Wolf MW24 Manuale utente

Model MW24

Standard Microwave Oven

The Wolf standard microwave oven

with optional trim can be used in

combination with a Wolf built-in oven

and/or warming drawer to finish off

your cooking tower with an integrated

look. You can choose from two different

trim styles to match our L Series and

E Series ovens. Model MW24 may also

be used in a freestanding application.

This is the only standard microwave

oven that deserves the Wolf name.

Features

Built-in or freestanding standard

microwave oven with 2.0 cu ft capacity

and 1200 watts of power

Classic stainless steel trim finish

Sensor cooking

Easy-to-operate control panel and

programmable power options

Interactive display—99 minutes,

99 seconds

Warming feature

Menu label and food guide

Multi-language—English, French and

Spanish

Removable turntable and support

Safety door latches—oven will not

operate unless the door is closed

Oven light comes on when oven is

operating or door is open

Tight door seals with one-touch door

open pad

Accessories

The optional trim kits listed above are available as

sales accessories through your Wolf dealer. To

obtain local dealer information, visit the Showroom

Locator section of our website, wolfappliance.com.

Classic

Model MW24 shown with 30" L Series trim installed above Model SO30F/S built-in oven

(framed) and Model WWD30 warming drawer with stainless steel drawer front.

Also shown, Model DF604CF dual fuel range.

L Series Trim Option Classic

30" Stainless Steel Trim MWTRIM30/S

E Series Trim Options Classic

27" Stainless Steel Trim MWTRIM27-2/S

30" Stainless Steel Trim MWTRIM30-2/S

Installation Notes

If the microwave oven is built in, a trim kit is

required for proper ventilation.

Specifications will vary with L Series and

E Series trim kits. Refer to installation

instructions provided with the trim kit for

detailed specifications.

Complete installation specifications can be

found on our website, wolfappliance.com.

Unit dimensions may vary by ±

Specifications

Overall Width (freestanding) 24"

Overall Width

with 30" L Series or E Series Trim 297/8"

Overall Width

with 27" E Series Trim 267/8"

Overall Height (freestanding) 133/8"

Overall Height with Trim 181/4"

Overall Depth 191/8"

Interior Capacity 2.0 cu ft

Interior Dimensions

173/8"Wx10

1/2"Hx18

5/8"D

Power 1200 W

Electrical Requirements 120 V AC, 60 Hz

15 amp circuit

Power Cord 3' cord with grounded plug

Shipping Weight 50 lbs

Installation Specifications

Installation with 30" L Series trim

Overall Dimensions

Model MW24

Standard Microwave Oven

Dimensions in parentheses are in

millimeters unless otherwise specified.

181/4"

(464)

TRIM

HEIGHT

191/8" (486)

BEHIND FRAME

297/8" (759)

30" (762) TRIM WIDTH

24" (610)

FREE-STANDING WIDTH

133/8"

(340)

FREE-STANDING

HEIGHT

11/4" (32) 11/4" (32)

211/16" (68)

24" (610)

FREE-STANDING WIDTH

181/4"

(464)

TRIM

HEIGHT

191/8" (486)

BEHIND FRAME

133/8"

(340)

FREE-STANDING

HEIGHT

297/8" (759)

30" (762) TRIM WIDTH

267/8" (683)

27" (686) TRIM WIDTH

Model MW24 with E Series trim

Model MW24 with L Series trim

24"min

(610)

273/16"

(691)

281/2" (724)

33" (838)

RECOMMENDED CABINET WIDTH

30"min (762)

1"min

(25)

30-INCH OVEN

ROUGH OPENING

271/2" (699)

MICROWAVE

OPENING WIDTH

17"

(432)

20"min

(508)

33" (838)

RECOMMENDED CABINET WIDTH

30"min (762)

271/2" (699)

OPENING WIDTH

20"min

(508)

OPENING DEPTH

17" (432)

OPENING

HEIGHT

36" (914)

STANDARD

FLOOR TO

COUNTER

HEIGHT
