’s life.
BEFORE EVERY RIDE: Visually inspect your fork for bent, scratched or
broken parts, abnormal sounds or other indications of possible fork failure. If
you see any scratches, cuts or cracks in the carbon ber tubes, DO NOT RIDE
THE FORK. CONTACT WHITE BROTHERS WITH ANY QUESTIONS.
Check all other bicycle components to ensure proper working order.
AFTER EVERY RIDE: Clean and dry the exterior of your fork. Visually in-
spect your fork for bent, scratched or broken parts, abnormal sounds or other
indications of possible fork failure. If you see any scratches, cuts or cracks
in the carbon ber tubes, DO NOT RIDE THE FORK. CONTACT WHITE
BROTHERS WITH ANY QUESTIONS.
OTHER CONDITIONS
THE PROVISIONS OF THIS LIMITED WARRANTY ARE IN LIEU
OF ANY OTHER WARRANTY, WHETHER EXPRESSED OR IM-
PLIED, WRITTEN OR ORAL, INCLUDING ANY WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
WHITE BROTHERS MAXIMUM LIABILITY SHALL NOT EXCEED
THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
IN NO EVENT SHALL WHITE BROTHERS BE LIABLE FOR SPECIAL,
INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES HOW-
SOEVER CAUSED INCLUDING WITHOUT LIMITATION THE RE-
PLACEMENT OF EQUIPMENT AND PROPERTY. THIS WARRANTY
IS VOID IF THE LABEL BEARING THE SERIAL NUMBER HAS BEEN
REMOVED OR DEFACED.
OTHER LEGAL RIGHTS
is limited warranty gives you specic legal rights, and you also may
have other rights that vary from state to state or country to country. Some
places do not allow limitations on implied warranties or the exclusion or
limitation of incidental or consequential damages, so the above limitations
or exclusions may not apply to you.
* Failure to register this product will not aect your limited warranty rights,
however, proof of purchase is required.
WHITE BROTHERS CYCLING IS A DIVISON OF:
MOUNTAIN RACING PRODUCTS
580 N WESTGATE DR
GRAND JUNCTION, CO 81505
970.241.3518
FOR MORE INFORMATION VISIT US ON THE WEB:
WHITEBROTHERSCYCLING.COM
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
MAINTENANCE LOG
WARRANTY REGISTRATION
NAME __________________________________
ADDRESS ________________________________
CITY/STATE/REGION______________________
ZIP/POSTAL CODE________________________
PHONE__________________________________
E-MAIL _________________________________
MODEL______________________________
SERIAL NUMBER_______________________
PURCHASE DATE_______________________
LOCATION___________________________
PLEASE REGISTER YOUR PRODUCT BY FILLING
OUT THE CARD BELOW AND MAILING TO:
MOUNTAIN RACING PRODUCTS
ATTN: WARRANTY
580 N WESTGATE DR.
GRAND JUNCTION, CO 81505
USA
REGISTRATION ALSO AVAILIBLE ONLINE AT
WHITEBROTHERSCYCLING.COM
