WiFi CONNEkT Starter Kit Istruzioni per l’uso
Wall Sockets Featuring
WIFI EXTEND (SSID REPEAT)
POWERLINE
TECHNOLOGY
USB CHARGING
INSTALL & SET-UP GUIDE
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 5
WiFi CONNEkT is a brand of Group Gear Ltd
THIS INSTALL GUIDE IS FOR:
WiFi CONNEkT Starter Kit
and
WiFi CONNEkT Add-On Sockets
GROUP GEAR LTD
Email • technical@groupgear.co.uk
Skype • technical@groupgear.co.uk
Website • www.groupgear.co.uk
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 6
CONTENTS
Important Safety Warnings 4
Socket Labels 5-6
Installation Regulations 7
Installation Instructions 8-9
Safety Approvals 10
Product Specifications 11-12
How to Connect 13-15
Buttons & LED Functions 16-18
Set-up - SSID Repeat 19-28
Set-up - Access Point (wireless) 29-41
Set-up - Access Point (wired) 42-52
Set-up - Add-On Socket 53
Switching Configuration Mode 54-56
Bandwidth Throttling 57-60
Time Settings 61-63
Global WiFi Control 64-66
Factory Restore 67-69
3
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 7
We recommend using a qualified electrician for installation.
Please ensure that these instructions are read carefully and
fully understood before commencing with installation.
IMPORTANT SAFETY WARNINGS
CONTACT WITH MAINS ELECTRICITY CAN CAUSE SERIOUS INJURY OR DEATH.
• Do not open the back of WiFi CONNEkT Wall Socket as this will void your warranty.
• Do not store or install this product in areas of high humidity.
• Do not insert any foreign objects into the openings of the WiFi CONNEkT Wall Socket.
• Do not cover or block the holes on the rear of the unit as they serve as ventilation.
• Do not use water or substances such as paint thinners, alcohol or strong cleaning solutions to
clean the WiFi CONNEkT Wall Socket due to risk of damage to the plastic, electrocution or fire.
• Do not use the WiFi CONNEkT Wall Socket with a power supply different than 220-240 volts 50 Hz AC.
• To prevent fire hazard always use cable of the correct rating, size & type for the installation.
• Suitable for indoor use only.
• If the WiFi CONNEkT Wall Socket becomes damaged isolate all electrics and
seek the advice from a qualified electrician.
4
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 8
5
MASTER SOCKET PRODUCT LABEL
The product label is located on
the back of the unit and contains
unique details specific to
your device.
• Model number
• Power usage details
• USB charger details
• Powerline MAC address
• Ethernet/wireless MAC address
• Serial number
• Default password (refer
to user manual)
• IP Address (refer to
user manual)
• Software version
PLEASE NOTE:
MAC 1, MAC 2, Serial NR & Softw. ver
will vary for each unit
Warranty is void if the label
is removed.
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 9
6
ADD-ON SOCKET PRODUCT LABEL
The product label is located on
the back of the unit and contains
unique details specific to
your device.
• Model number
• Power usage details
• USB charger details
• Powerline MAC address
• Ethernet/wireless MAC address
• Serial number
• Default password
• IP Address
• Software version
PLEASE NOTE:
MAC 1, MAC 2, Serial NR & Softw. ver
will vary for each unit
Warranty is void if the label
is removed.
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 10
INSTALLATION REGULATIONS
UNITED KINGDOM
The WiFi CONNEkT Wall Socket must be installed in accordance with the
latest edition of the IEE Wiring (BS 7671) Regulations & Building Regulations.
REPUBLIC OF IRELAND
The WiFi CONNEkT Wall Socket must be installed in accordance with the
ETCI National Rules for Electrical installations.
7
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 11
8
INSTALLATION INSTRUCTIONS
1. Switch off the mains power supply in the consumer unit (fuse box).
2. If retro fit remove the existing wall socket from the wall.
3. Prepare the mounting surface area clearing away any plaster debris
and dust from the inside the mounting box.
4. If using the included spacer slide it over the back of the wall socket.
5. Following the diagram overleaf push the cables into the relevant terminal blocks.
(features dual earth terminals, either or both can be used).
6. All earth wires must be sleeved and terminated to the backbox.
7. Tighten the terminal screws firmly and securely.
8. This device must be earthed.
9. Screw the wall socket securely to the wall using the screws provided.
10. Switch the mains supply back on in the consumer unit (fuse box) when
the installation has been correctly completed.
11. Before use we recommend that a socket test is carried out using a socket tester.
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 12
9
NOTE
Please follow installation guide diagram for best practice.
Starter Kit - Install guide PRINT - 2018_Layout 1 09/01/2018 09:41 Page 13
SAFETY APPROVALS
• EN300328
• EN301489
• EN62311
• EN50561
•EN50412
• EN55032
• EN61000-3-2
• EN61000-3-3
• BS5733
• Complies with UK Building Regulations 2010
approved document M, Volume 2, Section 4.
10
