Wolf PI543418 Manuale utente

Pro Island Ventilation Hoods

ith standard features like heat sentry

and dual setting halogen lighting, olf

pro island hoods provide the ultimate in

ventilation. Pro island hoods are available

in four widths.

MODEL OPTIONS

Model PI363418 PI423418 PI543418 PI663418

Overall Width 36" 42" 54" 66"

FEATURES

•Stainless steel finish.

•Heavy-duty, 16-gauge brushed stainless

steel with continually welded seams,

hemmed edges and sides.

•Stainless steel enclosed liner.

•ecessed easy-access controls.

•Infinite-speed blower control.

•Heat sentry feature automatically turns

unit on when heat is sensed and

automatically adjusts blower speed.

•Halogen lighting with two settings.

•emovable, dishwasher-safe, restaurant-

grade stainless steel baffle filters.

•Transition with backdraft damper included.

ACCESSORIES

•Internal, in-line and remote blowers

(refer to chart above).

•6", 12", 18" and 24" stainless steel duct

covers.

Accessories are avai ab e through your authorized

Wo f dea er. For oca dea er information, visit the

find a showroom section of our website,

wo fapp iance.com.

Mode PI543418 Pro Is and Hood

Mode PI423418 shown.

ecessed controls. Baffle filters.

BLO ER OPTIONS

INTE NAL IN-LINE EMOTE

CFM 500 600 900 1200 600 1100 600 900 1200 1500

PI363418 PI423418 ••• • •••

PI543418 •• • •• •

PI663418 •• ••

INSTALLATION NOTES

Pro island hoods are sold as a shell only. An

internal, in-line or remote blower is required.

For blower recommendations, visit our

website, wolfappliance.com.

Pro island ventilation hoods are recom-

mended for use with all Wolf cooking appli-

ances.

Complete installation specifications can be

found on our website, wolfappliance.com.

Unit dimensions may vary by ± 1/8".

18" (457)

HEIGHT

OF HOOD

34" (864)

DEPTH OF HOOD

WIDTH OF HOOD

LOCATION OF ELECTRICAL SUPPLY

THROUGH TOP OF HOOD

30" TO 36"

(762–914)

TO COUNTERTOP

30" TO 36"

(762–914)

TO COUNTERTOP

SPECIFICATIONS

Exterior Finish Stainless Steel

Overall Widths 36", 42", 54" and 66"

Overall Height 18"

Overall Depth 34"

Bottom of Hood to Countertop 30" to 36"

Discharge Vertical

Duct Size 10" ound

Electrical equirements 110/120 V AC

60 Hz, 15 amp dedicated circuit

Shipping Weight 95–168 lbs

INSTALLATION SPECIFICATIONS

Pro Island Ventilation Hoods

Dimensions in parentheses are in

mi imeters un ess otherwise specified.

OVERALL DIMENSIONS

18" (457)

OVERALL

HEIGHT

OVERALL WIDTH

4" (102)

34" (864)

OVERALL DEPTH

TOP WIDTH

SUBTRACT 18" (457) FROM OVERALL WIDTH

13"

(330)

VE TICAL DISCHA GE ONLY FO ISLAND HOODS.

©Wo f App iance, Inc. a rights reserved. Features and specifications are subject to change at any time without notice. 1/10
