Gas Multi-Function Cooktop

For true wok cookin , the burner of the

Wolf multi-function cooktop sculpts the

as flame into a plume, focusin heat in

the center of the wok, then dispersin it

outward for precisely controlled cookin .

The low-profile rate fits nicely with any

Wolf as cooktop and can accommodate

your lar est stockpot. The powerful

burner exceeds 22,000 Btu. The Wolf

multi-function cooktop is available natural

or LP as.

FEATURES

•Integrated design allows for installation of

multiple cooktops or modules.

•Stainless steel top construction.

•High output 22,000 Btu dual-stacked

sealed burner.

•Automatic electronic reignition system.

•Illuminated control panel.

•Individual spark ignition system.

•Two interchangeable cast iron burner

grates with matte porcelain finish—wok

grate and low-profile continuous grate.

•Deep drawn burner pan.

ACCESSORIES

•Filler strip for installation of multiple

cooktops or modules.

•Bracket supports for installation of two

integrated modules with downdraft

(model DD30 only).

•High altitude conversion kit.

Accessories are available t roug your aut orized

Wolf dealer. For local dealer information, visit t e

find a s owroom section of our website,

wolfappliance.com.

Model IM15/S s own

wit wok grate.

Model IM15/S s own. Also s own is model CT15G/S

gas cooktop and model DD30 downdraft ventilation system.

Control panel.

INSTALLATION NOTES

Natural gas installations above 10,250' and

L gas installations above 8,600' require the

high altitude conversion kit.

Complete installation specifications can be

found on our website, wolfappliance.com.

Sown wit wok grate.

Unit dimensions may vary by ± 1/8".

SPECIFICATIONS

Exterior Finish Stainless Steel

Overall Width 15"

Overall Height 5"

Overall Depth 21"

Burner Rating 22,000 Btu

Minimum Cabinet Depth 223/4"

Minimum Height Clearance* 5"

Countertop Cut-Out Width 14"

Countertop Cut-Out Depth 191/4"

Electrical Requirements 120 V AC, 60 Hz

15 amp circuit

ower Cord 6' cord with grounded plug

Gas Rating 22,000 Btu

Shipping Weight 30 lbs

*A minimum eig t clearance of 5 1

/2" is required

between countertop and any combustible surface

directly below t e cooktop.

INSTALLATION SPECIFICATIONS

OVERALL DIMENSIONS

Gas Multi-Function Cooktop

Dimensions in parent eses are in

millimeters unless ot erwise specified.

1/2"(13)

SIDES

1" (25)

FRONT / BACK

5" (127)

21" (533)

15"

(381)

36" (914)

FLOOR TO

COUNTERTOP

30" (762) min

COUNTERTOP

TO COMBUSTIBLE

MATERIALS

SEE COUNTERTOP

CUT-OUT BELOW

14" (356)

CUT-OUT

WIDTH

COUNTERTOP CUT-OUT

FRONT

191/4"(489)

CUT-OUT

DEPTH

21/2"(64) min

7" (178) TO

COMBUSTIBLE*

7" (178) TO

COMBUSTIBLE*

SIDE

CABINET

13" (330)

max

*Minimum clearance from cooktop cut-out to combustible materials up to 18" (457) above countertop.

NOTE: Application shown allows for installation of two 15" (381) modules side by side.

15" (381)

15"

(381)

(102)

18" (457) min

(127)

LOCATION OF GAS

AND ELECTRICAL

EXTENDS ON FLOOR

21/2"(64) min*

Countertop Cut-Out Dimensions

©Wolf Appliance, Inc. all rig ts reserved. Features and specifications are subject to c ange at any time wit out notice. 8/10
