Quick Start Guide

Tera Card TCS1-1 and TCS2-0 SATA hosts

Features

•32 bit, 33/66MHz fully compliant PCI host interface

•Two brackets to support low profile PCI and regular

size PCI in one card

•LBA supports smaller drives as well as drives larger

than 137GB

•Supports Spread Spectrum in receiver

•Supports two independent SATA channels

•Compliant with PCI Specification, revision 2.2

•Operating Systems: Mac OS X, Windows XP

Package contents

•PCI card

•Extra bracket for use with low profile computer cases.

•CD containing user’s manual, warranty information, and drivers

Installatio em. Unplug the power cable.

3. ly seated in the

th PCI Express (PCI-e) slots.

ith a screw.

6. Follow the instructions for your computer type to install firmware/drivers.

indows driver Installation

Drivers” on the CD.

2. Follow the instructions in the “readme.txt” file.

stalling firmware for Mac Usage

1, TCS2-0 Mac Firmware” on the CD. Open the

lashrom.command” file.

tinue”.

Press “C” on your keyboard and hit enter. The terminal window will now look like this:

n

1. Power down the computer syst

2. Open the computer case.

Insert the PCI board into an available 32-bit or 64-bit PCI or PCI-X slot. Do not force it,

but it will take firm pressure to insert the card. Make sure the card is ful

slot. Note: the card is not compatible wi

4. Secure the card in place w

5. Power up the computer.

W

1. Browse to the folder “TCS1-1, TCS2-0 Windows

In

Browse to the folder “TCS1-

TCS1-1

“F

When you launch the file, a terminal window will open and prompt you to “enter C to con

This screen presents you with three options:

•Option (A) allows you to set the card to work with the Mac.

•Option (B) resets the card to work with a Windows PC.

•Option (C) is self explanatory.

Choose option (A) to set the card to work with your Mac.

After prompting you for your administrator password, it will upload the firmware to the card.

As indicated by the terminal, you will have to restart your computer for the card to function.
